Felt AR Manuale utente
AR Owner’s Manual
Felt AR InternaLoc Seatpost Assembly
and Cable Routing Manual
This manual is not intended as a comprehensive use,
service, repair or maintenance manual. Please see your
dealer for all service, repairs or maintenance. Your dealer
may also be able to refer you to classes, clinics or books
on bicycle use, service, repair or maintenance.
Note:
Part IV AR Mechanical Compatible Frame
Mechanical Routing Instruction
Electronic Wiring Instruction
Part V AR Electronic Specific Frame
Electronic Wiring Instruction
Part VI Brake Routing Instruction
Pg. 25-34
Pg. 35-45
Pg. 46-54
Pg. 55-56
. . . .
. . . . . .
. . . . . .
. . . . . . .
Part I VM Seat Clamp
Part II VR Seat Clamp
Part III InternaLoc Seatpost
Pg. 1-5
Pg. 6-8
Pg. 9-22
. . . . . . . . . . . .
. . . . . . . . . . . . .
. . . . . . . . . .
1. Saddle Clamp Upper (x2)
2. Saddle Clamp Adjustment Head Half (x2)
3. Saddle Clamp Lower Clamp (x2)
4. Saddle Clamp Binder Nut with Keyway
5. Saddle Clamp Binder Bolt
6. VM Seatpost
AR Seatpost & Small Parts
VM Saddle Clamp Assembly
1 4
25
3 6
-1-
Locate the two AR saddle clamp
Lowers and place each onto a
saddle clamp Upper, aligning
the holes with the oval-shaped
holes of the saddle clamp
Uppers as illustrated below.
Step 2
The parts should appear as the
image on the left, in two stacks
of three pieces, with the bolt,
nut and seatpost remaining.
Step 3
Locate the two AR saddle clamp
Uppers and place each into a
saddle clamp adjustment Head
Half, positioning them so the
hooked surfaces are adjacent
and can grip a seatpost rail.
Step 1
-2-
The chamfer of the adjustment
head half will be placed in
contact with the chamfered
surface of the seatpost. Apply
friction paste between surfaces.
Being cautious to maintain
the order of parts in each
stack, turn each stack
upside down on the table
so now the threads face
away from the table.
Place the bolt and nut threads-
down into the holes of the two
stacks of pieces as pictured,
aligning tooth on nut to slot in
saddle lower clamp.
Step 5
Step 4
Note: Grease bolt threads.
-3-
Pick up one stack and place it thread-side down into the
seatpost so the chamfer of the adjustment head half is in
contact with the chamfer of seatpost alloy insert as pictured.
Holding the remaining stack of pieces in place on the other
side of the seatpost, align the bolt threads with the nut threads
and tighten 2 to 3 turns.
Step 7
Step 6
-4-
Once saddle angle and fore/aft position
are adjusted, tighten the saddle clamp
bolt to 10-12 nm of torque.
Slide the saddle into the saddle clamp
assembly beginning from the rear of the
saddle.
Step 9
Step 8
-5-
VR Saddle Clamp Assembly
1. VR Seatpost
2. 3T Saddle Clamp Inner Splined Adjusment Cylinder
3. 3T Saddle Clamp Outer Splined Adjustment Cyclinder
4. 3T Saddle Clamp Outer Clamp
5. 3T Saddle Clamp Binder Bolt
VR Seatpost & Small Parts
1 4
25
3
-6-
Slide the Inner Splined Adjustment
Cylinder into the Outer Splined
Cylinder as pictured.
Slide the Inner and Outer Splined
Adjustment Cylinder assembly into
the VR seatpost as pictured.
Place the Outer Clamp piecs over either end of the
Inner and Outer Adjustment Cylinder assembly and
insert binder bolts through the hole on the face of
the Outer Clamp pieces as pictured. Align threads
on binder bolts with the threads on Inner Splined
Adjustment Cylinder.
Step 2
Step 3
Step 1
Note: The 3T Outer Clamp
parts supplied are for 7mm
round rails. Optimal Outer
Clamp pieces are available
for other saddle rail options
from 3T.
-7-
Install the AR/3T saddle clamp
Outer Clamp and Binder Bolt
assembly, one on each side ot the
VR seatpost, and adjust the saddle
fore/aft position and angle. Tighten
the Binder Bolt to 5 nm.
Slide the saddle rails onto the
clamp assembly starting at the back
of the saddle.
Step 5
Step 4
-8-
