PrecisionCell HT

High Temperature Rigid Filters

Bulletin PB1003-1106

General

PrecisionCell HT filters are designed for high tem-

perature applications up to 900o F. They feature the

same rugged construction as the Gas Turbine

PrecisionCell. The HT version is manufactured of

specially selected components to meet high temper-

ature requirements.

They are ideal for paint drying ovens or any appli-

cation requiring high efficiency filtration at high tem-

peratures. PrecisionCell HT filters are offered in two

high temperature operating ranges; 750ºF and 900º

F and efficiency ranges of 65%, 85% and 95% per

ASHRAE Standard 52.1. Offered as a MERV 11-14

according to ASHRAE 52.2.

Construction

The enclosing frame is manufactured of aluminized

steel, which is designed to eliminate spalling of cor-

rosion inhibitors @ elevated temperatures.

The media pack is stabilized by a media pack

retaining bar and captured by faceguards upstream

and downstream. Grid strap bracing on the air

entering and leaving sides maintain the rigidity and

integrity of the PrecisionCell HT.

The media is designed for operation in high tem-

perature applications and manufactured from one

continuous sheet of wet-laid micro-fine fiberglass,

which provides the required tensile strength and

operating pressure drop for these stringent applica-

tions.

Physical Data

Frame: 24 ga. aluminized steel

Media: Dual layer microfine fiberglass

Separators: Hemmed-edge corrugated aluminum

Header Frame: 7/8” wide aluminized steel

Faceguards: Aluminized steel expanded

Cross Bracing: 1/2” “T” strap downstream and

horizontal strap upstream

Important Features

• Continuous duty up to 900ºF

• Aluminized steel construction

• 65%, 85%, 95% efficiencies

• Faceguards and grid straps

• MERV 11 to 14

Flanders Filters - Foremost in Air Filtration

Toll Free: 1-800-637-2803

Operating Nominal Size 500 fpm Media Weight

Efficiency Limit ºFH x W x D (inch) Rating Area Each

cfm pd (sq. ft.) (lbs)

750 24 x 24 x 12 2000 .45 140 26

60-65% 24 x 12 x 12 1000 69 21

900 24 x 24 x 12 2000 .50 175 28

24 x 12 x 12 1000 90 22

750 24 x 24 x 12 2000 .55 140 26

80-85% 24 x 12 x 12 1000 69 21

900 24 x 24 x 12 2000 .60 175 28

24 x 12 x 12 1000 90 22

750 24 x 24 x 12 2000 .65 140 26

90-95% 24 x 12 x 12 1000 69 21

900 24 x 24 x 12 2000 .70 175 28

24 x 12 x 12 1000 90 22

Notes:

1. PD represents clean pressure drop in inches w.g. The recommended final pressure drop is 2.5 inch w.g.

2. Operation down to zero velocity is satisfactory for all models.

3. Efficiencies are average and are based on ASHRAE Standard 52.1 and 52.2 dust spot test methods.

Performance values stated may be averages typical of the products listed. Contact factory for actual perform-

ance test reports on specific products.

4. Perfmormance values shown in this publication may be averages or estimates intended to generally represent

product styles. Always contact factory for latest actual test data on specific Flanders Precisionaire models.

1.0 General

1.1 High temperature rigid filters shall be

PrecisionCell HT separator type as manufactured

by Flanders.

1.2 Filter sizes and temperature ranges shall be as

scheduled on the drawings.

2.0 Filter Construction

2.1 Filters shall be constructed by pleating a contin-

uous sheet of wet-laid micro-fine glass media

into closely spaced pleats with hemmed-edge

corrugated aluminum separators.

2.2 The filter pack shall be sealed into a 24 ga.

aluminized steel frame with fire-retardant

sealant.

2.3 Expanded metal aluminized steel faceguards

shall be installed on the air entering and air leav-

ing sides.

2.4 A 1/2” “T” strap shall be installed on the down-

stream side and 1/2” horizontal strap on the air

entering side.

3.0 Performance

3.1 Initial and final resistance shall not exceed the

scheduled values.

3.2 Media area shall equal that of the scheduled

high temperature filter.

3.3 The manufacturer shall guarantee performance

as outlined in section 7.4 of ARI Standard 800.

Guide Specifications

REPRESENTED BY:

Flanders - PrecisionAire

Foremost in Air Filtration

Toll Free: 1-800-637-2803
