Fleurette FLEURETTE 2016 Manuale utente
USER MANUAL 2016
CONTENTS
Introduction Page 2
How to use this manual Page 3 - 4
Motorhome manners Page 5 - 6
Water system and gas installation Page 7 - 13
Fresh Water
Preparing to travel
Gas installation
Heating
Waste water
Winterzation
Tank level
Electrical system Page 14 -16
12 V and 220 V supply
Fuses
Electrical unit
Supply diagram
Equipments Page 17 - 18
Hotplate
Extractor hood
WC
Refrigerator
Oven
Food safety record Page 19
Laying-outs Page 20 - 21
Pull-down bed
Television
Sunroof
Dinette sleeping area
Radio - GPS Page 22
Quick repair kit Page 22
Maintenance of the interior Page 23 - 25
(Cushions, windows, mattress….)
Warranty Page 26
Fleurette dealers in France and Europe Page 27 - 28
PAGE 1
Dear Sir, Madam,
Thank you for having chosen FLEURETTE or FLORIUM and for your trust in
FLEURETTE Company.
Our team has taken great care in preparing your motorhome and we hope it will come
to your expectation.
It is very important to read this manual carefully as well as the instructions provided
with all the fittings. The information in this book will make you save time and help you
to know your new motorhome. To ensure greater comfort and to prevent excessive
depreciation of your motorhome, use it properly.
Some equipments listed in the Fiat user manual are not delivered in your motorhome
(bulb box, warning triangles, ...), it is up to you to purchase the equipment.
For your information, the Fleurette plant in Benet (85) is a place dedicated to the
production of motorhomes Fleurette / Florium. Only high-tech interventions are carried
out by our Technical Service, only after an appointment agreed between your dealer
and our after sales service.
Your dealer remains your main contact.
PAGE 2
Your dealer should give you the Fiat user manual, the
chassis maintenance book when your mothorhome is
delivered. We recommend that you take note of the
contents and follow the instructions.
Instructions for use
Seatbelts:
Before use, you must fasten your seat belt. No changes should be made to the
original system. Always use the same belt for one person and never hold a baby or
child on your lap with your seat belt fastened. Replace your seat belts in case of
deterioration. When putting in place back cushions, make sure to reposition the seat
belt in order to use it properly.
The rear seats / facing the road are compatible with child seats approved "Universel“
The rear seats are not suitable for attaching a child seat with ISOFIX
attachments.
Authorized seats facing the road:
When driving, all passengers must be seated facing forward or on the 5th place
opposite (see below). Some models of motorhomes Fleurette / Florium allow the
transformation of their cushions to comply with this rule.
PAGE 3
Original seat Take out the cushions
Check the locking
Lift the back Position the cushions
PAGE 4
Use of motrorhomes:
The motorhomes are designed for RECREATIONAL use and in no way intended to be
used as a living space.
Fresh water capacity while driving:
Pay attention, some vehicles may be limited to respect your motorhome’s maximum
load limit.
Use of gas and safety
The gas installation complies with European Regulations 2001/56 / EC and 2004/78 /
EG and the EN1919 standard. The bottles are placed in the external compartment
provided for this purpose. This compartment has to be locked. The two bottles must be
securely strapped.
A gas circuit control should be done every year by your distributor or an approved
workshop.
A ramp of gas valves allows individual connection of each device.
Taps located under the bed or in the sink cabinet = low profiles
Taps located in the front compartment of the double floor = A-classes
Warning: the validity of the flexible supply hoses (rubber gas pipes) is 5 years.They
have to be changed before the expiry date indicated on them.
Information on Fiat chassis
For all information concerning the original equipment of the vehicle, please refer to the
car manufacturer’s instructions Fiat and / or Alko. You will find instructions on the right
tire pressure, wheel alignment, the engine battery, fuse positions…
For information, the wheel alignment is set by the chassis manufacturer before leaving
the factory.
Warning: Our entire range is equipped with special tires for motor homes.
Safety instructions :
The existence of permanent upper and lower ventilation is essential in order to ensure
constant air renewal. The ventilation devices should nevery be blocked.
Never leave childen unattented in your motorhome.
Make sure you know the location and operation of emergency exits while leaving
escape routes.
In case of fire:
Evacuate occupants
Shut off the gas bottles
Disconnect power
Give the alarm and call the fire department
Use a fire blancket of a fire extinguisher if you can dot it securely
MOTORHOME MANNERS
The camper, used as a means of transport is likened to cars. It meets the traffic
rules applicable to this category of vehicles.
In town centers or in urban areas, it is advisable to park in places:
- That are not densely populated
- That do not impair visibility, nor business
- Where the motorhome will not obstruct traffic
Likewise, when using a motorhome as accomodation in these places you must not:
- Spread to the area around the vehicle
- Cause inconvenience to residents
- Monopolise the public area
- Allow pets to run riot or disturb your neighbours
Wastewater disposal must take place:
• in appropriate places, never near housing, rivers, streams or crops.
• emptying "black water" (lavatory) into the rain water drainage system is strictly
prohibited.
All water drainage valves must be closed whilst travelling. Even fresh water should
be emptied discreetly, to avoid suspicion.
Household garbage must be placed in plastic bags and disposed in designated
places.
By observing all of these common-sense rules, everyone can fully enjoy the
many pleasures to be had by motorhome enthusiasts
Source : Comité de liaison du Camping-Car
3, Rue des Cordelières
75013 PARIS
PAGE 5
PAGE 6
MOTORHOME MANNERS
RESPECT is the name given to the charter of the good motorhome driver
RRespect nature
EAvoid grouping
SPark in the appropriate places
PFavor local trade
EBe courteous and discreet
CCommunicate with others
TKeep all of these commitments
Source : UNIVDL
WATER AND GAS
Fresh water
Your motorhome is equipped with its own fresh
water tank with a capacity of 120l or 150l or
300l according to the models. The tank should
be filled with drinking water.
It is filled through an external nozzle fitted with a
lock cap, located on the side of the vehicle. To
open the cap, turn it counterclockwise to
clockwise.
The inspection door of the fresh water tank is
located on the ground under the living room or
between the passenger seat and the tray.
A blue cap is opened or closed with hand. You
can vent the tank via a sink plug placed in the
tank with an access via the inspection door.
For models Mayflower 70LD, Magister 70LD
and A-Classes under 3T, an handle on the fresh
water tank allows to get a volume of 20 liters:
- Turn the valve ¾ turn in the opposite direction
clockwise for 20 liters.
- Turn 2 turns in the opposite direction of
clockwise to empty the tank.
Depending on the model the pump is located
under the seat or under the bed.
PAGE 7
Vanne 20l ou vidange
Water supply
A switch on the control panel activates the
water supply pressure.
(See instructions on the control panel in the
white bag)
The pump sends water (see Nordelettronica
instructions in the white bag) to the sink in the
kitchen, washbasin in the bathroom, the shower
and WC. Before opening a tap, make sure there
is water in the water tank. If not used for a
while, the pump works automatically to maintain
pressure in the system.
The absence of water in the tank may damage
the pump.
The boiler must be full to get hot water. Start the
pump and open the hot water taps to actuate
the valve to release the air. (Heating time=
roughly 30mn)
The metallic filter should be cleaned at the
beginning and end of each season.
To disassemble, purge the water system,
unscrew the bell under the filter and get it out.
Go on tightening the bell by hand and check for
leaks.
The expansion tank located under the kitchen or
under the bed or under the seat (according th
the model) should be emptied every year by
draining the water circuit, tap opened , fresh
water tank emptied and clean in FrostControl
drain position (see Truma documentation).
PAGE 8
Water pump
Filter
Turning on the water
Expansion tank
