Firehawk FHB10W Manuale utente

PLEASE read all instructions BEFORE beginning to pair a system!

1.0 Plug alarm into pattress and switch on radio

base, the pattress led will ﬂash green twice per

second. If not please complete step 6.0

2.0 Bring alarm & radio base together then twist/slide to lock into place.

3.1 Place two alarms on the table spaced approximately

20cm APART.

3.2 Press the TEST BUTTON on one alarm and wait

THREE SECONDS.

3.3 Press the TEST BUTTON on the other alarm.

3.4 Watch carefully as both pattresses FLASH GREEN

AND RED

3.5 As soon as one FLASHES GREEN ONLY, move it to one side.

3.6 The other pattress will continue to ﬂash red/green until it BEEPS ,then it will FLASH GREEN

(The CO will BEEP FOUR TIMES) THE TWO ALARMS ARE NOW PAIRED.

3.7 There is now a 10 SECOND WINDOW to allow another device to be added to the system Step 4.0

If no other devices are to be added proceed to Step 5.0

(Repeat steps 1.0 and 2.0 for each alarm)

Wait for smoke or heat alarm to BEEP TWICE Wait for the CO alarm to BEEP FOUR TIMES

1CONNECT

2ALARM ASSEMBLY

3PAIRING TWO ALARMS

SMOKE ALARM FHB10W HEAT ALARM FHH10W CO ALARM CO7B (10Y)W

20cm

PAIRED

PRESS

& WAIT

FOR 3

SECS.

3.1 3.2 3.3 3.4 3.5

3.2 3.3

PAIRED

20cm

UNPAIRED

ALARM(S)

Pairing Radio Linked Alarms Instructions

PAIRED

Fireblitz Extinguisher Ltd Units 15/17 Manford Industrial Estate, Manor Road, Erith, Kent DA8 2AJ.

Tel: 01322 342238 |Fax: 01322 331532 |Email: sales@ﬁreblitz.co.uk |www.ﬁreblitz.co.uk

Fireblitz reserve the right to change the design or speciﬁcation details without prior notice.

REF: RADIOINSTRUCT09/20

4.1 To add additional alarms to the system simply PLACE THE PAIRED ALARM THAT BEEPED

(see section 3.6) approximately 20cm apart to a ASSEMBLED ALARM (see point 2.0)

UNPAIRED ALARM.

4.2 Firstly, press the TEST BUTTON on the PAIRED ALARM and wait THREE SECONDS.

4.3 Then press the TEST BUTTON on the UNPAIRED ALARM.

4.4 Repeat steps 3.4 to 3.6

5.1 When all alarms have been added to the system (smoke / heat alarm will BEEP ONCE,

CO alarms will BEEP FOUR TIMES) the pattresses will now continue to FLASH GREEN .

5.2 Once pattresses have stopped FLASHING GREEN .and BEEPING the alarms are now

READY FOR INSTALLION.

5.3 If any device fails to beep and ﬂashes red please reset all devices step 6.0 and repeat the pairing

process.

5.4 Assuming everything went to plan please now test each alarm in the system.

4PAIRING ADDITIONAL ALARMS

5PAIRED ALARMS READY FOR INSTALLATION

20cm

PRESS

& WAIT

FOR 3

SECS.

4.1 4.2 4.3

PAIRED

UNPAIRED

ALARM(S)

6.1 To reset the pattress, remove the alarm device

and press the black button. This will restore

factory settings and unlearn all paired devices.

The Led will ﬂash red four times then begin to

ﬂash green as in step 1.0.

6.2 Start again and repeat pairing process.

6DEVICE RESET

CLICK HERE FOR ONLINE TROUBLE SHOOTING GUIDE
