Fellowes LX Series Manuale utente

PLEASE READ THESE INSTRUCTIONS BEFORE USE.

DO NOT DISCARD: KEEP FOR FUTURE REFERENCE.

ENGLISH

CAPABILITIES

IMPORTANT SAFETY INSTRUCTIONS — Read Before Using!

KEY

A. Paper/card entry

B. Shredder head

C. See safety instructions below

D. Bin

E. Window

F. Safety lock

G. Control switch and LEDs

1. Reverse

2. Off

3. Auto-On (white)

4. Overheat (red)

To set lock slide

button down

**Shredder will operate continously

for indicated time. Continous

operation beyond this time will

trigger a cool down period.

*70g A4 paper at 220-240v, 50/60Hz, heavier

paper, humidity or other than rated voltage

may reduce capacity. Maximum recommended

daily usage rates: 30 sheets; 5 cards.

To learn more about Fellowes products and features go to www.fellowes.com

For safety reasons, shredder will operate only if the

shredder head is in correct position and used with

supplied basket.

LX10

Sheets Per Pass* 6

Cards Per Pass* 1

Maximum Continuous Operation** 3 min

Cool down Period** 30 min

Cut Size 4mm x 37mm

Current draw at capacity 1.0A

Entry Width 220mm

Will shred: Paper, small paper clips, plastic credit cards and staples

Will not shred: CD/DVDs, Continuous forms, adhesive labels, transparencies, newspaper, cardboard, large paper clips,

laminates or plastic other than noted above

• Operation, maintenance, and service requirements are covered in

the instruction manual. Read the entire instruction manual before

operating shredders.

• Moving parts. Keep away from children and pets. Keep hands away

from paper entry. Always set to off or unplug when not in use.

• Keep foreign objects – gloves, jewelry, clothing, hair, etc. – away

from shredder openings. If object enters top opening, switch to

Reverse ( ) to back out object.

• DO NOT use aerosol products, petroleum based or aerosol lubricants

on or near shredder. DO NOT USE “CANNED AIR” OR “AIR

DUSTERS” ON SHREDDER. Vapors from propellants and petroleum

based lubricants may combust causing serious injury.

• Sharp edges, DO NOT touch exposed cutting blades under shredder

head.

• Do not use if damaged or defective. Do not disassemble shredder.

Do not place near or over heat source or water.

• Avoid touching exposed cutting blades under shredder head.

• Shredder must be plugged into a properly grounded wall outlet or socket of

the voltage and amperage designated on the label. The plug on the power

supply cord is used as the disconnect device. The grounded outlet or socket

must be installed near the equipment and easily accessible. Energy converters,

transformers, or extension cords should not be used with this product.

• FIRE HAZARD – Do NOT shred greeting cards with sound chips or batteries.

• For indoor use only.

• Unplug shredder before cleaning or servicing.

BASIC SHREDDING OPERATION

Plug in and set to Auto-

On ( )

Feed paper/card straight

into paper entry and

release

When finished shredding,

set to Off ( )

PAPER/CARD

LIMITED PRODUCT WARRANTY

Limited Warranty: Fellowes, Inc. (“Fellowes”) warrants the parts of the machine to be free of

defects in material and workmanship and provides service and support for 2 years from the date of

purchase by the original consumer. Fellowes warrants the cutting blades of the machine to be free

from defects in material and workmanship for 3 years from the date of purchase by the original

consumer. If any part is found to be defective during the warranty period, your sole and exclusive

remedy will be repair or replacement, at Fellowes’ option and expense, of the defective part. This

warranty does not apply in cases of abuse, mishandling, failure to comply with product usage

standards, shredder operation using an improper power supply (other than listed on the label), or

unauthorized repair. Fellowes reserves the right to charge the consumers for any additional costs

incurred by Fellowes to provide parts or services outside of the country where the shredder is initially

sold by an authorized reseller. ANY IMPLIED WARRANTY, INCLUDING THAT OF MERCHANTABILITY

OR FITNESS FOR A PARTICULAR PURPOSE, IS HEREBY LIMITED IN DURATION TO THE APPROPRIATE

WARRANTY PERIOD SET FORTH ABOVE. In no event shall Fellowes be liable for any consequential

or incidental damages attributable to this product. This warranty gives you specific legal rights.

The duration, terms, and conditions of this warranty are valid worldwide, except where different

limitations, restrictions, or conditions may be required by local law. For more details or to obtain

service under this warranty, please contact us or your dealer.

PRODUCT MAINTENANCE

*Only use a non-aerosol vegetable oil in long nozzle container such as Fellowes 35250

Set to Off ( ) Set to Reverse ( )

for 2-3 seconds

*Apply oil across entry

All cross-cut shredders require oil for peak

performance. If not oiled, a machine may

experience diminished sheet capacity, intrusive

noise when shredding and could ultimately

stop running. To avoid these problems, we

recommend you oil your shredder each time

you empty your waste bin.

OILING SHREDDER

FOLLOW OILING PROCEDURE BELOW AND REPEAT TWICE

Australia Residents Only:

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other

reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.

The benefits under Fellowes’ Warranty are in addition to other rights and remedies under a law in relation to the shredder.

Overheat Indicator: When the Overheat Indicator is illuminated, the shredder has exceeded its maximum operating temperature and needs to cool down. This indicator will remain

illuminated and the shredder will not operate for the duration of the recovery time.

TROUBLESHOOTING

PAPER JAM

Alternate slowly back and forthSet to Reverse ( )

for 2-3 seconds

Set to Off ( )

and unplug

Gently pull uncut

paper from paper

entry. Plug in

Set to Auto-On ( )

and resume shredding

21 3

1 2 3 6

1789 Norwood Avenue, Itasca, Illinois 60143 •1-800-955-0959 •www.fellowes.com

Brands

CUSTOMER SERVICE & SUPPORT

www.fellowes.com

Australia: 1800 33 11 77
