Frico AR3200 Manuale utente
AR3200
.... 19
SE .... 24
GB
Original instructions
.... 28
FR .... 38
DE
.... 44
ES
.... 33
NO
.... 49
IT .... 54
NL .... 59
PL .... 64
RU
AR3200
2
Introduktionssidorna består huvudsakligen av bilder. För översättning av de
engelska texter som används, se respektive språksidor.
SE
The introduction pages consist mainly of pictures. For translation of the
English texts used, see the corresponding language pages.
GB
Introduksjonssidene består hovedsakelig av bilder. For oversettelse av de
engelske tekstene, se de respektive språksidene
NO
Les pages de présentation contiennent principalement des images. Consulter
la page correspondant à la langue souhaitée.
FR
Die Einleitungsseiten bestehen hauptsächlich aus Bildern. Für die Übersetzung
der verwendetenTexte in englischer Sprache, siehe die entsprechenden
Sprachseiten.
DE
Las páginas introductorias contienen básicamente imágenes. Consulte la
traducción de los textos en inglés que las acompañan en las páginas del
idioma correspondiente.
ES
De inleidende pagina's bevatten hoofdzakelijk afbeeldingen. Voor een vertaling
van de gebruikte Engelse teksten, zie de pagina's van de resp. taal.
NL
Le pagine introduttive contengono prevalentemente immagini. Per le
traduzioni dei testi scritti in inglese, vedere le pagine nelle diverse lingue.
IT
Początkowe strony zawierają głównie rysunki. Tłumaczenie wykorzystanych
tekstów angielskich znajduje się na odpowiednich stronach językowych.
PL
RU Страницы в начале Инструкции состоят в основном из рисунков, схем и
таблиц. Перевод встречающегося там текста приведен в разделе RU.
AR3200
3
1028 / 1538 / 2028
1078 / 1588 / 2078
475
525
90
70
256
90
135
51
ø29
ø20
ø29
AR3200
4
244
134
933 805
156
525
66
805 / 1315
157
Mounting on threaded bars outside the unit
AR3220
AR3210 / AR3215
Front view
Side view
AR3200
5
Fig. 1b. Mounting on threaded bars outside the unit.
Mounting on threaded bars outside the unit
Fig. 1a: Mounting brackets on delivery.
AR3220
AR3200
6
Mounting on threaded bars inside the unit
Fig. 2a: Mounting brackets on delivery.
124
392
E/A: 932
W: 848
E/A: 851
W: 935
121
124
850 / 1360
54
88
Top view
Side view
AR3220
AR3210 / AR3215
124
392
E/A: 932
W: 848
E/A: 851
W: 935
121
124
850 / 1360
54
88
AR3200
7
Mounting on threaded bars inside the unit
Fig. 2c. Location of the mounting brackets on the inside of the unit.
AR3220
6x
AR3210, AR3215 4x
Fig. 2d. In order to mount the brackets, remove the service hatch, outlet grille and covering plates.
AR3220
Fig. 2b. Mounting on threaded bars inside the unit.
AR3200
8
Fig. 3a: Snap fixings
2.
1.
1.
2.
90°
AR
Service hatch
Fig. 3b: Open the unit.
Fig. 4:Terminal box inside unit.
PA34TR PA34CB
PA34VD
FHDN15
Accessories
PA34TR15 AR3210, AR3215, 1 m
PA34TR20 AR3220, 1 m
PA34CB15 AR3210, AR3215
PA34CB20 AR3220
PA34VD15 AR3210, AR3215
PA34VD20 AR3220
PAMLK AR3200
FHDN15 AR3200W PAMLK
AR3200
9
SIReBN
SIReAC
SIReAA
SIReRTX 70x33x23 mm
SIReUR 114x70x50 mm
SIReWTA
SIReCJ4
SIReCJ6
SIReCC603 3 m
SIReCC605 5 m
SIReCC610 10 m
SIReCC615 15 m
SIReCC640 40 m
SIReCC403 3 m
SIReCC405 5 m
SIReCC410 10 m
SIReCC415 15
SIRe
C
SIReB
SIReAC/SIReAA
SIReRTX
SIReUR
SIReWTA
SIReCC
SIReCJ4/SIReCJ6
VMO15LF
DN15
VMO15NF
DN15
VMO20
DN20
VMO25
DN25
VMOP15LF
DN15
VMOP15NF
DN15
VMOP20
DN20
VMOP25
DN25
VOS15LF DN15
VOS15NF
DN15
VOS20
DN20
VOS25
DN25
VOSP15 LF
DN15
VOSP15NF
DN15
VOSP20
DN20
VOSP25
DN25
VOT15 DN15
VOT20 DN20
VOT25 DN25
VMT15 DN15
VMT20 DN20
VMT25 DN25
VAT
VOS VOSP
VMO VMOP
VOT
VMT
VAT
AR3200
10
*1) Lowest/highest airflow of totally 3 fan steps.
*2) Conditions: Distance to the unit 5 metres. Directional factor: 2. Equivalent absorption area: 200 m². At
lowest/highest airflow
*3) ∆t = temperature rise of passing air at maximum heat output and lowest/highest airflow.
*4) Applicable at water temperature 60/40 °C, air temperature, in +18 °C.
Type Output
steps
[kW]
Airflow*1
[m3/h]
∆t*3
[°C]
Sound
level*2
[dB(A)]
Tension
motor
[V]
Amperage
motor
[A]
Tension [V]
Amperage [A]
(heat)
Length
[mm]
Weight
[kg]
AR3210E05 2/3/5 1000/1800 15/8 43/57 230V~ 0,7 230V~/21,7
400V3N~/7,2
1078 30
AR3210E08 3/5/8 1000/1800 24/13 43/57 230V~ 0,7 400V3N~/11,6 1078 31
AR3215E08 3/5/8 1600/2900 15/8 43/57 230V~ 1,3 400V3N~/11,6 1588 41
AR3215E12 4/8/12 1600/2900 22/12 43/57 230V~ 1,3 400V3N~/17,3 1588 42
AR3220E10 3/7/10 2100/3900 14/8 44/60 230V~ 1,6 400V3N~/14,5 2078 57
AR3220E16 6/10/16 2100/3900 23/12 44/60 230V~ 1,6 400V3N~/23,1 2078 59
Protection class A3200 E: IP20.
Protection class A3200 A/W: IP21.
CE compliant.
3Electrical heat - AR3200 E
Technical specifications
Type Output
[kW]
Airflow*1
[m3/h]
Sound
level*2
[dB(A)]
Tension
motor
[V]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
AR3210A 0 1000/1800 43/57 230V~ 0,7 1078 29
AR3215A 0 1600/2900 43/57 230V~ 1,3 1588 40
AR3220A 0 2100/3900 44/60 230V~ 1,6 2078 55
1Ambient, no heat - AR3200 A
Type Output
[kW]
Airflow*1
[m3/h]
∆t*3
[°C]
Water
volume
[l]
Sound
level*2
[dB(A)]
Tension
motor
[V]
Amperage
motor
[A]
Length
[mm]
Weight
[kg]
AR3210W 8,2 1000/1500 19/16 1,1 44/53 230V~ 0,6 1078 30
AR3215W 14 1700/2600 19/16 1,7 48/56 230V~ 1,0 1588 41
AR3220W 18 2500/3150 18/17 2,3 50/56 230V~ 1,2 2078 56
2Water heat - AR3200 W
