Force1 F200W SHADOW Manuale utente
USER MANUAL
Visit us online at force1rc.com for product information, replacement parts, and ight tutorials.
0.6 Miles
FOR MORE INFORMATION
ATTENTION:
PLEASE WATCH THIS
FLIGHT INSTRUCTION
VIDEO BEFORE
FLYING YOUR DRONE.
https://youtu.be/tk3qzsUwoWs
FORCE1 RC
2
CONTENTS
Welcome & General Safety Precautions·······················3
LI-PO Battery Care ·······················································4
Drone Battery Charging ···············································5
Contents & Drone Overview ········································6
Transmitter Overview····················································7
Transmitter Battery Installation·····································8
Channel Selection & Signal Connection·······················9
Throttle Mode Selection·············································10
Drone Assembly ·························································11
Calibration··································································13
Preflight Checklist·······················································14
Basic Flight Controls···················································15
Functions ····································································16
Force1-F200W App Overview ···································19
Indicator Lights Overview ··········································21
Spare Parts ·································································23
Troubleshooting ························································24
F200W Shadow User Manual
3
WELCOME!
SAFETY PRECAUTIONS
Welcome to the Force 1 RC Team, and thank you for your Force1 drone purchase. Please read this manual
carefully before drone operation.
(1) This drone is not a toy! It’s a pro-level drone suitable for experienced RC drone users aged 14 years and
older. You accept all liability for operation.
(2) This drone does not require FAA registration or permitting, but FAA rules still apply. Please download
the B4UFLY mobile app for the most up-to-date zoning info, and heed all local government ordinances.
(3) The ying eld must be legally approved by your local government.
Any questions? We’d love to hear from you! Please contact us at support@force1rc.com any time and we’ll
be happy to help.
*Please use only original Force1 parts and accessories.
*Please keep the packaging and this user manual for future reference.
This drone is suitable for experienced RC drone operators aged 14 years and older. It contains small
parts, and should be kept out of reach of small children.
Please follow these safety procedures:
(1) Flight Zone
This drone does not require FAA registration or permitting, but FAA rules still apply. Please download
the B4UFLY mobile app for the most up-to-date zoning info, and heed all local government
ordinances.
(2) Avoid Moisture
Humidity and water can damage your drone, which in turn may cause accidents.
(3) Fly Safely
Please operate your drone as your skill level allows. User fatigue, impairment and improper operation
can cause accidents.
(4) Avoid Moving Parts & Hot Motors
Do not touch propellers, motors or other moving parts while your drone is on.
(5) Avoid Heat
Keep your drone away from heat and prolonged exposure to direct sunlight to avoid damage.
FORCE1 RC
4
LI-PO BATTERY CARE
Avoid Overheating
Your batteries will sometimes be warm/hot to the touch after use. This is normal, but beware that battery
components will fail if not allowed to cool down between uses. Also, do not leave batteries exposed to
direct sunlight.
Store Properly
Store batteries at room temperature, between 5C°/40°F and 27°C/80°F.
Use Carefully
• Leave time between charging and using the battery
• To extend the lifetime of the battery time your ights to leave about 20% power remaining in the
batteries (rather than completely draining them)
• If the battery is pushed beyond its limits, the battery could get hot and the performance will drop
• When using the battery for a long time, the battery will increase in temperature. If it is sealed, the air
inside will inate rapidly causing further heating
Charging
• DO NOT overcharge the battery; never charge batteries unattended, and stop charging as soon as your
batteries indicate they are charged
• DO NOT attempt to charge batteries that appear damaged in any way (cracking, swelling, discoloration, etc.)
• If you feel a battery isn’t charging properly, try using another charger if possible. If you nd your battery
or charger is defective, please visit force1rc.com for a replacement, or email us at support@force1rc.com
• To inspect a battery, remove it from the device and examine the battery, battery pins and contacts. If
you notice damage, please visit force1rc.com for a replacement, or email us at support@force1rc.com
• Check your battery and connections after every crash
• Please use genuine factory parts and replacements from force1rc.com
WARNING:
DO NOT LEAVE BATTERY
CHARGING UNSUPERVISED
F200W Shadow User Manual
5
DRONE BATTERY CHARGING
LI-PO BATTERY DISPOSAL & RECYCLING
Do not put lithium-polymer batteries in household trash. Please contact your
local waste management agency or LI-PO battery recycling center for more info.
FORCE1 RC
6
PHONE CLIP
BOX CONTENTS
DRONE WITH CAMERA TRANSMITTER 7.4V 1800MAH LIPO BATTERY (2)
PROPELLERS (4) BALANCE CHARGER
DRONE TOOLS
DRONE OVERVIEW
FRONT
B PROPELLER
COUNTERCLOCKWISE
A PROPELLER
CLOCKWISE
A PROPELLER
CLOCKWISE
B PROPELLER
COUNTERCLOCKWISE
REAR
RIGHTLEFT
F200W Shadow User Manual
7
TRANSMITTER OVERVIEW
LCD SCREEN
PHOTO (SHORT-PRESS)/
VIDEO (LONG-PRESS)*
ONE-KEY TAKE OFF/
ONE-KEY LANDING
ENTER/EXIT RETURN TO HOME
POWER SWITCH POWER INDICATOR
THROTTLE/RUDDER STICK (DEFAULT)
UNLOCK (SHORT-PRESS)
LOCK (LONG-PRESS)
DIRECTION CONTROL STICK (DEFAULT)
HEADLESS MODE SWITCHGESTURE/GPS MODE SWITCH
*APPLICABLE WHEN A MEMORY CARD IS INSERTED. IF THERE IS NO MEMORY CARD, PHOTOS AND VIDEOS CAN BE TAKEN AND SAVED
WITH THE F200W APP.
SATELLITE
NUMBER
GPS MODE
(7+ SATELLITES)
SIGNAL
STRENGTH
ALTITUDE FROM
HOME POINT
1-KEY RETURN
VIDEO
PHOTOHEADLESS
MODE
DISTANCE FROM
HOME POINT
DRONE
BATTERY LEVEL
TRANSMITTER
BATTERY LEVEL
TRANSMITTER
THROTTLE MODE
FORCE1 RC
8
TRANSMITTER BATTERY INSTALLATION
Open the battery cover and insert 4 AA batteries as shown below.
• The transmitter needs 4 AA batteries to work
• Insert batteries in correct polarity (+) and (-)
• Don’t mix old and new batteries
• Don’t mix alkaline, standard (carbon-zinc) and rechargeable (nickel-cadmium) batteries
• Remove rechargeable batteries before charging
• Only charge batteries under adult supervision
• Remove spent batteries from the transmitter
• Regularly inspect the charging cable, cord, plug, enclose and other parts; if you notice damage,
please visit Force1rc.com for a replacement, or email us at support@force1rc.com
CAUTION:
F200W Shadow User Manual
9
TRANSMITTER SIGNAL CONNECTION
TRANSMITTER CHANNEL SELECTION
Keep the transmitter steady during this process, or it may result in signal connection failure.
CAUTION:
Press and hold the top-left red button and then power on the transmitter (Fig. 2). It will beep twice, and the
indicator light will flash as the transmitter establishes a GPS satellite signal. Flashing will stop when a signal
is found.
Your transmitter (remote controller) uses 5G Wi-Fi and works on channels 36 (5180 MHz) and 149 (5745
MHz), both of which are available in the United States. The factory default setting is channel 36.
Channel Selection
• Press and hold the bottom-right corner button until the transmitter beeps twice (Fig. 1)
• This indicates a switch between channels 36 and 149
FIGURE 2
NOTE
• You should see no difference in operation, as both channels work in the U.S.
• If you are outside the U.S., contact support@force1rc.com for more detailed frequency info
FIGURE 1
