Fostex VM04 Manuale utente

VM04

Service Manual

Model

4chDigitalMixerwithDSPEffects

FOSTEX CORPORATION 3-2-35 Musashino, Akishima, Tokyo, Japan 196-0021

FOSTEX CORPORATION OF AMERICA 15431 Blackburn Ave., Norwalk, CA 90650, U.S.A. © PRINTED IN JAPAN MAR 1999 8288778000

VM04VM04

SAFETY INSTRUCTIONS

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

TO PREVENT ELECTRIC SHOCK, MATCH

WIDE BLADE OF PLUG TO WIDE SLOT,

FULLY INSERT.

POUR ÉVITER LES CHOCS ÉLECTRIQUES,

INTRODUIRE LA LAME LA PLUS LARGE DE

LA FICHE DANS LA BORNE CORRE-

SPONDANTE DE LA PRISE ET POUSSER

JUSQU' AU FOND.

CAUTION:

ATTENTION:

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and mainte-

nance (servicing) instructions in the literature

accompanying the appliance.

The lightening flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated

“dangerous voltage” within the product's en-

closure that may be of sufficient magnitude to

constitute a risk of electric shock to persons.

“WARNING”

“TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO

NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.”

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

1. Read instructions - All the safety and operating instructions

should be read before the appliance is operated.

2. Retain instructions - The safety and operating instructions

should be retained for future reference.

3. Heed warnings - All warnings on the appliance and in the

operating instructions should be adhered to.

4. Follow instructions - All operating and use instructions

should be followed.

5. Water and Moisture - The appliance should not be used near

water - for example, near a bathtub, washbowl, kitchen sink,

laundry tub, in a wet basement, or near a swimming pool,

and the like.

6. Carts and Stands - The appliance should be used only with a

cart or stand that is recommended by the manufacturer.

An appliance and cart combination should be moved with

care. Quick stops, excessive force, and uneven surfaces

may cause the appliance and cart combination to overturn.

7. Wall or Ceiling Mounting - The appliance should be mounted

to a wall or ceiling only as recommended by the manufac-

turer.

8. Ventilation - The appliance should be situated so that its lo-

cation or position does not interfere with its proper ventila-

tion. For example, the appliance should not be situated on a

bed, sofa, rug, or similar surface that may block the ventila-

tion openings; or, placed in a built-in installation, such as a

bookcase or cabinet that may impede the flow of air through

the ventilation openings.

9. Heat - The appliance should be situated away from heat

sources such as radiators, heat registers, stoves, or other ap-

pliances (including amplifiers) that produce heat.

10. Power Sources - The appliance should be connected to a

power supply only of the type described in the operating in-

structions or as marked on the appliance.

11. Grounding or Polarization - The precautions that should be

taken so that the grounding or polarization means of an appli-

ance is not defeated.

12. Power Cord Protection - Power supply cords should be routed

so that they are not likely to be walked on or pinched by items

placed upon or against them, paying particular attention to

cords at plugs, convenience receptacles, and the point where

they exit from the appliance.

13. Cleaning - The appliance should be cleaned only as recom-

mended by the manufacturer.

14. Nonuse Periods - The power cord of the appliance should be

unplugged from the outlet when left unused for a long period

of time.

15. Object and Liquid Entry - Care should be taken so that objects

do not fall and liquids are not spilled into the enclosure

through openings.

16. Damage requiring Service - The appliance should be serviced

by qualified service personnel when:

A. The power supply cord or the plug has been damaged;

B. Objects have fallen, or liquid has been spilled into the

appliance; or

C. The appliance has been exposed to rain; or

D. The appliance does not appear to operate normally or

exhibits a marked changed in performance; or

E. The appliance has been dropped, or the enclosure dam-

aged.

17 Servicing - The user should not attempt to service the appli-

ance beyond that described in the operating instructions. All

other servicing should be referred to qualified service personnel.

CH4

LO HI

PRE/POST

FADER PAN

EFFECT

SEND

10kHz100Hz

INPUT 4

(-10dBV)

METER

CH3

LO HI

PRE/POST

FADER PAN

EFFECT

SEND

10kHz100Hz

INPUT 3

(-10dBV)

METER

CH2

LO HI

PRE/POST

FADER PAN

EFFECT

SEND

10kHz100Hz

INPUT 2

(-10dBV~-50dBV)

METER

CH1

LO HI

PRE/POST

FADER PAN

EFFECT

SEND

10kHz100Hz

INPUT 1

(-10dBV~-50dBV)

METER

EFFECT

MASTER

METER

MASTER FADER

PHONES

OUTPUT

(-10dBV)

S/P DIF OUT

LREFFECT

TRIM

A/D

D/A

EFFECT

8. BLOCK DIAGRAMS

VM04VM04

322

FADER PCB

TABLE OF CONTENTS

NOTES

* Parts List and circuit diagrams are given in this manual to assist the service technician in maintaining the

Model VM04

* The following accessories are supplied with VM04 as the standard accessories.

Owner's manual : 8288440000

AC adaptor AD-9B : 8270818003 (for USA/CND)

: 8270818006 (for EUR)

: 8270818007 (for UK)

: 8270818010 (for JPN)

* Following is the packing material for the Model VM04.

PACK, SIDE, L, VM04 : 8228446000

PACK, SIDE, R, VM04 : 8228447000

CARTON, INNER, VM04 : 8228722000

CARTON, OUTER, VM04 : 8228901000

1. SPECIFICATIONS............................................................................ 4

2. CONTROLS, INDICATORS AND CONNECTORS.................... 5

3. SERVICE MODE ............................................................................. 6

REPLACING THE BATTERY .............................................................................7

4. EXPLODED VIEW .......................................................................... 8

5. PARTS LIST..................................................................................... 9

6. PCB PATTERN DRAWING......................................................... 11

7. CIRCUIT DIAGRAMS .................................................................. 16

8. BLOCK DIAGRAMS..................................................................... 23

CAUTION

Parts marked with this sign are safety critical components. They must always be replaced with

identical components. Refer to the Fostex Parts List and ensure exact replacement.

J401

FPC-17P

AD+5

DGND

ADGND

VR0

VR1

VR2

VR3

VR4

JOG0

JOG1

DGND ADGND

AD+5

R401

10KB

AD+5

ADGND

R402

10KB

AD+5

ADGND

R403

10KB

AD+5

ADGND

R404

10KB

AD+5

ADGND

R405

10KB

AD+5

ADGND

U401

EC12E

DGND

To Main J11

VM04VM04

214

DISPLAY PCB

SEG22

SEG21

SEG20

SEG19

SEG18

SEG17

SEG16

SEG15

SEG14

SEG13

SEG12

SEG11

SEG10

SEG9

SEG8

SEG7

SEG6

SEG5

SEG4

SEG3

SEG2

SEG1

GND

OSCI

OSCO

CL1

CL2

VCC

R/W

DB0

DB1

DB2 41

DB3 42

DB4 43

DB5 44

DB6 45

DB7 46

COM1 47

COM2 48

COM3 49

COM4 50

COM5 51

COM6 52

COM7 53

COM8 54

COM9 55

COM10 56

COM11 57

COM12 58

COM13 59

COM14 60

COM15 61

COM16 62

SEG40 63

SEG39 64

SEG38 65

SEG37 66

SEG36 67

SEG35 68

SEG34 69

SEG33 70

SEG32 71

SEG31 72

SEG30 73

SEG29 74

SEG28 75

SEG27 76

SEG26 77

SEG25 78

SEG24 79

SEG23 80

U301

HD44780U

SEG1 1

SEG2 2

SEG3 3

SEG4 4

SEG5 5

SEG6 6

SEG7 7

SEG8 8

SEG9 9

SEG10 10

SEG11 11

SEG12 12

SEG13 13

SEG14 14

SEG15 15

SEG16 16

SEG17 17

SEG18 18

SEG19 19

SEG20 20

SEG21 21

SEG22 22

SEG23 23

SEG24 24

SEG25 25

SEG26 26

SEG27 27

SEG28 28

SEG29 29

SEG30 30

SEG31 31

SEG32 32

SEG33 33

SEG34 34

SEG35 35

SEG36 36

SEG37 37

SEG38 38

SEG39 39

SEG40 40

SEG5

SEG4

SEG3

SEG2

SEG1

COM9

COM10

COM11

COM12

COM13

COM14

COM15

COM16

SEG6

SEG7

SEG8

SEG9

SEG10

SEG16

SEG37

SEG38

SEG39

SEG40

SEG13

SEG18

SEG23

SEG28

SEG33

COM9

COM10

COM11

COM12

COM13

COM7

COM6

COM5

COM4

COM3

COM2

COM1

U302

LCD_FD4

L301

LAMP

L302

LAMP

D+5

C302

0.01

DGND

LCD_D0

LCD_D1

LCD_D2

LCD_D3

LCD_D4

LCD_D5

LCD_D6

LCD_D7

R301

220K

SEG1

SEG2

SEG3

SEG4

SEG5

SEG6

SEG7

SEG8

SEG9

SEG10

SEG11

SEG12

SEG13

SEG14

SEG15

SEG16

SEG17

SEG18

SEG19

SEG20

SEG21

SEG22

SEG23

SEG24

SEG25

SEG26

SEG27

SEG28

SEG29

SEG30

SEG31

SEG32

SEG33

SEG34

SEG35

SEG36

SEG37

SEG38

SEG39

SEG40

COM1

COM2

COM3

COM4

COM5

COM6

COM7

COM8

COM9

COM10

COM11

COM12

COM13

COM14

COM15

COM16

R/W

DGND

R302

R303

R304

R305

R306

R307

10K

D+5

D-12

R311

5KB

J301

FPC-17P

DGND

D+5

D-12

R/W

LCD_D0

LCD_D1

LCD_D2

LCD_D3

LCD_D4

LCD_D5

LCD_D6

LCD_D7>

D-12DGND

D+5

C301

0.1

DGND

SEG1

SEG2

SEG3

SEG4

SEG5

SEG6

SEG7

SEG8

SEG9

SEG10

SEG11

SEG12

SEG13

SEG14

SEG15

SEG16

SEG17

SEG18

SEG19

SEG20

SEG21

SEG22

SEG23

SEG24

SEG25

SEG26

SEG27

SEG28

SEG29

SEG30

SEG31

SEG32

SEG33

SEG34

SEG35

SEG36

SEG37

SEG38

SEG39

SEG40

SEG1

SEG2

SEG3

SEG4

SEG5

SEG6

SEG7

SEG8

SEG9

SEG10

SEG16

SEG13

SEG37

SEG38

SEG39

SEG40

SEG18

SEG23

SEG28

SEG33

COM1

COM2

COM3

COM4

COM5

COM6

COM7

COM9

COM10

COM11

COM12

COM13

COM14

COM15

COM16

COM9

COM10

COM11

COM12

COM13

D+5D+5

DGND DGND

SEG[1..40]

COM[1. .16]

To Main J12

DGND DGND

S301

TACT

S302

TACT

S303

TACT

S304

TACT

S305

TACT

S306

TACT

S307

TACT

S308

TACT

S309

TACT

S310

TACT

S311

TACT

S312

TACT

D351

LED D352

LED D353

LED D354

LED D355

LED D356

NON

D357

LED D358

LED

KEY0

KEY1

KEY2

KEY3

KEY4

KEY5

DIG0

DIG1

LED_A0

LED_A1

LED_K0

LED_K1

LED_K2

LED_K3

LED_K4

LED_K5

J302

FPC-17P

D301A

DIODE D301B

DIODE D302A

DIODE D302B

DIODE D303A

DIODE D303B

DIODE

D304A

DIODE D305A

DIODE D306A

DIODE D304B

DIODE D305B

DIODE D306B

DIODE

D359

NON D360

LED D361

LED D362

NON

R321

NON

R322

NON

R323

NON

R324

NON

R325

NON

R326

NON

D+5 D+5 D+5 D+5 D+5 D+5

LED_A0

LED_A1

DIG0

DIG1

LED_K0

LED_K1

LED_K2

LED_K3

LED_K4

LED_K5

KEY0

KEY1

KEY2

KEY3

KEY4

KEY5

KEY[0..5]

LED_K[0..5]

LED_A[0..1] DIG[0..1]

FADERADJ CH1 CH2 CH3 CH4 VIEW

RECALL EFF TY PE EXIT STORE EFF PARAM ENT ER

FADERADJ CH1 CH2 CH3 CH4

RECALL EFF TY PE STORE EFF PA RAM

To Mai n J13

DEFINITION (Specification Unit : 0 dBV = 1 Vrms)

NORMAL FADER POSITION

Master fader ........................................................................................................... 80 position (Master Fader display)

Input fader........................................................................................................... 80 position (Channel Fader display)

Effect Send.................................................................................................................................................. 00 position

MIXER SECTION

INPUT 1, 2

Input Level .......................................................................................................................................-50dBV ~ -10dBV

Input Impedance ..................................................................................................................................... 20kΩor more

Connector ................................................................................................................... Ø6 mm Phone Jack/Unbalanced

INPUT 3, 4

Input Level ........................................................................................................................................................-10dBV

Input Impedance ..................................................................................................................................... 20kΩor more

Connector ................................................................................................................... Ø6 mm Phone Jack/Unbalanced

OUTPUT (L, R)

Output Level .....................................................................................................................................................-10dBV

Load Impedance......................................................................................................................................10kΩor more

Connector ................................................................................................................... Ø6 mm Phone Jack/Unbalanced

PHONES OUT

Output Level .........................................................................................................................20 mW MAX (16Ω load)

Load Impedance........................................................................................................................................16Ωor more

Connector............................................................................................................................ Ø6 mm Stereo Phone Jack

EQUALIZER

HI (Shelving Type) ...............................................................................................±18dB or more (-10dBV / 10 kHz)

LO (Shelving Type) ..............................................................................................±18dB or more (-10dBV / 100 Hz)

FREQUENCY RESPONSE

Input (-10dBV) →Stereo Out (-10dBV)............................................................................. +1, -2dB (20Hz ~ 20kHz)

Input (-50dBV) →Stereo Out (-10dBV)............................................................................. +1, -3dB (20Hz ~ 20kHz)

Input (-10dBV) →Phones Out (20mW/16Ω) ..................................................................... +1, -3dB (20Hz ~ 20kHz)

S/N (with DAT envelope filter)

Input (+2dBV) →Stereo Out (+2dBV) ....................................................................................86dB or more (IHF-A)

Input (-38dBV) →Stereo Out (+2dBV)................................................................................... 66dB or more (IHF-A)

Input ∑4 (+2dBV) →Stereo Out (+2dBV) ..............................................................................81dB or more (IHF-A)

Phones Out Phones Out Residual Noise ...................................................................................66dB or more (IHF-A)

DISTORTION (with DAT envelope filter)

Input (+2dBV) →Stereo Out (0dBV) ..........................................................................0.1% or less (100Hz ~ 10kHz)

Input (-40dBV) →Stereo Out (0dBV) .........................................................................0.1% or less (100Hz ~ 10kHz)

Input (0dBV) →Phones Out (20mW/16Ω) ................................................................................. 1.0% or less (1kHz)

CROSSTALK ...................................................................................................................................60dB or more (1kHz)

SHOCK NOISE ..................................................................................................................................... -30dBVp-p or less

LEVEL INDICATION

Type ............................................................................................................................................ LCD Bargraph Meter

Number of Indicated Levels ...................................................... 11 dots (-48, -30, -24, -18, -12, -9, -6, -3, -1, 0, OL)

Reference Level (-10dBV) Indication ................................................................................................................ -12dB

DIGITAL SECTION

SAMPLING FREQUENCY .................................................................................................................................. 44.1kHz

QUANTIZATION ........................................................................................................................................... 16 bit linear

A/D CONVERTER ......................................................20bit, 64 times Over Sampling Enhanced Dual Bit, Delta-Sigma

D/A CONVERTER .................................................................................... 20bit 128-time, Over Sampling, Delta-Sigma

S/P DIF OUT

Format ......................................................................................................................................... IEC 60958 (S/P DIF)

Connector........................................................................................................................................................... Optical

GENERAL

DC IN AD-9B, DC9V, 650 mA (the Center Positive)

DIMENSIONS................................................................................................................ 254 (W) ×186 (D) ×50 (H) mm

WEIGHT .................................................................................................................................................... Approx. 1.1 kg

POWER SUPPLY

USA/CND ............................................................................................................................................ 120VAC, 60Hz

EUR/UK.......................................................................................................................................... 230VAC, 50/60Hz

JPN 100VAC, 50/60Hz

1. SPECIFICATIONS

* Specifications and appearance are subject to change without notice for product improvement.

VM04VM04

520

MAIN PCB : ANALOG OUT

C111

10/16

R111

100K

U111A

NJM2115M

R113

27K

C113

10P

C116

0.01

A+5

AGND

R112

100K

C112

NON R115

AGND

VBIAS3

AOUTL

L111

BEAD

C114

10/16

R114

100K

AGND

1 3

U112

DTC314TK

AGND

4J6

YKB21-5074

AGND

C211

10/16

R211

100K

U111B

NJM2115M

R213

27K

C213

10P

R212

100K

C212

NON R215

AGND

VBIAS3

L211

BEAD

C214

10/16

R214

100K

AGND

1 3

U212

DTC314TK

AGND

4J7

YKB21-5074

AGND

AOUTR

C121

10/16

R121

1 3

U121

DTC314TK

AGND

C122

10/16

R122

100K

U122A

NJM3414AD

R124

4.7K

C124

10P

A+5

AGND

R123

470

C123

NON

C127

100/10

VBIAS4 AGND

R126

C125

220/10

R125

10K

AGND

C221

10/16

R221

1 3

U221

DTC314TK

AGND

C222

10/16

R222

100K

U122B

NJM3414AD

R224

4.7K

C224

10P

R223

470

C223

NON

VBIAS4 AGND

R226

C225

220/10

R225

10K

AGND

L121

BEAD 2

4J8

YKB21-5074

L221

BEAD

AGND

(-10dBV)

MASTERL

MASTERR

PHONE

MUTE

(DIP-8PIN)

R131A

RK09K12A

R131B

RK09K12A

C226

100/10

C126

100/10

C215

100/10

C115

100/10

R227

R127

R216

R116

AGND

2 3

U12

DTA114EK

R94

10K R95

100K

DGND D-12

D+5

10K

100/10

D11

DAN202K

DGND

2. CONTROLS, INDICATORS AND CONNECTORS

INPUT

-10-50

TRIMTRIM

-10-50

32 14

OUTPUT

MIN MAX

PHONESFOOT SW

OUT

S/P DIF

DC IN

RESET

123 45 6 7 8 9

1. DC INLET connector [the Center Positive]

2. S/P DIF optical output connector [Optical]

3. FOOT SW (unlatched) jack [Ø6 mm Phone]

4. Headphone jack [Ø6 mm Stereo Phone]

5. Headphone volume control knob

VIEW

CHANNEL EDIT

MASTER4321

MAX

MIN

SCENE No

1234LR1234MIN

MAX

EFFHILOPAN

VIEWLEVEL

FADER ADJUST

ENTEREXIT

DATA

STORERECALL SCENE

PARAMETERTYPE EFFECT

SETUP

MAX

MIN

MAX

MIN

MAX

MIN

CH MASTER

48 L

12 14 15 16

242522 23

10. Contrast control knob

11. FADER ADJUST key

12. LCD display

13. View status indicator

14. SCENE Number display

15. SCENE RECALL key

16. SCENE STORE key

17. EFFECT PARAMETER key

6. Stereo OUTPUT L/R jacks [Ø6 mm Phone]

7. RESET switch

8. INPUT jacks [Ø6 mm Phone]

9. TRIM knobs

18. EFFECT TYPE key

19. EXIT key

20. ENTER key

21. DATA encoder

22. CHANNEL EDIT key

23. Input faders

24. MASTER fader

25. VIEW key

< REAR PANEL >

< TOP PANEL >

VM04VM04

196

MAIN PCB : ANALOG IN

YKB21-5074

R101

18K

R102

22K

C101

10/16

R103

100K

U101A

NJM2115M

R104

C103

100P

C106

0.01

A+5

AGND

R106

130

R107

100K

R110

20KC

AGNDAGND

C102

NON

U101B

NJM2115M

R108

10K

R109 10K

C105

NON

VBIAS1

AIN1+

AIN1-

YKB21-5074

R201

18K

R202

22K

C201

10/16

R203

100K

U201A

NJM2115M

R204

C203

100P

C206

0.01

A+5

AGND

R206

130

R207

100K

R210

20KC

AGNDAGND

C202

NON

U201B

NJM2115M

R208

10K

R209 10K

C205

NON

VBIAS2

AIN2+

AIN2-

YKB21-5074

R301

27K

R302

47K

C301

10/16

R303

100K

U301A

NJM2115M

R304

C303

NON

C306

0.01

A+5

AGND

AGNDR305

NON

AGNDAGND

C302

NON

U301B

NJM2115M

R306

10K

R307 10K

C305

NON

AGND

VBIAS3

AIN3+

AIN3-

YKB21-5074

R401

27K

R402

47K

C401

10/16

R403

100K

U401A

NJM2115M

R404

C403

NON

C406

0.01

A+5

AGND

AGNDR405

NON

AGNDAGND

C402

NON

U401B

NJM2115M

R406

10K

R407 10K

C405

NON

AGND

VBIAS3

AIN4+

AIN4-

L101

BEAD

L201

BEAD

L401

BEAD

L301

BEAD

INPUT1

INPUT2

INPUT3

INPUT4

(-10dBV to -50dBV)

(-10dBV)

C107

220/10

C207

220/10

C407

10/16

C307

10/16

R308

R408

3-1 Software Version Check

While holding down the EXIT key and ENTER key together, press the EFFECT TYPE key.

The LCD Display will show the SoftwareVersion of the VM04 for a second, and then return to

the Normal Mix mode.

MASTERCH

3-4 Fader Check

While holding down the EXIT key and ENTER key together, press the FADERADJUST key.

3-3 Display Check

While holding down the EXIT key and ENTER key together, press the VIEW key.

· All the LEDs and LCD segments are supposed to start blinking. Check if they are correctly

blinking or not.

· Press the ENTER key would change the blinking pattern.

· If the key other than the ENTER key is pressed, the VM04 returns to Normal Mix mode display.

3-2 Battery Check

While holding down the EXIT key and ENTER key together, press the EFFECT PARAMETER key.

· The LCD Display will show the voltage of the memory backup battery inside theVM04 for

a second, and then return to the Normal Mix mode.

· If the voltage falls below 2.2V, the message “BattEmpty” will appear when powering ON.

· If the message “BattEmpty” is displayed, please replace the battery with the new one. For

exchanging procedure, please refer to the page 7.

MASTER SCENE NO.

MAX

2ch1ch 4ch DATA encoder3ch

3. SERVICE MODE

MASTERCH

3-5 Test Scene RECALL

While holding down the EXIT key and ENTER key together, press the SCENE RECALL key

· There are five Test Scenes (Test 1 ~Test 5).

· Pressing the ENTER key would step forward the Test Scene.

· Pressing the key other than the ENTER key would return the VM04 to the Normal Mix mode display.

· Each Test Scene is set up as shown in the table below.

Eff Send

Level PAN Level PAN Level PAN Level PAN 1~4 ch

TEST 1 80 L 80 R 80 L 80 R 80 00 POST -

TEST 2 80 L 80 R 00 C 00 C 80 00 POST -

TEST 3 00 C 00 C 80 L 80 R 80 00 POST -

TEST480L80L80L80L 80 00 POST -

TEST500C00C00C00C 80 80 PREDelay

EffectMaster Pre/Post

CH 1 CH 2 CH 3 CH 4

Blink

TEST 1 Line Check 1~4 Output Level / Frequency Response

TEST2 Line Check 1, 2 Output Level(Trim) / Frequency Response / Distortion / S/N(INPUT : Short)

TEST 3 Line Check 3, 4 Output Level / Frequency Response / Distortion / S/N(INPUT : Short)

TEST 4 Line Check 1~4 S/N(∑4, INPUT : Short)

TEST 5 Effect Check 1~4 Only the effect signal (1 Time Delay) is output.

· Confirm that each channel parameter value correctly appears on the

Character Display.

· Confirm that the SCENE NO. Display value would vary when rotat-

ing the DATA encoder.

· If any key is pressed, theVM04 returns to Normal Mix mode display.

CAUTION: While in the condition that the Test Scene is recalled, please do not turn off the power. Otherwise, correct Scene No. cannot be recalled.

VM04VM04

718

MAIN PCB : DSP (EFFECT)

TSTI1

OPCL

/PDAD

/PDDA

/PD

/RST

TSTIO1

TSTIO2

TSTIO3

DVB

SDIN2

SDAD

SDOUT2

SDDA

SDDA2

SDOUT3

SDOUT1

SDIN1

SMODE

BCLK

LRCK

CLKO

DVDD

DVSS

XTI

XTO

TSTI2

/CS

/WRQ

DVSS

DVDD

SCLK

WRDY

DRDY

/CASRF

/RASCE

/WE

A16

A15

A14

A13

A12

A11

A10

DVSS

DVDD

A8 51

A7 52

A6 53

A5 54

A4 55

A3 56

A2 57

A1 58

A0 59

/OE 60

IO0 61

IO1 62

IO2 63

IO3 64

IO4 65

IO5 66

IO6 67

IO7 68

DVSS 69

DVDD 70

DZFSET 71

DVSS 72

DVDD 73

DVB 74

DVB 75

DZF2 76

DZF1 77

NC 78

AVB 79

AOUTR2 80

AOUTL2 81

NC 82

AOUTR1 83

AOUTL1 84

VRD AL 85

AVSS 86

AVDD 87

VRD AH 88

NC 89

AINR- 90

AINR+ 91

AINL- 92

AINL+ 93

VCO M 94

VRA DL 95

AVSS 96

AVDD 97

VRA DH 98

AVB 99

NC 100

AK7712A

I/O0 21

I/O1 22

I/O2 23

I/O3 25

I/O4 26

I/O5 27

I/O6 28

I/O7 29

/OE 32

VSS

24 /CE1 30

CE2 6

/WE 5

VCC

A10

A11

A12

A13

A14

A15

A16

TC551001CFT-70L

A10

A11

A12

A13

A14

A15

A16

C76

10/16 C77

0.01

D+5

DGND

D+5

DGND

16.9344MHZ

C67

22P C68

22P

DGND DGND

A10

A11

A12

A13

A14

A15

A16

/WE

AIN3+

AIN3-

AIN4+

AIN4-

AOUTL

AOUTR

C66

0.01

C65

0.01

C64

0.01

C63

0.01

C62

10/16

D+5

DGND

C57

0.01

C56

0.01

C55

0.01

C51

10/16 AGND

A+5

C61

0.1

C60

10/16

C59

0.1

C58

0.1

AIN4-

AIN4+

AIN3-

AIN3+ AOUTL

AOUTR

/PD_DSP

/RST_DSP

/PD_ADDA

/PD_DSP

/RST_DSP

/CS_DSP_EFF

/WRQ_DSP

WRDY_DSP

DRDY_DSP_EFF R77 100

SCK

[ANA]

[CPU]

R71

C54

0.01

C53

0.01

C52

0.01

R74 100

R76 330

R75 100

R82 330

R81 330

R80 330

R79 330 C69

1500P

C70

1500P

BLOCK 1

UBDA 2

LRS 3

LRCK 4

BCK 5

DATA 6

VLDY 7

EMPH 8

COPY 9

FS1 10

FS2 11

CKS 12

XI 13

VSS 14

DO1

15 DO2

16 M1

17 M2

18 IS1

19 IS2

20 CTG1

21 CTG2

22 CTG3

23 FR32

24 LBIT

25 CKA1

26 CKA2

27 VDD

28 U9

TC9271F

DGND

D+5

DGND

C81

0.01

U10

GPIF32T

C82

10/16

C83

0.01

DGND

D+5

R91

100

1110 U5E

74VHC14

1312 U5F

74VHC14

R73 330

/PD_ADDA

AIN34_DATA

FXS_DATA

ST_DATA

R72 330

MSCK

LRCK

BCK

MSCK

LRCK

BCK

AIN34_DATA

ST_DATA

FXS_DATA

DG_OUT_DATA

[DSP]

CLOCK MASTER

MASTER

3-6 Memory Clear

While holding down the EXIT key and ENTER key together, press the SCENE STORE key

· Pressing the ENTER key would clear the memory and the message “ClearMem!”

appear. All the setup will be initialized.

· Pressing the key other than ENTER returns to the Normal Mix mode display (The

Scene No. 00 is displayed.) and the memory will not be initialized.

· Pressing the RESET SW would also clear the memory and the message “ClearMem!”

appear.

MASTER

Gain Table

The value appears in the LCD display corresponds

to the gain in dB as shown below.

REPLACING THE BATTERY

If the voltage of the inside memory backup battery falls below 2.2V,

the message “BattEmpty” will appear when powering ON.

CAUTION

· Replacing the battery with the new one would basically

initialize the backup data.

· In order to retain the backup data, please replace the

battery while powering on.

B001

Parts No.:8239120000

BATTERY, 3V, CR2032

Value

L10

R10

PAN

Left

0.0

-0.1

-0.25

-0.4

-0.7

-1.0

-1.4

-1.8

-2.2

-2.6

-3.0

-4.2

-5.5

-7.1

-9.0

-11.3

-14.1

-17.6

-23.5

-32.0

- ∞

Right

- ∞

-32.0

-23.5

-17.6

-14.1

-11.3

-9.0

-7.1

-5.5

-4.2

-3.0

-2.6

-2.2

-1.8

-1.4

-1.0

-0.7

-0.4

-0.25

-0.1

0.0

Gain (dB)

Value

Gain (dB)

- ∞

-72.0

-55.0

-42.5

-35.0

-28.75

-23.0

-18.0

-15.5

-13.0

-10.5

-8.5

-7.0

-5.5

-4.0

-2.5

-1.25

+1.5

+3.0

+4.67

+6.0

INPUT Fader

MASTER Fader

EFFECT Send

VM04VM04

178

4. EXPLODED VIEW

18 17

BTT 3x8 BZn

B 3x8

CZn

BTT 3x8 BZn

BTT 3x8

BZn

BTT 3x8

BZn

BTT 3x8

BZn

13 14

MAIN PCB : DSP (CHANNEL)

TSTI1

OPCL

/PDAD

/PDDA

/PD

/RST

TSTIO1

TSTIO2

TSTIO3

DVB

SDIN2

SDAD

SDOUT2

SDDA

SDDA2

SDOUT3

SDOUT1

SDIN1

SMODE

BCLK

LRCK

CLKO

DVDD

DVSS

XTI

XTO

TSTI2

/CS

/WRQ

DVSS

DVDD

SCLK

WRDY

DRDY

/CASRF

/RASCE

/WE

A16

A15

A14

A13

A12

A11

A10

DVSS

DVDD

A8 51

A7 52

A6 53

A5 54

A4 55

A3 56

A2 57

A1 58

A0 59

/OE 60

IO0 61

IO1 62

IO2 63

IO3 64

IO4 65

IO5 66

IO6 67

IO7 68

DVSS 69

DVDD 70

DZFSET 71

DVSS 72

DVDD 73

DVB 74

DVB 75

DZF2 76

DZF1 77

NC 78

AVB 79

AOUTR2 80

AOUTL2 81

NC 82

AOUTR1 83

AOUTL1 84

VRDAL 85

AVSS 86

AVDD 87

VRDAH 88

NC 89

AINR- 90

AINR+ 91

AINL- 92

AINL+ 93

VCOM 94

VRADL 95

AVSS 96

AVDD 97

VRADH 98

AVB 99

NC 100

AK7712A

AIN1+

AIN1-

AIN2+

AIN2-

C46

0.01

C45

0.01

C44

0.01

C43

0.01

C42

10/16

D+5

DGND

C37

0.01

C36

0.01

C35

0.01 AGND

A+5

C41

0.1

C40

10/16

C39

0.1

C38

0.1

AIN2-

AIN2+

AIN1-

AIN1+

/PD_ADDA

/PD_DSP

/RST_DSP

/PD_ADDA

/PD_DSP

/RST_DSP

/CS_DSP_CH

/WRQ_DSP

WRDY_DSP

DRDY_DSP_CH

SCK

[ANA]

[CPU]

R52

C34

0.01

C33

0.01

C32

0.01

C31

10/16

R58 330

R57 330

R56 330

R55 330 C47

1500P

C48

1500P

R53 330

CLOCK SLAVE

R54 330

MSCK

LRCK

BCK

AIN34_DATA

FXS_DATA

ST_DATA

FXS_DATA

AIN34_DATA

BCK

LRCK

MSCK

[DSP]

R51

100

VM04VM04

916

7. CIRCUIT DIAGRAMS 5. PARTS LIST RESISTORs

Ref.No. Part No. Description

R033 8230500331 ST, CARBON, 1/10W, 330, 5%

R034~039 8230500103 ST, CARBON, 1/10W, 10K, 5%

R041~046 8230500102 ST, CARBON, 1/10W, 1K, 5%

R047, 048 8230500102 ST, CARBON, 1/10W, 1K, 5%

R049, 050 8230500103 ST, CARBON, 1/10W, 10K, 5%

R051 8230500101 ST, CARBON, 1/10W, 100, 5%

R052 8230500100 ST, CARBON, 1/10W, 10, 5%

R053, 054 8230500331 ST, CARBON, 1/10W, 330, 5%

R055~058 8230500331 ST, CARBON, 1/10W, 330, 5%

R071 8230500100 ST, CARBON, 1/10W, 10, 5%

R072, 073 8230500331 ST, CARBON, 1/10W, 330, 5%

R074, 075 8230500101 ST, CARBON, 1/10W, 100, 5%

R076 8230500331 ST, CARBON, 1/10W, 330, 5%

R077 8230500101 ST, CARBON, 1/10W, 100, 5%

R079~082 8230500331 ST, CARBON, 1/10W, 330, 5%

R090 8230500103 ST, CARBON, 1/10W, 10K, 5%

R091 8230500101 ST, CARBON, 1/10W, 100, 5%

R092 8230500103 ST, CARBON, 1/10W, 10K, 5%

R093 8230500222 ST, CARBON, 1/10W, 2.2K, 5%

R094 8230500103 ST, CARBON, 1/10W, 10K, 5%

R095 8230500104 ST, CARBON, 1/10W, 100K, 5%

R096 8230500103 ST, CARBON, 1/10W, 10K, 5%

R101, 201 8230500183 ST, CARBON, 1/10W, 18K, 5%

R102, 202 8230500223 ST, CARBON, 1/10W, 22K, 5%

R103, 203 8230500104 ST, CARBON, 1/10W, 100K, 5%

R104, 204 8230500105 ST, CARBON, 1/10W, 1M, 5%

R106, 206 8230500131 ST, CARBON, 1/10W, 130, 5%

R107, 207 8230500104 ST, CARBON, 1/10W, 100K, 5%

R108, 208 8230500103 ST, CARBON, 1/10W, 10K, 5%

R109, 209 8230500103 ST, CARBON, 1/10W, 10K, 5%

R110, 210 8240154010 POT, PL, RT9, 20KC, RK09K111

R111, 211 8230500104 ST, CARBON, 1/10W, 100K, 5%

R112, 212 8230500104 ST, CARBON, 1/10W, 100K, 5%

R113, 213 8230500273 ST, CARBON, 1/10W, 27K, 5%

R114, 214 8230500104 ST, CARBON, 1/10W, 100K, 5%

R115, 215 8230500102 ST, CARBON, 1/10W, 1K, 5%

R116, 216 8230500102 ST, CARBON, 1/10W, 1K, 5%

R121, 221 8230500102 ST, CARBON, 1/10W, 1K, 5%

R122, 222 8230500104 ST, CARBON, 1/10W, 100K, 5%

R123, 223 8230500471 ST, CARBON, 1/10W, 470, 5%

R124, 224 8230500472 ST, CARBON, 1/10W, 4.7K, 5%

R125, 225 8230500103 ST, CARBON, 1/10W, 10K, 5%

R126, 226 8230500100 ST, CARBON, 1/10W, 10, 5%

R127, 227 8230500102 ST, CARBON, 1/10W, 1K, 5%

R131 8240168003 POT, PI, RT 9, 50KAA, RK09K12A

R301, 401 8230500273 ST, CARBON, 1/10W, 27K, 5%

R302, 402 8230500473 ST, CARBON, 1/10W, 47K, 5%

R303, 403 8230500104 ST, CARBON, 1/10W, 100K, 5%

R304, 404 8230500000 ST, CARBON, 1/10W, 0, 5%

R306, 406 8230500103 ST, CARBON, 1/10W, 10K, 5%

R307, 407 8230500103 ST, CARBON, 1/10W, 10K, 5%

R308, 408 8230500102 ST, CARBON, 1/10W, 1K, 5%

CAPACITORs

ALU = Electrolytic

CER = Ceramic type

Ref.No. Part No. Description

C001 8232143477 VT, ALU, 16V, 470µF, 20%

C002 8232142107 VT, ALU, 10V, 100µF, 20%

C003, 004 8233504103 ST, CER, 25V, 0.01µF, 10%

C005 8232142107 VT, ALU, 10V, 100µF, 20%

C006 8233504103 ST, CER, 25V, 0.01µF, 10%

C007 8232142107 VT, ALU, 10V, 100µF, 20%

C008 8232142107 VT, ALU, 10V, 100µF, 20%

C009 8232143107 VT, ALU, 16V, 100µF, 20%

C010 8233500122 ST, CER, 50V, 0.0012µF, 10%

C011 8232143107 VT, ALU, 16V, 100µF, 20%

C015 8233502104 ST, CER, 50V, 0.1µF, +80

C016 8233502104 ST, CER, 50V, 0.1µF, +80

C018 8232143106 VT, ALU, 16V, 10µF, 20%

C019, 020 8233500330 SAP, ST, CER, 50V, 33pF, 5%

C021, 022 8233504103 ST, CER, 25V, 0.01µF, 10%

C023 8233504103 ST, CER, 25V, 0.01µF, 10%

C024 8232143106 VT, ALU, 16V, 10µF, 20%

C025 8233500101 ST, CER, 50V, 100pF, 5%

EXPLODED VIEW

No. Part No. Description

1 8212653000 WINDOW, LCD, VM04

2 8226239001 KNOB, FADER, N4.5

3 8212652100 PANEL, TOP, VM04

4 8226238000 KNOB, JOG, FD-4

5 8274167000 PCB ASSY, FADER, VM04

6 8276839615 CABLE, FLAT, FFC, 17P, L150

7 8274166000 PCB ASSY, DISPLAY, VM04

8 8226246001 BUTTON, 7X13, LED

9 8226246002 BUTTON, 7X13, N4.5

10 8216695000 SHEET, LED, VM04

11 8221266000 SHIELD, MAIN, VM04

12 8216694000 SHIELD, EMI, VM04

13 8274165000 PCB ASSY, MAIN, VM04

14 8239120000 BATTERY, 3V, CR2032

15 8216699000 SHEET, BATTERY, VM04

16 8221265100 PANEL, BOTTOM, VM04

17 8260561000 Foot, Assy

18 8270818003 AC adaptor,AD-9B, USA/CND

8270818006 AC adaptor,AD-9B, EUR

8270818007 AC adaptor, AD-9B, UK

8270818010 AC adaptor, AD-9B, JPN

8274165000 PCBASSY,MAIN,VM04

ICs

Ref.No. Part No. Description

U001 8236570101 IC, ST, DG, DRIVER, DTC114EK

U003 8236541300 IC, ST,AN, DC-DC, NJM2360AM

U004 8236085201 IC, QFP, DG, CPU, VM04

U005 8236545014 IC, ST, TSSOP, 74VHC14

U006, 007 8236084900 IC, QFP, DG, DSP, AK7712A

U008 8236084600 IC, TSOP, SRAM, TC551001CFT-70L

U009 8236504900 IC, ST, DG, DIGITAL OUT, TC9271F

U010 8245317000 CONN, OPT, TOTX178

U011 8236570101 IC, ST, DG, DRIVER, DTC114EK

U012 8236570401 IC, ST, DG, DRIVER, DTA114EK

U013, 014 8236540301 IC, ST, REGULATOR, NJM78M05DLA

U101~401 8236505011 IC, ST,AN, OPAMP, NJM2115M(TEI)

U111 8236505011 IC, ST,AN, OPAMP, NJM2115M(TEI)

U112, 212 8236570201 IC, ST, DG, DRIVER, DTC314TK

U121, 221 8236570201 IC, ST, DG, DRIVER, DTC314TK

U122 8236037500 IC, DIP, AN, NJM3414AD

TRANSISTOR

Ref.No. Part No. Description

Q001, 002 8234100802 TR, VT, PNP, 2SA1150Y

DIODEs

Ref.No. Part No. Description

D002~004 8234019612 D, VT, DSK10C-ET1

D005 8234019612 D, VT, DSK10C-ET1

D006, 007 8234502800 D, ST, DAN202K

D008 8234502800 D, ST, DAN202K

D009 8234502100 D, ST, SCHOTTKY, SB05-05CP

D010 8234502800 D, ST, DAN202K

D011 8234502800 D, ST, DAN202K

RESISTORs

Ref.No. Part No. Description

R001 8230500103 ST, CARBON, 1/10W, 10K, 5%

R002 8230500104 ST, CARBON, 1/10W, 100K, 5%

R003 8230500109 ST, CARBON, 1/10W, 1, 5%

R004 8230500102 ST, CARBON, 1/10W, 1K, 5%

R005 8230500822 ST, CARBON, 1/10W, 8.2K, 5%

R006 8230500103 ST, CARBON, 1/10W, 10K, 5%

R012 8230500102 ST, CARBON, 1/10W, 1K, 5%

R013 8230500103 ST, CARBON, 1/10W, 10K, 5%

R015, 016 8230500473 ST, CARBON, 1/10W, 47K, 5%

R017 8230500104 ST, CARBON, 1/10W, 100K, 5%

R018~023 8230500750 ST, CARBON, 1/10W, 75, 5%

R024, 025 8230500102 ST, CARBON, 1/10W, 1K, 5%

R026~031 8230500101 ST, CARBON, 1/10W, 100, 5%

R032 8230500103 ST, CARBON, 1/10W, 10K, 5%

MAIN PCB : CPU

C15

0.1

DGND

DTC114EK

P76

P77

P00

P01

P02

P03

P04

P05

P06

P07

P10//INT0

P11/INT1

P12/INT2/TC1

P13//DVO

P14//PPG

P15/TC2

P16

P17

P20//INT5//STOP

TEST

P21/XTIN

P22/XTOUT

/RESET

XIN

XOUT

VSS

P30

P31

P32

P33

P34

P35

P36 33

P37 34

P40 35

P41 36

P42//SCK1 37

P43/SI1 38

P44/SO1 39

P45//SCK2 40

P46/SI2 41

P47/SO2 42

P50/INT3/TC3 43

P51/INT4/TC4 44

P52//PWM//PDO 45

P53 46

P54 47

VASS 48

VAREF 49

P60/AIN0 50

P61/AIN1 51

P62/AIN2 52

P63/AIN3 53

P64/AIN4 54

P65/AIN5 55

P66/AIN6 56

P67/AIN7 57

VDD 58

P70 59

P71 60

P72 61

P73 62

P74 63

P75 64

TMP87CM40AF

VR0

VR1

VR2

VR3

VR4

C19 33P

C20 33P

8MHZ

DGND

D+5B

KEY0

KEY1

KEY2

KEY3

KEY4

KEY5

J11

FPC-17P

J12

FPC-17P

/STOP

C18

10/16

C16

0.1

ADGND

AD+5

LCD_ E

LCD_ R/ W

LCD_ RS

VR[0 ..4 ]

R15

47K

R16

47K

C21

0.01

C22

0.01

DGND

CS 1

ES 2

GND

INV 5

V+

CD 8

NJM2360

8.2K

100/10

C11

100/16

C10

0.0012UF

DSK10C

68UH

D-12

+12V

1 2

U5A

74VHC14

5 6

U5C

74VHC14

9 8

U5D

74VHC14

VCC

GND

U5G

74VHC14

C23

0.01

D+5B

DGND

R41

R42

1K C92

100/10

C91

0.01

A+5

AGND

VBIAS1

R43

R44

1K C94

100/10

C93

0.01

A+5

AGND

VBIAS2

R45

R46

1K C96

100/10

C95

0.01

A+5

AGND

VBIAS3

BATT_VOL

R32

10K R33

330 R34

10K R35

10K R36

10K R37

10K R38

10K

D+5

JOG_0

JOG_1

WRDY_DSP

DRDY_DSP_CH

DRDY_DSP_EFF

/WRQ_DSP

/RST_DSP

/CS_DSP_CH

/CS_DSP_EFF

/PD_DSP

/PD_ADDA

MUTE

LED0

LED1

LED2

LED3

LED4

LED5

DIG0

DIG1

VR0

VR1

VR2

VR3

VR4

JOG0

JOG1

DGND

AD+5

ADGND

KEY0

KEY1

KEY2

KEY3

KEY4

KEY5

DIG0

DIG1

LED_K0

LED_K1

LED_K2

LED_K3

LED_K4

LED_K5

LED_A0

LED_A1

J13

FPC-17P

DGND

LCD_ D0

LCD_ D1

LCD_ D2

LCD_ D3

LCD_ D4

LCD_ D5

LCD_ D6

LCD_ D7

LCD_ E

LCD_ R/ W

LCD_ RS

D+5

DGND

D-12

AD+5

ADGNDDGND

DGND

DGNDD-12

D+5

DIG[0.. 1]

LED_A[0 ..1 ]

LED_K[0 ..5 ]

R18

75 R19

75 R20

75 R21

75 R22

75 R23

LED_K0

LED_K1

LED_K2

LED_K3

LED_K4

LED_K5

2SA1050

R25

R24

D+5

DIG0

DIG1

LED_A0

LED_A1

R17

100K

/PD_DSP

/PD_ADDA

/RST_DSP

/CS_DSP_CH

/WRQ_DSP

WRDY_DSP

DRDY_DSP_CH AIN2+

AIN2-

AIN1+

AIN1-

SCK

ST_DATA

FXS_DATA

AIN34_DATA

MSC K

BCK

LRCK

DSP(CHANNEL)

DSP_CH.SCH

/PD_DSP

/PD_ADDA

/RST_DSP

/CS_DSP_CH

/WRQ_DSP

WRDY_DSP

DRDY_DSP_CH AIN2+

AIN2-

AIN1+

AIN1-

SCK

ST_DATA

FXS_DATA

AIN34_DATA

MSC K

BCK

LRCK

AIN1+

AIN1-

AIN2+

AIN2-

AIN3+

AIN3-

AIN4+

AIN4-

ANALOG IN

ANA_IN.SCH

AIN1+

AIN1-

AIN2+

AIN2-

AIN3+

AIN3-

AIN4+

AIN4-

AIN1+

AIN1-

AIN2+

AIN2-

AIN3+

AIN3-

AIN4+

AIN4-

AOUTL

AOUTR AOUTL

AOUTR

MUTE

ANALOG OUT

ANA_OUT.SCH

AOUTL

AOUTR

MUTE

SCK

/PD_DSP

/PD_ADDA

/RST_DSP

/CS_DSP_EFF

/WRQ_DSP

WRDY_DSP

DRDY_DSP_EFF

AIN4+

AIN4-

AIN3+

AIN3-

AOUTL

AOUTR

SCK

ST_DATA

FXS_DATA

AIN34_DATA

MSC K

BCK

LRCK

DSP(EFFECT)

DSP_EFF.SCH

/PD_DSP

/PD_ADDA

/RST_DSP

/CS_DSP_EFF

/WRQ_DSP

WRDY_DSP

DRDY_DSP_EFF

AIN4+

AIN4-

AIN3+

AIN3-

AOUTL

AOUTR

SCK

ST_DATA

FXS_DATA

AIN34_DATA

MSC K

BCK

LRCK

R31 100

R30 100

R27 100

R26 100

R29

100

R28 100

SCK

/CS_DSP_CH

/CS_DSP_EFF

/RST_DSP

/WRQ_DSP

SCK

/PD_ADDA

/PD_DSP

WRDY_DSP

/RST_DSP

/WRQ_DSP

SCK

/PD_ADDA

/PD_DSP

WRDY_DSP

/RST_DSP

/WRQ_DSP

ST_DATA

FXS_DATA

AIN34_DATA

MSCK

BCK

LRCK

SCK

/WRQ_DSP

/RST_DSP

/CS_DSP_EFF

/CS_DSP_CH

/PD_DSP

SCK

/PD_ADDA

R39

10K

DGND

TOFADERJ401

TO LCD J 301

TOKEY J302

DGND

LCD_ D0

LCD_ D1

LCD_ D2

LCD_ D3

LCD_ D4

LCD_ D5

LCD_ D6

LCD_ D7

J10

YKF21-5074

DAN202K

BEAD R12

DGND

R13

10K

D+5

FOOTSW

R49

10K

R50

10K

D+5

R47

R48

1K C98

100/10

C97

0.01

A+5

AGND

VBIAS4

DGND

3 1

D10

DAN202K-1

R92

6.8K

R93

2.2K DGND

R96

10K

D+5

100K

DGND

D+5B

0.01

3 4

U5B

74VHC14

DAN202K

U11

DTC114EK

DGND

S001

SKHVLH

YKB31-0014

DSK10C

CR2032

470/16 C2

100/10

D+5B

0.01 C4

0.01

22UH

100/10

100/10 R1

10K

BATT_VOL

(To CPU)

+12V

DSK10C D9

SB05-05CP

D+5

AD+5A+5

AGND ADGNDGND

DGND

U13

78M05DLA

C26

0.01 C27

0.01

U14

78M05DLA

C28

0.01 C29

0.01

3 1

DSC10C

C24

10/16

C99

100p R99

10K

D+5B

VM04VM04

1510

CAPACITORs

ALU = Electrolytic

CER = Ceramic type

Ref.No. Part No. Description

C026~029 8233504103 ST, CER, 25V, 0.01µF, 10%

C031 8232143106 VT, ALU, 16V, 10µF, 20%

C032~037 8233504103 ST, CER, 25V, 0.01µF, 10%

C038, 039 8233502104 ST, CER, 50V, 0.1µF, +80

C040 8232143106 VT, ALU, 16V, 10µF, 20%

C041 8233502104 ST, CER, 50V, 0.1µF, +80

C042 8232143106 VT, ALU, 16V, 10µF, 20%

C043~046 8233504103 ST, CER, 25V, 0.01µF, 10%

C047, 048 8233500152 ST, CER, 50V, 0.0015µF, 5%

C051 8232143106 VT, ALU, 16V, 10µF, 20%

C052~057 8233504103 ST, CER, 25V, 0.01µF, 10%

C058, 059 8233502104 ST, CER, 50V, 0.1µF, +80

C060 8232143106 VT, ALU, 16V, 10µF, 20%

C061 8233502104 ST, CER, 50V, 0.1µF, +80

C062 8232143106 VT, ALU, 16V, 10µF, 20%

C063~066 8233504103 ST, CER, 25V, 0.01µF, 10%

C067, 068 8233500220 ST, CER, 50V, 22pF, 5%

C069, 070 8233500152 ST, CER, 50V, 0.0015µF, 5%

C076 8232143106 VT, ALU, 16V, 10µF, 20%

C077 8233504103 ST, CER, 25V, 0.01µF, 10%

C081 8233504103 ST, CER, 25V, 0.01µF, 10%

C082 8232143106 VT, ALU, 16V, 10µF, 20%

C083 8233504103 ST, CER, 25V, 0.01µF, 10%

C091 8233504103 ST, CER, 25V, 0.01µF, 10%

C092 8232142107 VT, ALU, 10V, 100µF, 20%

C093 8233504103 ST, CER, 25V, 0.01µF, 10%

C094 8232142107 VT, ALU, 10V, 100µF, 20%

C095 8233504103 ST, CER, 25V, 0.01µF, 10%

C096 8232142107 VT, ALU, 10V, 100µF, 20%

C097 8233504103 ST, CER, 25V, 0.01µF, 10%

C098 8232142107 VT, ALU, 10V, 100µF, 20%

C101, 201 8232143106 VT, ALU, 16V, 10µF, 20%

C103, 203 8233500101 ST, CER, 50V, 100pF, 5%

C106, 206 8233504103 ST, CER, 25V, 0.01µF, 10%

C107, 207 8232142227 VT, ALU, 10V, 220µF, 20%

C111, 211 8232143106 VT, ALU, 16V, 10µF, 20%

C113, 213 8233500100 ST, CER, 50V, 10PF, 5%

C114, 214 8232143106 VT, ALU, 16V, 10µF, 20%

C115, 215 8232142107 VT, ALU, 10V, 100µF, 20%

C116 8233504103 ST, CER, 25V, 0.01µF, 10%

C121, 221 8232143106 VT, ALU, 16V, 10µF, 20%

C122, 222 8232143106 VT, ALU, 16V, 10µF, 20%

C124, 224 8233500100 ST, CER, 50V, 10pF, 5%

C125, 225 8232142227 VT, ALU, 10V, 220µF, 20%

C126, 226 8232142107 VT, ALU, 10V, 100µF, 20%

C127 8232142107 VT, ALU, 10V, 100µF, 20%

C301, 401 8232143106 VT, ALU, 16V, 10µF, 20%

C306, 406 8233504103 ST, CER, 25V, 0.01µF, 10%

C307, 407 8232143106 VT, ALU, 16V, 10µF, 20%

MISCELLANEOUS

Ref.No. Part No. Description

B001 8239121000 HOLDER, BATTERY, BCR20H4

E801 8239120000 BATTERY, 3V, CR2032

J001 8245544000 CONN, DC INLET,YKB31-0014

J002~005 8245339004 CONN, JACK, PHONE,YKB21-5074

J006, 007 8245339004 CONN, JACK, PHONE,YKB21-5074

J008 8245339004 CONN, JACK, PHONE,YKB21-5074

J010 8245339004 CONN, JACK, PHONE,YKB21-5074

J011 8245272017 CONN, PI, JACK, FPC 17P

J012 8245272017 CONN, PI, JACK, FPC 17P

J013 8245272017 CONN, PI, JACK, FPC 17P

L002 8242196223 COIL, PVT, 22µH, 5%, LF5.0S

L003 8242214031 COIL, PVT, 68µH, 5%, ELES

L004 8242501121 FILTER, EMI, 120, 25%, MMZ2012S

L101~401 8242501121 FILTER, EMI, 120, 25%, MMZ2012S

L111, 211 8242501121 FILTER, EMI, 120, 25%, MMZ2012S

L121, 221 8242501121 FILTER, EMI, 120, 25%, MMZ2012S

S001 8253469000 SW, PLT, TACT, SKHVLH

X001 8256134003 RESONATOR, PF, CER, 8.00MHZ

X002 8256170004 RESONATOR, ST, XTL, 16.9344MHZ

Y1501 8245340000 NUT, PHONEJACK

8251972201 Plain PCB, MAIN, VM04

8274165000 PCB ASSY, DISPLAY, VM04

ICs

Ref.No. Part No. Description

U301 8236083600 IC, QFP, DG, LCD DRIVER, HD44780

U302 8256176000 MODULE, DISPLAY, LCD, FD-4

DIODEs

Ref.No. Part No. Description

D301~306 8234502800 D, ST, DAN202K

D351 8234504001 OPT, VT, LED, RED, LT3D31W

D352 8234504003 OPT, VT, LED, YLW, LT3H31W

D353 8234504003 OPT, VT, LED, YLW, LT3H31W

D354 8234504003 OPT, VT, LED, YLW, LT3H31W

D355 8234504003 OPT, VT, LED, YLW, LT3H31W

D357 8234504004 OPT, VT, LED, GRN, LT3E31W

D358 8234504003 OPT, VT, LED, YLW, LT3H31W

D360 8234504001 OPT, VT, LED, RED, LT3D31W

D361 8234504003 OPT, VT, LED, YLW, LT3H31W

RESISTORs

Ref.No. Part No. Description

R301 8230500224 ST, CARBON, 1/10W, 220K, 5%

R302~306 8230500102 ST, CARBON, 1/10W, 1K, 5%

R307 8230500752 ST, CARBON, 1/10W, 7.5K, 5%

R311 8240151004 POT, PI, RT9, 5KB, L20, RK09K113

R321~326 8230500103 ST, CARBON, 1/10W, 10K, 5%

CAPACITORs

CER = Ceramic type

Ref.No. Part No. Description

C301 8233502104 ST, CER, 50V, 0.1µF, +80

C302 8233504103 ST, CER, 25V, 0.01µF, 10%

MISCELLANEOUS

Ref.No. Part No. Description

J301, 302 8245272117 CONN, PL, JACK, FPC, 17P

L301, 302 8239116000 LAMP, 5V, 75MA

S301~312 8253135002 SW, PT, TACT, SOR-112HS

Y301 8212611000 PLATE, REFLECT, LCD, FD-4

8251972102 Plain PCB, DISPLAY, VM04

8274167000 PCB ASSY, FADER, VM04

Ref.No. PartNo. Description

U401 8253466000 SW, PI, ENCODER, EC12E

RESISTOR

Ref.No. PartNo. Description

R401~405 8240274005 POT, PI, SL30, 10KB, RS30H111

MISCELLANEOUS

Ref.No. PartNo. Description

J401 8245272117 CONN, PL, JACK, FPC, 17P

8251972003 Plain PCB, FADER, VM04

U401

J401

117

R405

R404

R403

R402

R401

U401

J401

R405

R404

R403

R402

R401

17 1

8251972 003

FADER, VM04

FADER PCB : PARTS SIDE

FADER PCB : FOIL SIDE

Altri manuali per VM04

Indice

Manuali Mixer musicale popolari di altre marche

Neve

Neve 8816 Manuale utente

Mackie

Mackie Onyx Analogue Mixer Manuale utente

Behringer

Behringer EUROPOWER PMP518M Manuale utente

Peavey

Peavey S-32 Sanctuary Series Manuale utente

Rane

Rane MP 4 Manuale utente

True

True T9 Touchscreen Console Manuale utente

Studiomaster

Studiomaster Air Pro 24 Manuale utente

Pioneer

Pioneer SVM 1000 - Audio/Video Mixer Manuale utente

Roland

Roland M-160 Manuale utente

Yamaha

Yamaha MR1642 Manuale utente

Ecler

Ecler MAC40v Manuale utente

Pioneer

Pioneer DJM 909 - Battle Mixer W/Effects Manuale utente

Veeder-Root

Veeder-Root TLS-350 Series Manuale utente

Alto

Alto APM80.QUAD Manuale utente

Omnitronic

Omnitronic PM-211 Manuale utente

SoundCraft

SoundCraft B400 Manuale utente

Roland

Roland SoundCanvas SC-8820 Manuale utente

CARVIN

CARVIN RX 1200 Manuale utente
