Fluid FLD3900 Manuale utente
39” LED FHD Television
FLD3900
Instruction Manual
Read all of the instructions before using this TV and keep the
manual in a safe place for future reference.
8007958
2
Important Safety Instructions
• Read these instructions – All the safety and operating instructions should be read before this product is
operated.
• Keep these instructions – The safety and operating instructions should be retained for future reference.
• Heed all warnings – All warnings on the appliance and in the operating instructions should be adhered to.
• Follow all instructions – All operating and use instructions should be followed.
• Do not use this apparatus near water – The appliance should not be used near water or moisture – for
example, in a wet basement or near a swimming pool, and the like.
• Clean only with dry cloth.
• Do not block any ventilation openings. Install in accordance with the manufacture’s instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug has two blades
with one wider than the other. A grounding plug has two blades and a third grounding prong. The wide
blade or the third prong is provided for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at the plugs, convenience
receptacles, and at the point where they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer,
or sold with the apparatus. When a cart or rack is used, use caution when moving
the cart/apparatus combination to avoid injury from tip-over.
• Unplug the apparatus during lightning storms or when unused for long periods of time.
• Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in
any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
• Please keep the unit in a well-ventilated environment.
• WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
The apparatus shall not be exposed to dripping or splashing and that objects filled with liquids, such as
vases, shall not be placed on apparatus.
• WARNING: The wall socket plug is used as disconnect device, the disconnect device shall remain readily
operable.
• WARNING: The batteries shall not be exposed to excessive heat such as sunshine, fire or the like.
• This lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of non-insulated “dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock.
• To reduce the risk of electric shock, do not remove cover (or back) as there are no user-serviceable parts
inside. Refer servicing to qualified personnel.
• The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance instructions in the literature accompanying the appliance.
• This equipment is a Class II or double insulated electrical appliance. It does not require a grounded
connection.
CA UT IO N
RISK OF ELECTRICAL SHOCK
DO NOT OPEN
3
Contents
Important Safety Instructions ............................................. 2
Safety Information ......................................................4
What’s Included ........................................................ 5
Getting Started ....................................................... 6-7
Front/Side View .................................................... 6
Rear View ......................................................... 7
Wall Mounting ...................................................... 7
Connecting to External Devices ........................................... 8
Remote Control Button Functions .......................................9-10
Operating Your Television .............................................11-20
Picture Mode Setup Wizard ..........................................11
Select Your Onscreen Language Preference ............................12
Navigating the Onscreen Display ......................................13
Choosing a TV Channel ..............................................13
Selecting Input Source ..............................................14
Picture Menu Options ...............................................14
Picture Mode .......................................................14
Audio Menu Options ................................................15
Time Menu Options .................................................15
Setup Menu Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Lock Menu Options .................................................17
Channel Menu Options ...............................................18
Parental Menu Options ..................................................19
Troubleshooting ....................................................20-22
FCC .................................................................. 23
Specifications .........................................................23
Warranty .............................................................24
4
Safety Information
To ensure reliable and safe operation of this equipment, please read carefully all the instructions
in this user guide, especially the safety information below.
Electrical safety
• The TV set should only be connected to a main power supply with voltage that matches the
label at the rear of the product.
• To prevent overload, do not share the same power supply socket with too many other
electronic components.
• Do not place any connecting wires where they may be stepped on or tripped over.
• Do not place heavy items on them, which may damage the leads.
• Hold the main plug, not the wires, when removing from a socket.
• During a thunderstorm or when not using the television for long periods, turn off the power
switch on the back of the television.
• Do not allow water or moisture to enter the TV or power adapter. Do NOT use in wet, moist
areas, such as bathrooms, steamy kitchens or near swimming pools.
• Pull the plug out immediately, and seek professional help if the main plug or cable is
damaged, liquid has spilt onto the set, if accidentally exposed to water or moisture, if
anything accidentally penetrates the ventilation slots or if the set does not work normally.
• Do not remove the safety covers. There are no user serviceable parts inside.
Trying to service the unit yourself is dangerous and may invalidate the product’s warranty.
Only qualified personnel should service this apparatus.
• To avoid battery leakage, remove exhausted batteries from the remote control, or when not
using for a long period.
• Do not break open or throw exhausted batteries in a fire.
Physical safety
• Do not block ventilation slots in the back cover. You may place the TV in a cabinet, but
ensure at least 5 cm (2”) clearance all around.
• Do not tap or shake the TV screen, this may damage the internal circuits. Take good care of
the remote control.
• To clean the TV use a soft dry cloth. Do not use solvents or petroleum based fluids.
• Do not install near any heat sources such as radiators, heat registers, stoves or other
apparatus (including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong, the wide blade, or the third prong is provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs.
• Unplug the apparatus during lightning storms or when unused for long periods.
• Refer all servicing to a qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled, or objects have fallen into the apparatus, has been exposed to rain or moisture,
does not operate normally, or has been dropped.
• Please always connect your television to a power outlet with protective ground connection.
5
8007958
ST4 X 16
(ST4 X 16, 4 PCS)
What’s Included
Unit and Accessories
User’s Manual
TV Set
Base Stand
Initial Assembly
AV connection cable
Screws (ST 4 X 16, 4 PCS)
Remote Control with Batteries
39” LED FHD Television
8007958
FLD3900
6
Getting Started
Front/Side View
Button Functions
1. POWER : Turns on/standby the TV set
2. SOURCE : Displays the input source menu
3. MENU : Displays the OSD menu. Press again to exit the menu
4. CH / : Scans through channels
5. VOL +/- : Adjusts the volume
5
7
Getting Started
Rear View
1. AC power input terminal
2. Headphone output
3. SERVICE port
4. HDMI1 / HDMI2 / HDMI3 input
5. VGA input
6. PC audio input
7. AV input
8. Component and audio input terminal
9. Coaxial audio signal output plug
10 . Antenna input (75 Ohm VHF/UHF)
Wall Mounting
The TV is provided with mounting holes for a VESA approved wall mounting bracket (NOT
SUPPLIED). The VESA mounting pattern is 200 x 200. Remove the screws holding the base to
the base bracket and lift the base away (do not remove the base mounting brackets). Mount the
VESA bracket using 4 x M4 x 10 isometric threaded screws (not supplied). Do not use screws
longer than 10 mm; damage will occur to the internal components.
Caution: Your new TV is heavy; please consult with a professional wall mount installer to perform
this installation.
10
SERVICE
8
Connecting to External Devices
Connecting external devices to your LED TV
9
Remote Control Button Functions
Power button
Numeric buttons
Channel setup button
Picture mode button
Sound mode button
Signal source selection button
Channel selection button
CH. LIST button
FREEZE button
UP button
LEFT button
TV setup menu button
V-CHIP button
CC button
EPG button
Mute button
Return channel button
Sleep button
MTS button
Information button
Volume adjust button
Auto button
Aspect button
ENTER button
RIGHT button
DOWN button
Exit OSD menu button
FAV button
ADD/ERASE button
If there is light around the TV, the remote control may fail or work abnormally.
If not using the remote for a long period of time, please remove the batteries.
10
Remote Control Button Functions
POWER: Power on/off button, press once to turn TV on and press again to turn TV off.
P.MODE: Sets the picture mode.
S.MODE: Sets the sound mode.
MTS: Press to select the audio channel.
• Make sure the TV has searched the channels and that there is an Analog Stereo/Dual Sound
Signal shown on the program.
• Press the MTS (Multichannel Television Sound) button to select STEREO and MONO.
SLEEP: Sleep button, sets TV power off time.
0, 1-9: TV channel selection button.
- : Press this button to enter a program number for multiple program channels such as 2-1, etc.
: Previous channel button, return to the previous channel watched.
SOURCE: Signal source selection button (TV/AV/Component/HDMI1/HDMI2/HDMI3/VGA).
MENU: OSD menu button, to enter the TV set up menu.
e/ d : (Up/Down) Up and Down button of OSD menu. To change the OSD menu items.
f / g : (Left/Right) Left and right button of the OSD menu. To select the OSD menu items.
OK: Confirms the selection of the highlighted menu item.
INFO: Press the info button to view the current channel. Press again to exit channel information.
EXIT: To exit operation.
VOL +/-: Volume adjusting button, to increase and decrease the volume.
CH +/- : Channel selection button, to increase or decrease the channel.
MUTE: Mute button, press once to disable the audio and press again to enable the audio.
ASPECT: Select display mode: Wide/Zoom/Cinema/Normal.
ADD/ERASE: Add or delete favourite channel.
FAV: Display favourite of program list.
EPG: Electronic Program Guide Function.
CC: Closed Caption select button OFF, ON or CC ON Mute.
V-CHIP: Parental control set-up.
CH.LIST: Display program list.
FREEZE: Freeze picture for TV.
AUTO: Auto adjust (only for use with VGA source).
