Friedrich CP05N10 Manuale utente

Compact Programmable

Room Air Conditioners

PURCHASER P.O. # DATE

PROJECT LOCATION

ENGINEER ARCHITECT

SUBMITTED BY FOR APPROVAL FOR REFERENCE

ITEM PLAN DESIGNATION QUANTITY COOLING BTU/H VOLTAGE FRIEDRICH MODEL

CP_SUBMITTAL_08 (3-08)

• Auto Air Sweep swing louvers

provide even air distribution

• 12-hour electronic timer lets

you program on/oﬀ times

• MoneySaver® setting saves

energy by cycling the fan with

the compressor

• Three cooling speeds, plus

three fan-only settings

• Energy eﬃcient for low operat-

ing cost

• 12-hour electronic timer lets

you program on/oﬀ times

• Three cooling speeds, plus three

fan-only settings

• Energy eﬃcient for low operat-

ing cost

• Stale air exhaust vent

• Four-way air ﬂow control

• Auto Air Sweep swing louvers

provide even air distribution

• 24-hour electronic timer lets

you program on/oﬀ times

• MoneySaver® setting saves

energy by cycling the fan with

the compressor

• Three cooling speeds, plus

three fan-only settings

• Fixed chassis

• One-touch, lift out ﬁlter

• Auto-restart

• Dry Mode for greater dehumidiﬁcation

• Expandable side curtains included to

block light and noise and to allow for

easier removal and storage

COMPACT SIZE FOR EASIER REMOVAL and STORAGE | 5,000 BTU/h EER 9.7

• Stale air exhaust vent

• Four-way air ﬂow control

• Slide-out chassis for more permanent

window or wall installation

• One-touch, lift out ﬁlter

• Auto-restart

• Dry Mode for greater dehumidiﬁcation

• Expandable side curtains included to

block light and noise and to allow for

easier removal and storage

COMPACT and SMALL SIZE FOR EASIER REMOVAL and STORAGE | 6,000 to 11,800 BTU/h EERs up to 10.8

• Energy eﬃcient for low operat-

ing cost

• Stale air exhaust vent

• Slide-out chassis for easy

window or wall installation

• Expandable side curtains

included

• Easy access, lift out ﬁlter

MEDIUM SIZE FOR EASIER REMOVAL and STORAGE | 14,000 to 23,500 BTU/h EERs up to 9.8

Specications

Due to continuing research in new energy-saving technology, specifications are subject to change without notice.

★ENERGY STAR® Models

Cooling

Capacity

BTU/h

Heating

Capacity

Rated

Electrical Characteristics (60 Hertz) Energy

Efficiency

Ratio

EER

Moisture

Removal

Pints/Hr.

Room Side

Air Circulation

CFM Sleeve

Net

Weight

Lbs.Model

Volts

Rated

Cooling

Amps

Cooling

Watts

Heating

Amps

Heating

Watts

COMPACT PROGRAMMABLE

CP05N10 5000 — 115 4.8 515 — — 9.7 1.3 135 P1 49

★CP06E10 6000 — 115 5.1 560 — — 10.7 1.8 210 P6 60

★CP08E10 7800 — 115 6.8 720 — — 10.8 3.0 250 P6 66

★CP10E10 10000 — 115 8.5 920 — — 10.8 3.0 270 P7 95

★CP12E10 12000 — 115 10.2 1110 — — 10.8 3.0 280 P7 100

CP14N10 14000 — 115 12.0 1430 — — 9.8 4.3 370 P4 119

CP18N30 18000/17600 — 230/208 8.2/8.8 1850/1810 — — 9.7/9.7 5.0 375 P4 150

CP24N30 23500/23100 — 230/208 12.0/13.1 2740/2710 — — 8.6/8.5 6.3 400 P5 163

Model

Circuit Rating

Breaker or

T-D Fuse

Plug Face

(NEMA#)

Wall Outlet

Appearance

CP05, CP06, CP08, CP10, CP12 and CP14. 125V - 15A 5 - 15P

CP18 250V - 15A 6 - 15P

CP24 250V - 20A 6 - 20P

Installation Information / Sleeve Dimensions

† Sleeve P1 does not have thru-the-wall hole dimensions, as these units are fixed chassis and should not be installed thru-the-wall.

Circuit Rating/ Breaker

Sleeve Height Width

Depth

with Front

Depth

Hood to

Louvers

Minimum

Extension

Into Room

Minimum

Extension

Outside

Window Width

Thru-the-wall

Finished Hole

Minimum Maximum Height Width

P1† 12 ¼" 18 ½" 15" 5" 3 ½" 10 ¾" 22" 36"

NOT FOR THRU-WALL

P4 17 ½" 26" 27

5⁄8"8

7⁄8"5½" 165⁄8" 27" 42" 17 ¾" 26 ¼"

P5 17 ½" 26" 29 ¾" 8 7⁄8" 5 ½" 19 ½" 27" 42" 17 ¾" 26 ¼"

P6 13 5⁄8" 18 ½" 20 5⁄8"8

1⁄8" 4 ½" 11" 22" 36" 13 7⁄8"18¾"

P7 15" 23 5⁄8" 22 ¼"" 8 ¾" 4 ½" 12 27" 39" 15 ¼" 23 7⁄8"

The consumer- through the AHAM Room Air Conditioner Certification Program- can be certain that the AHAM Certification Seal accurately

states the unit’s cooling and heating capacity rating, the amperes and the energy efficiency ratio.

★ As an ENERGY STAR® partner, Friedrich Air Conditioning Co. has determined that the selected ENERGY STAR®(★) models meet the ENERGY STAR®guidelines for energy efficiency.

CP_SUBMITTAL_08 (3-08)
