Fiat Ulysse Guida utente

Dear Customer,

Thank you for selecting Fiat and congratulations on your choice of a Ulysse.

We have written this booklet to help you get to know all your new Ulysse’s features and use it in the best possi-

ble way.

You should read it right through before taking to the road for the first time.

You will find information, tips and important warnings regarding the driving of the vehicle to help you derive the

maximum from your Ulysse’s technological features. You will also find very valuable tips for your own safety, the

car’s weelbeing and about how to protect the environment.

The Warranty Booklet lists the services that Fiat offers its Customers:

• the Warranty Certificate, with terms and conditions for maintaining its validity

• the range of additional services available to Fiat Customers.

Best regards and good motoring!

This Owner Handbook describes all the Fiat Ulysse versions. As a consequence, you should consider

only the information which is related to the engine and bodywork version of the car you purchased.

MUST BE READ!

REFUELLING

JTD engines: only refuel with diesel fuel conforming to the European specification EN590.

The use of other products or mixtures may irreparably damage the engine with invalidation of the warranty

due to the damage caused.

ENGINE START-UP

JTD engines: make sure the handbrake is pulled up; put the gear lever into neutral; press the clutch pedal

down to the floor without touching the accelerator; then turn the ignition key to Mand wait for the instru-

ment panel warning light mto go out, then turn the ignition key to Dand release it as soon as the engine

starts.

JTD enegines with automatic gearbox: make sure the handbrake is pulled up and the gear lever is in P

or N; then turn the ignition key to Mand wait for the instrument panel warning light mto go out, then turn

the key to D, without touching the accelerator and release it as soon as the engine starts.

PARKING OVER INFLAMMABLE MATERIAL

When functioning normally, the catalytic converter reaches high temperatures. For this reason do not park

the vehicle over inflammable material, grass, dry leaves, pine needles, etc.: fire hazard.



ELECTRICAL ACCESSORIES

If, after buying the car, you decide to add electrical accessories (that will gradually drain the battery), visit a

Fiat Dealership. They can calculate the overall electrical requirement and check that the car’s electric sys-

tem can support the required load.

쇵

CODE CARD

Keep the code card in a safe place, not in the car. You should always keep the electronic code written on

the CODE card with you in case you need to carry out an emergency start-up procedure.

SCHEDULED SERVICING

Correct maintenance of the car is essential for ensuring it stays in tip-top condition and safeguards its safety

features, its environmental friendliness and low running costs for a long time to come.

THE OWNER HANDBOOK CONTAINS…

…information, tips and important warnings regarding the safe, correct driving of your car, and its mainte-

nance. Pay particular attention to the symbols

(personal safety)

(environmental protection)

(the car’s

wellbeing).

PROTECTING THE ENVIRONMENT

A system for continuosly monitoring emission system components to ensure greater environmental protec-

tion is fitted in your car.

WELCOME ABOARD Fiat Ulysse

Fiat Ulysse is a compact saloon with an original bodyline, designed to offer great driving satisfaction, ensure safe-

ty and be as friendly as possible to the environment.

Everything, from its new engines to its safety devices, from its improved comfort for driver and passengers alike

to its practical solutions, contributes to make you appreciate your Fiat Ulysse’s personality.

And you will realise it later when you discover that its driving style and performance goes hand in hand with

new manufacturing processes that help cut running costs.

The Fiat Ulysse, for example, no longer needs to be taken in for its first servicing after the traditional 1,500 km...

but after 30,000 km.

THE SIGNS TO HELP YOU DRIVE CORRECTLY

The signs you see on this page are very important. They highlight those parts of the handbook where, more than

anywhere else, you should stop for a minute and read carefully.

As you can see, each sign has a different symbol to make it immediately clear and easy to identify the subjects in

the different areas:

Personal safety.

Important. Total or partial failure to

follow these instructions can place dri-

ver, passengers or others in serious

danger.

Environmental protection.

This shows you the correct proce-

dures to follow to ensure the vehicle

will not harm the environment.

The car’s wellbeing.

Important. Total or partial failure to

follow these instructions will result in

the risk of serious damage to the car

and may invalidate the warranty as

well.

SYMBOLS

Special coloured labels have been at-

tached near or actually on some of the

components of your Ulysse. These la-

bels bear symbols that remind you of

the precautions to be taken as regards

that particular component.

A list of the symbols to be found on

your Ulysse is given below, with the

name of the component to which it re-

lates at the side of it.

These symbols are divided into the

following four categories: danger, pro-

hibition, warning, obligation.

DANGER SYMBOLS

Front headlights

Danger - Electric shocks.

Belts and pulleys

Moving parts; keep parts

of the body and clothes

away.

Climate control

system tubing

Do not open. Gas under

high pressure.

Battery

Corrosive fluid.

Battery

Explosion.

Fan

May cut in automatically

when the engine is off.

Expansion tank

Do not remove the cap

when the coolant is boiling.

Coil

High voltage.

PROHIBITION SYMBOLS

Battery

Keep away from open

flames.

Battery

Keep away from children.

Heat shields - belts -

pulleys - fan

Do not touch.

WARNING SYMBOLS

Catalytic converter

Do not park over inflam-

mable materials. See chap-

ter: “Protecting the emission control

devices”.

Power steering

Do not exceed the max-

imum fluid level in the

reservoir. Use only the fluid specified

in section “Capacities”.

Brake circuit

Do not exceed the max-

imum fluid level in the

reservoir. Use only the fluid specified

in the section “Capacities”.

Windscreen wiper

Only use fluid of the type

specified in section “Ca-

pacities”.

Engine

Use only the oil specified

in section “Capacities”.

Diesel vehicle

Use diesel fuel only.

Expansion tank

Use only fluid of the type

specified in section “Ca-

pacities”.

DIESEL

OBLIGATION SYMBOLS

Battery

Protect your eyes.

Battery

Jack

See the Owner hand-

book.

GETTING TO KNOW YOUR CAR

DASHBOARD

fig. 1
