Fender Nashville Power Manuale utente

0.022 2

OF OUTPUT JACK ASS'Y

POWERCHIP ASS'Y TO TERMINAL #8

SOLDER WHITE WIRE FROM

JACK ASS'Y L=.300 TO AVOID SHORT

ASS'Y TO TERMINAL #2 OF OUTPUT

SOLDER SHIELD FROM POWERCHIP

JACK ASS'Y

ASS'Y TO TERMINAL #4 OF OUTPUT

SOLDER RED WIRE FROM POWERCHIP

#1 OF OUTPUT JACK ASS'Y

BATTERY SNAP TO TERMINAL

SOLDER BLACK WIRE FROM

TO BACK OF CONTROL POT

BLACK WIRE FROM BRIDGE PICKUP

RED FROM MIDDLE PICKUP

SOLDER BLACK WIRE FROM NECK PICKUP

TO GROUND PAD ON POWERCHIP

INSULATOR ON LEAD WIRE AND SOLDER

STRIP PIEZO SHIELD TO ALLOW 1/4" OF

CABLE TO PIEZO IN ON POWERCHIP

SOLDER BLACK LEAD WIRE FROM PIEZO

SOLDER TO POWERCHIP

LENGHT OF PIEZO CABLE BEFORE

INSTALL SHRINK TUBING OVER ENTIRE

SEE DETAIL " A "

BATTERY SNAP

5 WAY SWITCH

NECK PICKUP TO

WHITE WIRE FROM

5 WAY SWITCH

NASHVILLE POWER TELECASTER 0135000/5002

N.T.S.

BRIDGE SECTION

SECTION (6)

FOR EACH BRIDGE

ACOUSTIC PICKUP

OUTPUT JACK

RED WIRE FROM

BATTERY SNAP

BOTTOM VIEW : N.T.S.

TERMINAL DETAIL

MIDDLE PICKUP TO

YELLOW WIRE FROM

BRIDGE PICKUP TO

WHITE WIRE FROM

07-12-2000

Pg. 2 of 5

BRIDGE ASSEMBLY

CONTROL ASSEMBLY

SCALE: N.T.S.

TOP VIEW

BOTTOM VIEW

JUMPER IN THIS

POSITION

RED WIRE FROM

BATTERY-SNAP

RED WIRE FROM

TWO CONDUCTOR

SHIELDED CABLE

TURN TRIM-POT FOR PIEZO

VOL FULL CLOCKWISE

SHIELD FROM TWO

CONDUCTOR CABLE

MAG-INPUT PAD

WHITE WIRE FROM

TWO CONDUCTOR

SHIELDED CABLE

NASHVILLE POWER TELECASTER 0135000/5002

FISHMAN PREAMP POWERCHIP (WIRING DETAIL)

07-12-2000

Pg. 3 of 5
