Focus Designs Inc.

SBU

The Electric Self-Balancing Unicycle

OWNER’S MANUAL

3rd Edition, 2012

focusdesigns.com

IMPORTANT:

This manual contains important safety, performance

and service information. Read it before you take the

first ride on your new SBU and keep it for reference.

A SPECIAL NOTE FOR PARENTS:

As a parent or guardian, you are responsible for the

activities and safety of your minor child, and that

includes making sure that the SBU is properly fitted to

the child; that it is in good repair and safe operating

condition; that you and your child have learned and

understand the safe operation of the SBU; and that you

and your child have learned, understand and obey not

only the applicable local motor vehicle, unicycle and

traffic laws, but also the common sense rules of safe

and responsible unicycling. As a parent, you should

read this manual, as well as review its warnings and

the SBU’s functions and operating procedures with

your child, before letting your child ride the SBU.

MANUAL"FOR"THE"SBU"V3!

For"Your"Records:"

Congratulations on the purchase of your new Focus

Designs SBU! This manual is designed to give you the

information you need for the safe operation and

maintenance of your new SBU. Please read it

thoroughly before riding your SBU.

Please take this opportunity to record important

information about your new SBU.

IMPORTANT NOTICE!!!

Please visit

focusdesigns.com/user

We cannot guarantee a warranty

claim unless you do this!

Your Name ________________________

Date of Purchase ___________________

Location of Purchase _______________

Your Location ______________________

MANUAL"FOR"THE"SBU"V3"

Table"of"Contents!

General Warning:...................................................................... 5!

Fit .................................................................................................... 6!

Does your SBU fit you?................................................................6!

Seat Adjustments...........................................................................6!

Safety First.................................................................................. 7!

Mechanical Safety Check ...................................................... 8!

Frame ..................................................................................................9!

Tire.......................................................................................................9!

Tube.................................................................................................. 10!

To replace the tube: .................................................. 10!

Operation.................................................................................. 11!

Pushbutton Switch ..................................................................... 11!

Safety Lock..................................................................................... 12!

Automatic Fall Detection ......................................................... 12!

LED Status Indicator .................................................................. 12!

Normal Operation ..................................................... 12!

Low Battery Mode...................................................... 13!

Depleted Battery Mode .............................................. 13!

Fall Detect Mode ....................................................... 13!

Factory Readout Modes ............................................. 14!

Battery Pack................................................................................... 14!

Battery Protection Mode – AKA Pushback................... 15!

Folding Foot Wedges................................................................. 15!

Battery Charger ........................................................................... 15!

First ride ................................................................................... 16!

Make sure it fits .......................................................................... 16!

Make sure the SBU is in tip top shape .............................. 16!

Be safe ............................................................................................. 16!

About your first ride ................................................................. 16!

Changing / Modifying the SBU, or Adding

Accessories.............................................................................. 19!

MANUAL"FOR"THE"SBU"V3!

Appendix A - Safety ............................................................ 21!

Appendix B - Specifications............................................. 25!

Rigid Construction ..................................................................... 25!

Truly Hands-Free ....................................................................... 25!

Elegant Electronics..................................................................... 25!

Motion-Learning Technology ............................................... 26!

Turn AssistTM ............................................................ 26!

Push BackTM .............................................................. 27!

Smart SenseTM ........................................................... 27!

High-Performance Vehicle ..................................................... 27!

Hill Climbing............................................................. 27!

Top Speed................................................................. 27!

Weight Limit.............................................................. 27!

Range ....................................................................... 27!

Regenerative Braking ................................................ 28!

Charger............................................................................................ 28!

Battery ............................................................................................. 29!

The Human Interface................................................................. 29!

Adjustable Seat Post.................................................. 30!

Dimensions and Travel Specs:.............................................. 30!

Riding Mode.............................................................. 30!

Compact Mode.......................................................... 30!

Storage Mode............................................................ 30!

Appendix C - Warranty ...................................................... 32!

MANUAL"FOR"THE"SBU"V3"

General"Warning:"

Like any sport, unicycling involves risk of injury and

damage. By choosing to ride the SBU, you assume the

responsibility for that risk. You need to understand,

and to practice the rules of safe and responsible riding

and of proper use and maintenance. Proper use and

maintenance of your SBU reduces risk of injury. This

Manual contains many “Warnings” and “Cautions”

concerning the consequences of failure to maintain or

inspect your SBU and of failure to follow safe cycling

practices.

The combination of the safety alert symbol and the

word WARNING indicates a potentially hazardous

situation, which, if not avoided, could result in serious

injury or death.

The combination of the safety alert symbol and the

word CAUTION indicates a potentially hazardous

situation, which, if not avoided, may result in minor or

moderate injury, or is an alert against unsafe practices.

The word CAUTION used without the safety alert

symbol indicates a situation, which, if not avoided,

could result in serious damage to the SBU or the

voiding of your warranty. Many of the Warnings and

Cautions say, “You may lose control and fall.” Because

any fall can result in serious injury or even death, we

do not always repeat the warning of possible injury or

death. Because it is impossible to anticipate every

situation or condition, which can occur while riding,

this Manual makes no representation about the safe

use of the SBU under all conditions. There are risks

MANUAL"FOR"THE"SBU"V3!

associated with the use of any unicycle which cannot

be predicted or avoided, and which are the sole

responsibility of the rider.

Fit"

Does"your"SBU"fit"you?"

Correct fit is an essential element of SBU safety,

performance and comfort - it will result in the correct

fit for your body.

The SBU is designed for riders with

an inseam of at least 26”,

although it is possible for

riders of any height to ride the SBU, it will require

assistance from another person while learning how to

ride the SBU for the first time. The SBU is easy to

adjust to fit your body; there is simply one item that

addresses fit, the seat height.

WARNING: If your SBU does not fit properly, you may

lose control and fall. Adjust the SBU for proper fit,

have someone assist you during the learning to ride

process. We recommend two people on either side of

you for balance support.

Seat"Adjustments"

If you are a beginner, we recommend you set the seat

height at a level that allows you to place both feet flat

on the ground while straddling the SBU’s seat. This is

important when learning to balance left and right on

the SBU. After you have mastered left right balance,

we recommend you raise the seat for a higher level of

riding comfort.

The seat is adjusted using the quick-release clamp

located on the seat post. Make sure to observe the

Minimum Insertion requirements of the seat post. The

MANUAL"FOR"THE"SBU"V3"

seat post should be inserted into the SBU frame AT

LEAST TWO INCHES. Once your seat is at the desired

height, tighten the clamp slightly, and align the seat

with the wheel, making sure they are in line with each

other, and then tighten so that the seat post does not

have movement in any direction. Your SBU may come

with a seat post that is too long. It may need to be

trimmed down with a tube cutter. Consult your local

hardware store to have them cut the tube to length if

this is needed.

WARNING: Always make sure that your seat post does

not extend from the frame beyond the Minimum

Insertion requirements of three inches; the seat post

may break, or separate from the frame, which could

cause you to lose control and fall.

WARNING: After any seat adjustment, be sure that the

seat clamp is properly tightened before riding. A loose

seat clamp can cause damage to the seat post, or can

cause you to lose control and fall. A correctly

tightened seat clamp will allow no seat movement in

any direction. Periodically check to make sure that the

seat clamp is properly tightened.

Safety"First"

Always wear an approved helmet when riding your

SBU. Be sure to attach the chin strap, and follow the

helmet manufacturer’s instructions for fit, use and care

of your helmet.

MANUAL"FOR"THE"SBU"V3!

Also wear other required and recommended safety

equipment such as: elbow pads, kneepads, shin

guards and wrist guards.

See Appendix A for more Safety Information.

WARNING: Many states require specific safety

devices. It is your responsibility to familiarize yourself

with the laws of the state where you ride and to comply

with all applicable laws. This includes properly

equipping yourself and your SBU as the law requires.

Mechanical"Safety"Check"

Routinely check the condition of your SBU before every

ride. Some service and maintenance can and should be

performed by the owner, and requires no special tools

or knowledge beyond what is presented in this

manual. The following are examples of the type of

service you should perform yourself. A qualified

mechanic using the correct tools and procedures

specified by Focus Designs, Inc should perform all

other service, maintenance and repair in a properly

equipped facility.

WARNING: Before performing any work on the SBU

make sure to disengage the power by turning the

safety lock into the “locked” position. This will prevent

the SBU from an accidental power on.

Nuts,"bolts,"wires,"battery,"top"plate,"etc."

Make sure nothing is loose or damaged. Check all

bolts and nuts to make sure they are tight. Check

wiring for damage. With the SBU turned OFF, lift it off

the ground by two or three inches, while holding

bounce the tire on the ground. Anything sound, feel or

MANUAL"FOR"THE"SBU"V3"

look loose? Do a quick visual and tactile inspection of

the whole SBU. Any loose parts or accessories? If so,

secure them. If you’re not sure, ask someone with

experience to check.

Frame"

Check the frame particularly in the area around welded

joints; the seat post and clamp for any deep scratches,

cracks or discoloration. These are signs of stress-

caused fatigue and indicate that a part is at the end of

its useful life and needs to be replaced.

Tire"

Make sure the tire is sufficiently inflated but below the

maximum recommended pressure that is printed on

the sidewall of the tire. The best way to inflate a tire to

the correct pressure is with a bicycle pump, which has

a built-in pressure gauge. Check the tire and look for

any cuts in the tread and sidewall. Check to make sure

the tire bead is seated evenly on the rim. Replace a

damaged tire before riding.

WARNING: Riding the SBU with a flat or under-inflated

tire, will void your warranty.

WARNING: Never inflate a tire beyond the maximum

pressure marked on the tire’s sidewall. Exceeding the

recommended maximum pressure may blow the tire

off the rim, which could cause damage to the SBU and

injury to the rider and bystanders – it will also void

your warranty.

10"

MANUAL"FOR"THE"SBU"V3!

CAUTION: Pencil type automotive tire gauges can be

inaccurate and should not be relied upon for

consistent accurate pressure readings. Instead use a

quality dial gauge.

Tube"

If the tube is damaged or punctured we recommend

replacing the tube, patches should only be used for an

emergency repair and the patched tube should be

replaced as soon as possible.

To#replace#the#tube:#

i. Make sure the SBU is in the “off” position.

ii. Remove the 8 bolts holding the wheel to the

frame.

iii. Carefully move wheel away from the frame by

letting out the slack in the wire being fed

through the frame.

iv. Remove the tire using a bicycle tire remover,

and remove the damaged tube.

v. Place a new tube in the tire; place tire onto the

wheel making sure the tire bead is seated

evenly on the rim.

vi. Inflate the tire to recommended pressure that

is printed on the sidewall of the tire.

vii. Place wheel back onto frame fork, paying

attention to the proper orientation of the

wheel.

viii. Securely fasten the 8 bolts back to the

frame. Spin the wheel to make sure it is secure

and spins freely.

ix. Check to make sure everything is secure, and

you are ready to ride again.

Altri manuali per SBU V3

Indice

Altri manuali Focus Designs Bicicletta

Focus Designs

Focus Designs SBU Manuale utente

Focus Designs

Focus Designs SBU V3 Manuale utente

Manuali Bicicletta popolari di altre marche

RAMBO

RAMBO R1000X2M-FF-BFD Manuale utente

Vermeiren

Vermeiren SAFARI Manuale utente

Velec

Velec A2/36V Manuale utente

Coswheel

Coswheel A-ONE Manuale utente

Betzold

Betzold 97869 Manuale utente

Cervélo

Cervélo S3 2019 Manuale utente

Tenways

Tenways AGO X Manuale utente

Festo

Festo EGSC-BS-KF Manuale elenco delle parti

Gio Electric

Gio Electric H1 Volt Manuale utente

GOGOBEST

GOGOBEST GM30 Manuale utente

DAHON

DAHON CIAO - 2009 Manuale utente

Aprimatic

Aprimatic ONDA 500 Guida rapida

MV Agusta

MV Agusta Lucky Explorer GRAVEL Manuale di istruzioni

Greyp

Greyp G6 Series Manuale utente

Babboe

Babboe Carve-E Manuale utente

Huka

Huka orthros Manuale utente

Xtracycle

Xtracycle Stoker 2021 Manuale utente

APRILIA

APRILIA DORSODURO 750 ABS 2015 Manuale utente
