FLOS RF16082 Manuale utente
EN
F2-S BLACK DIFFUSER
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
RF16082
REV. 1
DATE 06/07/2021
Ray SRay F2
1
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
EN
Fig.1
A
D
RAY F2 F5921030
REV. 1
DATE 06/07/2021
Position the diffuser (D) on the support (A).
RF16082
F2-S BLACK DIFFUSER
2
WARNING! When installing and whenever acting on the appliance, ensure that the power supply has been switched off.
For the installation of the spare-part, it is necessary to consult a qualified electrician.
©2021 Flos -All rights reserved -www.flos.com
Flos reserves the right to introduce any changes to its own models, without prior notice.
Assemble the diffuser (O) on the frame, installing it as shown in the image
on the left hand side, ensuring that the edges of the diffuser are placed
over the appropriate supports (P).
EN
Fig.1
RAY S F5931030
REV. 1
DATE 28/07/2021
O
P
RF16082
F2-S BLACK DIFFUSER
