A. Speed/Flow Rate Display: In flow rate mode, displays the current flow rate,
and the motor speed is displayed at the C frame. In speed mode, displays the
current set up speed and flow rate is displayed at the C frame. Click A to amend
the flow rate or speed. When fixed time and volume function is turned on, A is
disabled and you are not allowed to amend the flow rate or speed.
B. Real-time Dynamic Display: Real-time display of the current running status,
dynamic display of the running results.
C. Real-time Parameter Display: Display the current running state and setup
parameters. When the fixed volume measurement turns on, displays the fixed
volume measurement parameter. When the fixed time and volume function turns
on, displays the fixed time and volume parameter. When these two functions
turn off, display parameters are all 0.
D. Setting Parameter Display: Display the fixed volume measurement, fixed time
and volume state information, the model of pump head and tube size.
E. Date and Time Display: Display the current date and time which you can
change in the system settings. When it displays an alarm clock on the right side,
it means the timer start and stop function is turned on.
F. System Settings Button: Click this button in order to set up other parameters.
G. Flow Calibration Button: Click this button to enter the flow rate calibration
interface.
H. Date & Time Button: Click this button to enter set up current date and time
interface.
I. Fixed Volume Measurement Button: Click this button to enter the fixed
volume measurement interface.
J. Fixed Time and Volume Button: Click this button to enter fixed time and
volume interface.
K. Timer Start and Stop Button: Click this button to enter timer start and stop
interface.
