Ferguson Online Neo Manuale utente

Ferguson Online Neo Wireless Scanner –

Scanner User Guide

Ferguson Online

Page 1 of 45

Ferguson Online NEO Scanner User Guide

Ferguson Online Neo Wireless Scanner –

Scanner User Guide

Ferguson Online

Page 2 of 45

Ferguson Online NEO Scanner User Guide

You have received a Psion NEO device that has been previously configured with the ECOM Application.

You have installed Windows Mobile Device Center/Active Sync and the Upload Application onto your PC

or laptop. This guide is the User Guide after all installation is complete.

Contents

Ferguson Online NEO Scanner User Guide ............................................................................................... 1

Selecting the Program You Would Like To Use......................................................................................... 3

Features of Program 1 –Qty And Product............................................................................................5

Features of Program 2 –Info, Qty, And Product ................................................................................15

Features of Program 3 –Qty, Product, And Info ................................................................................ 27

Downloading the Items You’ve Scanned ................................................................................................37

Turning Off the Gun ................................................................................................................................ 39

Ferguson Online Neo Wireless Scanner –

Scanner User Guide

Ferguson Online

Page 3 of 45

Turning On the Scan Gun

To turn the Psion NEO scan gun on, press and hold the red power/enter button.

Selecting the Program You Would Like To Use

Once you’ve turned the scan gun on, the first screen you will see if the one below.

You will see 3 options of programs to select from:

a. 1-Qty and Product

b. 2-Info, Qty, And Product

c. 3-Qty,Product and Info

Red power/enter button

Ferguson Online Neo Wireless Scanner –

Scanner User Guide

Ferguson Online

Page 4 of 45

Note: If you do not see the three programs, but instead you see the screen below, then with your stylus

or finger tip tap the Windows symbol in the bottom left corner of the screen.

Tap the Windows symbol in

the bottom left of the screen.

Tap “Programs”.

Tap “E-Commerce”.

Ferguson Online Neo Wireless Scanner –

Scanner User Guide

Ferguson Online

Page 5 of 45

The next screen should be the programs screen.

Features of Program 1 –Qty And Product

1) Upon selecting program 1 –Qty And Product, you will be prompted to enter a “User ID”. The

value entered is not validated against any database. It is free-form text. We encourage you to

enter your employee ID number or initials so that anyone reviewing the downloaded files will be

able to tell who was using the gun.

Enter Employee ID or Initials in “User

ID” box using keypad.

Ferguson Online Neo Wireless Scanner –

Scanner User Guide

Ferguson Online

Page 6 of 45

2) After entering your User ID, you can either tap “[Enter]-Accept” on the touch screen or use the

red Enter key on the keypad to get to the next screen.

Note: For the letters Y and Z, hit the XYZ key once for X, twice for Y, and three times for Z.

3) You will be brought to the entry screen below.

Red enter key

Ferguson Online Neo Wireless Scanner –

Scanner User Guide

Ferguson Online

Page 7 of 45

a. # Scanned This value will display the number 0 before you begin scanning products.

If you successfully scan an item, the value will increment by 1 each time.

b. User ID This is the User ID that you entered in the previous step. To change the user,

tap “Exit”.

c. Qty When you first come to this screen, your curser will be in the Qty field. Simply

use the key pad to key the desired qty to be scanned or you may also scan a barcode

that represents a qty.

Note: you must either hit the red Enter key or tap the Product field to move on to

scanning. If you put a qty in and attempt to scan without hitting Enter, the gun will beep

as if it’s scanning but the “# Scanned” at the top right corner will not increment. This

means you have not successfully scanned the item.

Ferguson Online Neo Wireless Scanner –

Scanner User Guide

Ferguson Online

Page 8 of 45

Note: If you attempt to put your cursor in the Product field and scan before entering a

value in the Qty field, you will get an error that says:

Please enter a valid Quantity.

Ferguson Online Neo Wireless Scanner –

Scanner User Guide

Ferguson Online

Page 9 of 45

d. Product After entering a qty, either tap the Product field on the touch screen or hit

the red Enter key . Once the cursor is in the Product field, simply scan a barcode for

a product code or manually enter the product code into this field.

e. [Enter]-Accept If you choose to manually enter a product code into the Product field,

use the [Enter]-Accept button on the touch screen to accept the entry of that product.

You may also hit the red Enter key on the key pad .

Note: if you’ve chosen to scan a barcode, then you will not need to hit Enter.

Ferguson Online Neo Wireless Scanner –

Scanner User Guide

Ferguson Online

Page 10 of 45

f. F1-Review/Modify Once you have scanned all of the items, it is recommended that

you review them and modify any that you might need to change. To do that you may

either tap the “F1-Review/Modify” button on the touch screen, or press the blue

Function button and then the 1/F1 key on the key pad.

i. When you select “Review/Modify”, you will be brought to a screen that looks

similar to the one below.

Press

blue

Function

key, then

1/F1
