flexyPage LT-Line Manuale utente
Product datasheet flexyPage displays
LT-Line
sizes from 25,6 cm (10,1”) up to 139,7 cm (55”)
© ELFIN GmbH 2019-12-14
Content
Introduction
Advice for this flexyPage documentation
Area of application
Safety instructions and restrictions
Installation and maintenance
Ambient conditions
Installation
Assembling
Electrical connection, interfaces and LED
SIM card
USB0
Ethernet interface
Digital inputs
Speaker - Audio
Switch
CAN + Power supply
Principle sketch
Maintenance
Dust
Humidity
Security updates
Aspect ratio notes
Technical data
General data of the LT-Line displays
Designation
Display
Display controller
Power supply
Housing
Ambient conditions
Size specific data of the displays LT-Line 10,1 and 10,4
Size specific data of the displays LT-Line 12,1 4:3 and 16:9
Size specific data of the displays LT-Line 15,0, 15,1 and 15,6
Size specific data of the displays LT-Line 17, 18,5 and 19
Size specific data of the displays LT-Line 21.5, 24 and 29
Size specific data of the displays LT-Line 32
Size specific data of the displays LT-Line 38
Size specific data of the displays LT-Line 42, 46 and 55
© ELFIN GmbH technology flexyPage.de 2
Introduction
flexyPage is a modern, flexible system for the simultaneous display of lift information and
multimedial presentations in a lift car and in the floors of a building.
The flexyPage LT-Line display is an open-frame display for back-wall mounting into car or
landing panels of a lift. An optional stainless steel frame also allows front mounting. By
using the integrated CAN interface, external sensors, in- and output modules as well as
controllers which support the CANopen standard CiA 417 CANopen-Lift can be connected.
The audio signal is available via a speaker connection.
Configuration and access to the internet is provided by the LAN interface or via an optional
internal 4G modem. If no internet access is available, software updates can be uploaded if
needed and configurations imported or exported through the USB interface.
The LT-Line displays can be used in any lift and for various applications, in new installations
as well as for retrofitting.
The flexyPage functions and layout can be flexible configured, also by using the internet.
Therefore, a configuration software is not required, as every up-to-date internet browser can
be used.
Do you need a touch sensor? Our DM-Line displays are available for this purpose.
Do you have questions or suggestions? Contact us at [email protected].
© ELFIN GmbH technology flexyPage.de 4
Advice for this flexyPage documentation
This product datasheet describes the technical properties of the flexyPage LT-Line displays.
It constitutes only a small part of the whole documentation and is undergoing continual
improvement.
The documents, images, graphics and videos, as well as
hardware and software are protected by copyright. It is
prohibited to copy or circulate this document without prior
written consent. Translations do also require a written
declaration of consent. The ELFIN GmbH is sole contact for
copies, translations and similar concerns.
This documentation is continuously revised and updated with
the greatest of care. Nevertheless, errors cannot be excluded.
We are pleased to hear your comments, helpful references and
suggestions about this documentation. Please contact our
sales department or support for that.
The ELFIN GmbH will not accept any liability for errors or any potential damage and their
consequences related to the delivery or usage of this document.
Please carefully read the user manuals, product datasheets and safety and mounting
instructions before using!
The actual user manual as well as other documents and application cases can
be found at the product website:
Introduction to the flexyPage system flexypage.de/en/doc/documentation
Quick start guide flexypage.de/en/doc/documentation
Video tutorials flexypage.de/en/tags/video-tutorials
flexyPage user manual flexypage.de/en/doc/documentation
Widget descriptions flexypage.de/en/doc/widget-descriptions
Product datasheets flexypage.de/en/doc/technical-documentation
Frequently asked questions flexypage.de/en/faq
Sales contact flexypage.de/en/sales
Support contact flexypage.de/en/support
© ELFIN GmbH technology flexyPage.de 5
Area of application
The flexyPage displays were designed for use in lifts. They can be installed in new
constructed buildings and in context of modernisation measures for lifts of all manufacturers.
The displays can be used in both the lift’s cabin and on the landings.
The flexyPage LT-Line display is an open-frame display for back-wall mounting into indicator
boards and panels. It is available in different sizes, resolutions and optionally with a touch
sensor. Please find the requirements concerning power supply and environmental conditions
attached.
Safety instructions and restrictions
Precisely follow this document’s instructions, as well as the ones you will find on
the device. An exclamation mark inside a warning triangle points out that
warnings and hints are available, whose disregard may lead to danger or material
damage.
The flash with an arrow leads your attention to dangerous voltage. Disregarding
this warning can be life-endangering.
Installation and setup is limited to professionals after having read the whole product
documentation!
Restoration of damaged assemblies is only permitted for the ELFIN support. An autonomous
opening of the housing may damage the device which automatically leads to the loss of the
warranty claim. If the device is already damaged when delivered, do not connect it to the
power supply and contact the ELFIN support!
Do not use any caustic cleaning material and avoid installing sharp devices to the glass.
Heat accumulation may cause an overheating of the flexyPage monitor controller and
displays, which may lead to damages. The internal electricity is cooled passively using the
housing. If this includes louvers, ensure that these are always unobstructed, so that a
sufficient air circulation is provided. Wetness and liquids can also cause bypasses or
electrical shocks. Therefore, only make use of and connect the device inside a building.
Ensure that liquids and carrying elements do not come in touch with the device.
© ELFIN GmbH technology flexyPage.de 6
Installation and maintenance
Danger: Electrical Shock
Danger to life
This product operates with a 12 VDC or 24 VDC safety extra-low voltage (SELV)
power supply. Do not use incompatible adapter.
Danger: Electrical Shock
Danger to life
Input and output of this device are only suitable for low voltage signals.
Do only use the intended signals.
Caution: Explosive Risk
The installed main board is equipped with a lithium battery.
Danger of explosion if battery is incorrectly replaced. Replace only with battery
of the same or equivalent type.
Warning: Burns Hazard
The product generates considerable amount of heat. The housing transports this
heat to the environment and therefore gets hot. Caution when touching the
housing, burns hazard!
Ambient conditions
Caution: Damage
Do not operate the product beyond the specified ambient conditions.
Danger: Explosive Risk
Do not operate the product in potentially explosive atmosphere.
© ELFIN GmbH technology flexyPage.de 7
Installation
Assembling
The open-frame flexyPage LT-Line displays are designed for back-wall mounting. Using an
optional stainless steel frame it can also be mounted front mounting. To protect the
displays, a pane of acrylic or safety glass in front of the display is required. It can be ordered
separately.
Caution: Damage
The display and pieces of glass are very sensitive. Pay attention that you do not
scrape or pollute them.
If it is necessary to consider a specific mounting direction, a sticker at the back of the device
indicates this.
Electrical connection, interfaces and LED
After having installed the device mechanically, you can connect the required interfaces using
the connections portrayed in the illustration below.
Terminals of a flexyPage display
The flexyPage displays provide the following connecting possibilities:
User LEDs
Next to the connection terminals there are three user LEDs - LPC, PCI and CPU. These
serve to output internal status states.
© ELFIN GmbH technology flexyPage.de 8
SIM card
In addition to the user LEDs, there is also a SIM card holder that can hold a SIM card for an
optional 4G module (LTE) (Art. No. fel4A-02a-opt-lte).
USB0
The device includes a USB 2.0 (high speed) interface. It is possible to use USB port, e.g. to
install a firmware update or to load configurations.
Note: Load
The interface max. provides 500 mA. If the load exceeds this, the internal controller may
cause a reset or the interface is blocked until the next reset! In this case, use an external USB
port with an own power supply.
Ethernet interface
To configure and to connect to the internet an ethernet interfaces 10/100 MBit is provided.
The default network parameter can be taken from the sticker.
The LEDs at the ethernet socket have the following function:
LED E1 on: internal power on
flashing: network traffic active
LED E2 flashing: connection to external network device
Digital inputs
Four inputs for discrete signals are available on the monitor controller.
The following connectors can be used here: ELFIN ArtNo. bl-dn35-5-I1-COM
1
I1
2
I2
3
I3
4
I4
5
COM
The inputs are galvanically isolated from the other signals of the device and refer to the
COM signal.
++The impedance of the inputs is 5 kOhm. The input signals are detected as high from
6 VDC.
© ELFIN GmbH technology flexyPage.de 9
Speaker - Audio
The displays is equipped with an internal 6W amplifier for the output of audio signals.
Speakers (4-8 ohms) for voice announcement, gong, video sound or background music can
be connected to a 2-pin output terminal.
The following connectors can be used here: ELFIN ArtNo. bl-dn35-2-SP
Switch
The monitor controller has two internal micro switches OPT, Term. The OPT switch activates
special functions. The Term switch activates the internal termination of the CAN interface
with a 120 ohm resistor.
CAN + Power supply
The terminals for the CAN interface and the power supply of the device are located on the
CAN / Power connector. The CAN interface is compatible with ISO 11898-2 (high speed) and
galvanically isolated. The displays support the standard 'CANopen CiA-417 CANopen-Lift' as
master and as client. The CAN bus is terminated via an internal switch. If the 'switch contact
2' is in the "ON" position, the connection of the CAN termination (120 Ω) takes place.
The following connectors can be used here: ELFIN ArtNr. bl-dn35-4-CL-VIN
1
CAN-L (CL)
2
CAN-H (CH)
3
Power 22..26 VDC
4
Power GND
Danger: Electrical Shock
Danger to life
This product operates with a 24...28 VDC safety extra-low voltage (SELV) power
supply. Do not use incompatible adapter.
© ELFIN GmbH technology flexyPage.de 10
