LCD-40 installation in an existing MS-9200(C)/E
InanexistingMS-9200(C)/Einstallation,thefollowingproceduremustbefollowedtoprogramtheMS-9200(C)/Efor
usewiththeLCD-40SeriesAnnunciator:
1. ConnecttheLCD-40totheMS-9200(C)/EControlPanel(refertotheappropriateMS-9200(C)/ETechnical
ManualandProductInstallationDrawings).
2. Software Versions:
(1)IfsoftwarewitheitherthePartNumber73750or73829isinstalledintheMS-9200(C),theLCD-40
SeriesAnnunciatormusthavesoftwarewithaPartNumberof73779or73879tooperatewiththe
FACP(FireAlarmControlPanel). IfsoftwarewithaPartNumberof#M9200V20orhigherisinstalled
in the MS-9200(C), the LCD-40 Series Annunciator must have software with a Part Number of
#LCD40V20orhighertooperatewiththeFACP.
(2)IfsoftwarewithPartNumber73846isinstalledintheMS-9200E,theLCD-40SeriesAnnunciator
musthavesoftwarewithPartNumber73779or73879tooperatewiththeFACP. Ifsoftwarewith
PartNumber#M9200EV20orhigherisinstalledintheMS-9200E,theLCD-40SeriesAnnunciator
musthavesoftwarewithaPartNumber of#LCD40V20 orhigher tooperate withtheFACP.
3. Uponinitialpower-upoftheMS-9200(C)/Ewiththenewsoftwareinstalled,thefollowingmessagemay
appearontheMS-9200(C)/ELCDdisplay:
"TROUBLEINSYSTEM
PROGRAMCORRUPTED"
Whether the above message appears or not, the following steps must be followed to program the
MS-9200forusewiththeLCD-40.
4. Press the ENTER key.
5. Press the 1 key to select Programming.
6. Enter your LEVEL 1 password.
7. Press the ENTER key.
8. Press the 1 key to select Autoprogram.
9. Upon successful completion of the Autoprogram function, press the LEFT ARROW key.
10. Press the 3 key to select System Edit.
11. At this point, use the RIGHT ARROW key to select TRM = N (or L/P = N as shown in the manual).
12. Press the UP ARROW key to change 'N' to'L' in order to program the system for LCD-40 use.
13. Be sure to press the ENTER key to store the programming change in memory.
14. Press the LEFT ARROW key several times to get back to the SYSTEMS ALL NORMAL display.
15.Atthispoint,theMS-9200(C)/EshouldbesuccessfullyprogrammedforusewiththeLCD-40. Toensure
thatallprogrammingchangeshavebeenaccepted,depresstheRESETkey. Thesystemshouldreturn
to the SYSTEMS ALL NORMAL display, after a successful software check.
