FLORABEST HG00249 Manuale utente
SOLAR ANIMAL REPELLER
IAN 270734
®
SOLAR ANIMAL REPELLER
Operation and Safety Notes
SOLCELLSDJURSKRÄMMA
Bruksanvisning och säkerhetsanvisningar
DYRESKRÆMMER
MED SOLAR
Brugs- og sikkerhedsanvisninger
LAMP OP ZONNE-ENERGIE
DIE DIEREN AFSCHRIKT
Bedienings- en veiligheidsinstructies
GB/IE Operation and Safety Notes Page 5
SE Bruksanvisning och säkerhetsanvisningar Sidan 21
DK Brugs- og sikkerhedsanvisninger Side 36
NL/BE Bedienings- en veiligheidsinstructies Pagina 51
A
B
7
8
9
1210
11
1
2
3
4
5
6
C
13
15
16
17
14
5GB/IE
Intended use........................................................................................Page 6
Mechanism ............................................................................................Page 6
Description of parts.......................................................................Page 7
Scope of delivery............................................................................Page 8
Technical Data....................................................................................Page 8
Safety instructions..........................................................................Page 9
Safety instructions for rechargeable batteries.....Page 10
Before use
Replacing/inserting rechargeable batteries ............................................Page 11
Charge indicator.........................................................................................Page 12
Charging the batteries................................................................................Page 13
Start-up
Installation on the ground, using the ground spike...................................Page 14
Installation on a wall using a screw/ peg.................................................Page 15
Operation...............................................................................................Page 15
Adjusting the motion sensor .......................................................................Page 16
Adjusting the signal frequency...................................................................Page 16
Maintenance and Cleaning....................................................Page 17
Troubleshooting...............................................................................Page 17
Disposal....................................................................................................Page 18
Warranty.................................................................................................Page 19
6 GB/IE
Solar Animal Repeller
Intended use
This product is intended for use as an animal repellant, through the
use of background noise and/or flashing light. Any use of the
product for other or additional purposes is considered improper
use. No claims can be made for problems cause by improper use
or failure to comply with the operational and safety instructions
included in the operational manual. The product is not intended
for commercial use.
Mechanism
The solar animal repellent registers the body heat of animals that
move in the detection range of the motion sensor. As soon as an
animal is registered, the device produces a very high pitched tone,
which is uncomfortable for animals. As different animals can have
different hearing ranges, the frequency of the signal can be ad-
justed. Nocturnal animals can also trigger an automatic flashing light.
To be able to repel lots of different animals, you can adjust the
settings to combine any of the signal frequencies with the flashing
light.
7GB/IE
WARNING: Frequencies from 16 Hz to a maximum of 20kHz
can generally be heard by humans. However, with increasing age,
humans‘ ability to hear higher frequencies is reduced. You should
work on the assumption the programmes 1, 2 and 5 release
frequencies, which can be heard by humans.
Thus you should set up the device so that it is out of the hearing
range of humans.
Description of parts
1Speaker
2Sensitivity controller
3Frequency controller
4Flashing light
5Motion sensor
6Charge indicator
7Loop
8Battery cover
9Seal
10 Solar cell
11 Holder for the ground spike
12 USB charging socket
13 USB charging cable
14 Ground spike
15 Rechargeable batteries (3 x
AA, NiMH, 800mAh each)
16 Screw
17 Peg
8 GB/IE
Scope of delivery
1 Solar Animal Repellent
1 USB Charging Cable
1 Ground Spike (two parts)
3 Rechargeable batteries (AA, NiMH, 800mAh each)
(already inside)
1 Peg (Ø 6mm)
1 Mounting Screw (3.8 x 30mm)
1 Set of Instructions for Use
Technical Data
Operational voltage: 3.6V , max. 500mA
Rechargeable batteries: 3 x NiMH batteries/AA/1.2 V/800mAh
(already inside)
Protection class:
Protection type: IP44 (splash-proof)
Signal frequency: approx. 13.5kHz–23.5kHz
Motion sensor:
Range: approx. 8m
Detection angle: approx. 110°
9GB/IE
Safety instructions
Before using the product, please familiarise yourself with all of the
safety information and instructions for use! When passing this
product on to others, please also include all the documents!
This device may be used by children aged 8 years
and up, as well as by persons with reduced physi-
cal, sensory or mental capacities, or lacking experi-
ence and/or knowledge, so long as they are supervised or
instructed in the safe use of the device and understand the
associated risks. Do not allow children to play with the device.
Cleaning and user maintenance should not be performed by
children without supervision.
Do not use this product if you notice any damage.
Ensure that the solar panel does not get dirty or covered in
snow or ice. Otherwise the performance of the solar panel
will be diminished.
Do not place objects on top of the device!
Keep away from open flames!
If the device makes unusual noises or you discover smoke or
similar faults, removed the rechargeable battery from the
10 GB/IE
device immediately or separate the device from the charge
adapter.
Never use the device within human hearing range. The device
releases frequencies, which can be disturbing or uncomforta-
ble for many people.
Safety instructions for
rechargeable batteries
DANGER TO LIFE!
Keep rechargeable batteries away from children. If they are
accidentally swallowed seek immediate medical attention.
CAUTION! EXPLOSION HAZARD!
Never throw batteries into fire or water.
Do not exert mechanical strain on batteries.
Risk of battery leaking!
In the event of a battery leak, remove the rechargeable
battery from the device immediately to prevent damage.
Do not let the fluid from a leaking battery come
into contact with your skin, eyes or mucous mem-
branes. In the event of contact with battery acid,
