flamco VHW 260 Manuale utente

Flamco VHW 260
Sanitary heat pump
-10 °C to 35° C
Flamco VHW 260
Contents(adaptinownlanguage)
ENG Installation and user manual 3

2
BE Flamco Belux
J. Van Elewijckstraat 59
B -1853 Grimbergen
+32 2 476 01 01 info@amco.be
CH Flamco AG
Fännring 1
6403 Küssnacht
+41 41 854 30 50 info@amco.ch
CZ Flamco CZ
Evropská 423/178
160 00 Praha 6
+420 602 200 569 info@amco.cz
DE Flamco GmbH
Steinbrink 3
42555 Velbert
+49 2052 887 04 info@amco.de
DK Flamco
Tonsbakken 16-18
DK-2740 Skovlunde
+45 44 94 02 07 info@amco.dk
EE Flamco Baltic
Löötsa 6
114 15 Tallin
+ 372 56 88 38 38 info@amco.ee
FI Flamco Finland
Ritakuja1
01740 Vantaa
+ 358 10 320 99 90 info@amco.
FR Flamco s.a.r.l.
BP 77173
95056 CERGY-PONTOISE cedex
+33 1 34 21 91 91 info@amco.fr
HU Flamco Kft.
(A Pest Megyei Bíróság mint Cégbíróság.
Cg.13-09-136479)
H-2330Dunaharaszti,
Jedlik Ányos út 25
+36 24 52 61 31 info@amco.hu
NL Flamco B.V.
Postbus 502
3750 GM Bunschoten
+31 33 299 75 00 support@amco.nl
PL FlamcoSp.zo.o.
ul. Akacjowa 4
62-002 Suchy Las
+48 616 5659 55 info@amco.pl
SE Flamco Sverige
Kungsgatan 14
541 31 Skövde
+46 500 42 89 95 vvs@amco.se
UAE Flamco Middle East
P.O. Box 262636
JebelAli,Dubai
+971 4 881 95 40 info@amco-gulf.com
UK Flamco Limited
Washway Lane- St Helens
Merseyside WA10 6PB
+44 1744 74 47 44 info@amco.co.uk

3
ENG
Table of content
1. APPLICATION 4
1.1 GENERAL 4
1.2 TECHNICAL SPECIFICATIONS 5
1.3 APPLIANCE LAYOUT 6
1.4 WIRING DIAGRAM 7
1.5 STORAGE AND TRANSPORT 8
1.6 SCOPE OF SUPPLY 8
1.7 OPERATING PRINCIPLE OF THE VENTILATION HEAT PUMP WATER HEATER 10
2. SAFETY 11
2.1 SAFETY,CONTROLANDPROTECTIONDEVICES 12
2.1.1 HIGH PRESSURE SWITCH 12
2.1.2 HIGH LIMIT SAFETY CUT-OUT 12
2.1.3 TEMPERATURE SENSOR FOR AIR INLET 12
3. INSTALLATION 13
3.1 INSTALLATION LOCATION 13
3.2 CONNECTING THE CONDENSATE HOSE 14
3.3 CONNECTING THE DUCTS 14
3.4 FILLING THE CYLINDER 15
3.4.1 WATER QUALITY 15
4. USE 16
4.1 FLOWCHART MENU 16
4.2 OPERATION 17
4.3 OPERATION MODES 17
4.4 SETTING THE DOMESTIC HOT WATER TEMPERATURE 17
4.5 MAIN MENU 18
4.6 “PROG” SUBMENU - OPERATING MODES 18
4.6.1 “MANUAL” OPERATING MODE 18
4.6.2 “P1”,“P2”AND“P3”OPERATINGMODES 19
4.6.3 “FULL” OPERATING MODE 19
4.6.4 “OFF” OPERATING MODE 19
4.7 “MODE” SUBMENU - HEATING MODE 19
4.7.1 ELECTRICAL HEATING MODE 20
4.7.2 “HEAT PUMP” OPERATING MODE 20
4.7.3 “COMBI” OPERATING MODE 20
4.8 “SET” SUBMENU - SETTINGS 20
4.8.1 DATE-SETTINGTHETEMPERATUREUNIT,DATE,TIMEANDDAYOFTHEWEEK 21
4.8.2 PROG - PROGRAMMING OF THE OPERATING TIMES 21
4.8.3 “LEG” - AUTOMATIC THERMAL DISINFECTION 23
4.8.4 « FAN » - FANSPEED 24
4.8.5 « DUCT » - USE OF DUCTS 24
4.8.6 “PURG” - DRAIN 24
4.8.7 “FSET” - DEFAULT SETTINGS 24
4.8.8 “INFO” SUBMENU – INFORMATION 25
4.9 FAULT DIAGNOSIS 25
4.10 DEFAULT SETTINGS 25
4.11 FAULTS DISPLAY 26
4.11.1 DISPLAY 26
5. MAINTENANCE (YEARLY CHECK) 27
5.1 GENERAL INSPECTIONS 27
5.2 CLEANING 27
5.3 CONDENSATE PIPE 27
5.4 REFRIGERANT CIRCUIT 27
5.5 HIGH LIMIT SAFETY CUT-OUT 28
5.6 DRAINING THE CYLINDER 28
5.7 “SERVICE” MENU 28
6. DISMANTLING, RECYCLING AND ENVIRONMENTAL PROTECTION 29
ENG Installationandusermanual

4
ENG Installationandusermanual
1. APPLICATION
1.1 GENERAL
The appliance may only be used for DHW (Domestic Hot Water) heating. Using the boiler for any other purpose
will be considered incorrect use. Flamco accepts no liability for any damage resulting from such use.
The appliance is not suitable for commercial or industrial applications. It is approved for household use only.
DeFLVHW260isaheatpumpforDHWheatingwiththefollowingspecications:
•(H) CFC-free polyurethane hard foam isolated (70 mm) vessel of stainless steel (1.4521);
•Indirect heating of DHW;
•Refrigerant R134a;
•Temperature DHW adjustable between 30° C to 70° C;
•Automatically switch-off heat pump at air temperature between -10°C to 35°C;
•Easy serviceable;
•NoFluorgasescerticationneededforchangingthecompleteheatpumpassembly
Please read the installation instructions before installing the appliance!
Please read the operating instructions before commissioning the appliance!
Please observe the safety instructions in the operating instructions!
Theinstallationlocationmustmeettherequirementsforsufcientventilation!
Installation must only be carried out by an authorized contractor!

5
ENG
1.2 TECHNICAL SPECIFICATIONS
Heatingoutput–inaccordancewithEN255-3,airtemperature20°C,
heating water from 15°C to 45°C.
Unit VHW 260
Output kW 1,7*
Total heating output (including electric booster heater) kW 3,7*
COP - 4,3*
Standby energy consumption kW/day 0,74*
Heatingoutput–inaccordancewith16147,XLcycle,airtemperature
15°C,heatingwaterfrom10°Cto54°C.
VHW 260
COP - 3,2*
Heating time (HP only) - 8h48*
Standby energy consumption kW/day 1,08*
Heatingoutput–inaccordancewith16147,XLcycle,airtemperature
7°C,heatingwaterfrom10°Cto54°C.
VHW 260
COP - 2,79*
Heating time (HP only) - 10h38*
Standby energy consumption kW/day 0,97*
General specifications VHW 260
Description - Air/water heat
pump for DHW
use
Motor type Fan - DC
Adjustment range sp1/sp2 (without pipe work) m3/h 380/490
Control ventilator Adjustable by HMI
(2 speed)
IP-class - 21
Refrigerant/mass -/gram R134a/400
Operating temperature °C -10 … +35
Maximum pressure compressor bar 27
Reservoir capacity liter 250
Maximum pressure vessel bar 10
Sound level (distance 1 meter-380m3/h) dB(A) 50*
Power supply V/Hz 230 /50
Max. power consumption Watt 2600
Nominal current (HP-only/HP + immersion heater) A 2,6/11,3
Start-up current A 13,5max.
Fuse rating A 16
Electrical immersion heater kW 2
Plug type - Type E
Labels and markings - CE/LCIE*/WEEE/
NF*/RoHS/
REACH/ACS
*allthesevaluescanonlybereleasedordefinedafterthemeasurementsdonebyLCIE.

6
ENG Installationandusermanual
1.3 APPLIANCE LAYOUT
1
2
6 7 8
12
11
1
17
15
10
16
9
13 14
2
5
4
3
[1] Water inlet – G3/4”
[2] Water outlet – G3/4”
[3] Thermal insulation
[4] Water inlet to condenser
[5] Water outlet from condenser
[6] Fan
[7] Evaporator
[8] Condenser (gas/water heat exchanger)
[9] Compressor
[10] Sensor pocket for DHW temperature sensor
[11] Electrical backup immersion heater
[12] Adjustable feet (3x)
[13] Air outlet aperture
[14] Air inlet aperture
[15] Condensate outlet
[16] Circulation pump
[17] Front protective covering

7
ENG
1.4 WIRING DIAGRAM
[1] NTC temperature sensor for air inlet
Thisballonandcomponentisaddedinthispicture,notinEPS
[2] NTC temperature sensor
[3] NTC temperature sensor in water inlet
[4] Power cable
[5] High Pressure Switch
[6] Electrical capacitor for compressor
[7] Compressor
[8] High limit safety cut-out for compressor
[9] Circulation pump
[10] Fan
[11] Immersion heater
[12] High-limit safety cut-out for immersion heater
[13] Electronics box
[14] NTC temperature sensor (evaporator plates)
[15] Electrical capacitor for fan start
[16] Electrical capacitor for fan speed
[17] Defrost valve

8
ENG Installationandusermanual
1.5 STORAGE AND TRANSPORT
WARNING:Transportdamage!
•Take care when handling the appliance.
•Toavoiddroppinganddamagingtheappliance,donotpivotit.
NOTICE:Transportdamage!
•Toavoidtransportdamage,donotremovetheprotectivepackaging.Wait
until the appliance is at the installation location to remove the protective
packaging.
•Transport and set down the appliance carefully. Jerky movements can
damagethecomponents,thevesselandtheirconnectionsortheexternal
casing.
•Use suitable means of transport to bring the appliance to theinstallation
location(specialcar,pallettruck,etc).
General information
The appliance is delivered on a single pallet and is protected against transport
damage by special packaging. The appliance must be stored and transported
vertically in its original packaging1and the cylinder must be empty. Ambient
temperatures of -20 °C to +60 °C are permissible for storage and transport.
This device is not intended for use by persons (including children) with
physical,sensoryormentaldisability,ofbypersonswithlackexperienceorknowledge,unlesstheyhavereceived
from a person in charge of their safety adequate supervision or preliminary instructions on how to use the device.
Dare must be taken at all times to keep children from playing with the device.
1.6 SCOPE OF SUPPLY
1-Flamco VHW 260
2-Set of documents
3-Condensate drain and hose pillar
1 Horizontaltransportationispermittedovershortdistances,providedthattheconditionsdescribedabovearefulfilled.
Flamco VHW 260
Sanitary heat pump
-10 °C to 35° C
Flamco VHW 260
Contents(adaptinownlanguage)
ENG Installation and user manual 3
2
3
1

9
ENG
Data plate
The data plate is located on the rear side of the appliance.
1.6.1 ACCESSORIES
This table need to be determined.
Description Article number
Safety valve 12450
…. ….
…. ….
…. ….
Dimensions

10
ENG Installationandusermanual
1.7 OPERATING PRINCIPLE OF THE VENTILATION HEAT PUMP WATER HEATER
The Ventilation Heat Pump Water heater consists
ofanexpansionvalve(1),anairheatexchanger(2),
a compressor (3) and a water heat exchanger (4).
A refrigerant circulates in the closed system (5). In
theexpansionvalve,thepressureandtemperature
oftherefrigerantarelowered,whichbecomes
vaporous. It extracts heat from the air (6) via the air
heat exchanger. The vapour is then compressed
by the compressor. This increases the pressure
and the temperature (7). The heat is transferred to
the water via the water heat exchanger (8). And the
cycle begins anew. It is therefore possible to heat
water with a low temperature of 10 ºC to domestic
hot water with a temperature of 60 ºC. This makes
it possible to create four parts of energy (heat) from
just one part of energy (electricity).
