Owner’s Manual

Blood Glucose Monitoring System

TABLE OF CONTENTS

IMPORTANT SAFETY INSTRUCTIONS 04

READ BEFORE USE 04

INTENDED USE 04

THE APPEARANCE AND KEY FUNCTIONS 05

METER DISPLAY 05

FORA Diamond MINI TEST STRIPS 06

SETTING THE METER AND DELETING 06

THE FOUR MEASURING MODES 09

CHECKING THE SYSTEM WITH CONTROL SOLUTIONS 10

HOW TO PERFORM A CONTROL SOLUTION TEST 10

TESTING YOUR BLOOD 11

VIEWING THE METER MEMORY 13

VIEWING RESULTS 13

VIEWING DAY AVERAGE RESULTS 14

DOWNLOADING RESULTS ONTO A COMPUTER 14

DATA TRANSMISSION VIA CABLE (FOR DM30a) 15

DATA TRANSMISSION VIA BLUETOOTH (FOR DM30b) 15

BATTERY RECHARGE 16

DISPLAY MESSAGES AND PROBLEMSOLVING GUIDE 17

SYMBOL INFORMATION 19

SPECIFICATIONS 20

English

Version 1.0 2012/05

311-4283000-005

IMPORTANT SAFETY INSTRUCTIONS

READ BEFORE USE

Dear owners of FORA Diamond MINI Blood Glucose Monitoring System,

The system consists of three main products: the meter, test strips and

control solutions. These products have been designed, tested, and proven

to work together as a system to produce accurate blood glucose test

results. Only use FORA Diamond MINI test strips and control solutions

with the FORA Diamond MINI Blood Glucose Monitoring System.

INTENDED USE

This system is intended for external use (in vitro diagnostic use) only.

It is used for the quantitative measurement of glucose in samples of

venous whole blood and fresh capillary whole blood taken from the palm,

forearm, upper arm, calf, thigh, or fingers. It is not intended to diagnose

or screen for diabetes mellitus, or to be used on neonates.

Professionals may test with capillary and venous blood sample; home

use is limited to capillary whole blood testing. Use only heparin for

anticoagulation of whole blood.

This system provides you with plasma equivalent results.

The measurement unit used for indicating the concentration of blood or

plasma glucose can either have a weight dimension (mg/dL) or a molarity

(mmol/L). The approximate calculation rule for conversion of mg/dL in

mmol/L is:

mg/dL

mmol/L

Divided by 18

Times 18

= mmol/L

= mg/dL

For example;

1) 120 mg/dL ÷ 18 = 6.6 mmol/L

2) 7.2 mmol/L x 18 = 129 mg/dL

approximately.

APPEARANCE AND KEY FUNCTIONS

OF THE METER

METER DISPLAY

Test Slot Main Button

Charging indicator/

Bluetooth indicator

(for DM30b)

Display Screen

SET Button

Data Port

Battery Cover

NOTE:

The meter will turn off automatically after 180 seconds without any action or you

can press and hold the Main button for 3 seconds to turn off the meter.

Face Low/ High Symbol

Memory Symbol

Indicates a test result

stored in memory.

Blood Drop Symbol

Flashes when meter is ready

for sample application.

Measuring Mode

Gen, AC, PC, QC.

Test Area

Test results are displayed here.

Error Message

Appears with error messages.

Low Battery Symbol

Appears when the

battery is low.

Alarm Symbol

Time Display

Month / Day / Hour /

Minute

Measurement Unit

FORA Diamond MINI TEST STRIPS

SETTING THE METER AND DELETING

THE MEMORY

Your system measures the amount of sugar (glucose) in whole

blood. Blood is applied to the absorbent hole on the test strip and is

automatically drawn into the reaction cell where the reaction takes place.

Start with the meter off (no test strip inserted). Press SET.

Absorbent Hole

Apply a drop of blood here.

The blood will be automatically absorbed.

Confirmation Window

This is where you confirm if enough

blood has been applied to the absorbent

hole in the strip

Test Strip Handle

Hold this part to insert the test strip into the slot.

Contact Bars

Insert this end of the test strip into the meter.

Push it in firmly until it will go no further.

1. Setting the date

With the year flashing, press Main button

until the correct year appears. Press SET.

With the month flashing, press Main

button until the correct month appears.

Press SET.

With the day flashing, press Main button

until the correct day appears. Press SET.

2. Setting the time format

Press Main button to select the desired

time format --- 12h or 24h. Press SET.

3. Setting the time

With the hour flashing, press Main button

until the correct hour appears. Press SET.

With the minute flashing, press Main

button until the correct minute appears.

Press SET.

4. Deleting the memory

With “dEL”and a flashing “”on the

display, press Main button and select “no”

to keep the results in memory then press

SET to skip.

To delete all the results, press Main

button and “yes”and “”are displayed

on the meter, press SET to delete the

memory.

5. Setting the reminder alarm

You may set up any or all of the reminder

alarms (1-4). The meter displays “On”or

“OFF”and “”, press Main button to

turn on or turn off to set the first reminder

alarm.

Press Main button to select “On”, then

press SET to set the hour. When the hour

is flashing, press Main button to add

an hour. Press SET to confirm and go to

minutes, press Main button to add one

minute. Hold Main button longer to add

faster. Press SET to confirm and go to the

next alarm setting.

With the "no" symbol flashing on the

display, press SET to skip the pairing.

If you wish to enter the pairing mode,

press Main button once and the meter

will display "yes". Then press SET to

confirm and the meter will show "CLr" The

meter will then automatically turn off and

the Bluetooth indicator will start blinking,

which means the meter is in the process

of pairing with a Bluetooth receiver.

NOTE:

This step is recommended when the user needs to pair this meter to a Bluetooth

receiver for the first time, or when user needs to pair this meter to another new

Bluetooth receiver.

If you do not want to set an alarm, press SET to skip this step.

If you want to turn off an alarm, find the alarm number by pressing SET in

the setting mode, press Main button to change from “ON”to “OFF”.

6. Enter the Bluetooth pairing (for

DM30b only)

You can switch between each mode by:

The meter provides you with four modes for measuring, General, AC, PC

and QC.

1. Start with the meter switched off. Insert a test strip to turn on the

meter. The screen will display a “”.

THE FOUR MEASURING MODES

MODES

General

(displays as “Gen”)

USE WHEN

any time of day without regard to time since last

meal

no food intake for at least 8 hours

2 hours after a meal

testing with the control solution

2. Press Main button to switch between General, AC, PC and QC mode.

CHECKING THE SYSTEM WITH

CONTROL SOLUTIONS

Our control solutions contain a known amount of glucose that reacts with

test strips. By comparing the result of your control solution test with the

expected range printed on the test strip vial label, you can check that the

meter and the test strips are working together as a system and that you

are performing the test correctly. It is very important that you perform this

simple check routinely to make sure you get accurate results.
