DUCTLESS SPLIT SYSTEMS

AIR CONDITIONERS |HEAT PUMPS

Ductless splits are an innovative and ecient alternative

to window and thru-the-wall units. They have the benets

of a central system, without the diculty and expense of

installing ductwork. These are only a few of the benets

of ductless...

• Unobstructed window views.

• No need to uninstall and store unit during the winter.

• Independently-controlled zone cooling means up to four separate

indoor units working from a single outdoor unit.

• Save money by turning o units in unoccupied rooms.

• Set room temperatures based on individual preferences, instead of

one-size-ts-all.

simple installation

Friedrich ductless split systems have the

advantages of a ducted installation without

the high material and labor costs. Absolutely

no ductwork is required, so most systems

can be installed and running in a few hours.

SEER ratings up to 19.0

All Friedrich ductless models exceed the

federal 13.0 SEER requirements. And, a full

one-third of our models have super high

ratings ranging from 16.5 to 19.0 SEER

signicantly outperforming 13 SEER product

on energy savings.

extremely quiet

Ductless systems keep the operating noise

of the condensing unit outdoors, while

the blower fan of the indoor unit remains

whisper quiet.

Like a central system, without the ductwork.

TECHNOLOGY

INVERTER

all models use

R-410A

R E F R I G E R A N T

The ultimate room air conditioner

Easy to install. Exceptionally quiet.

Totally flexible.

The indoor unit and outdoor unit are

connected by refrigerant and power

lines, through a small three-inch hole

in the exterior wall.

electric wiring

refrigerant lines

OUTDOOR CONDENSER

transfers heat to the outdoors.

Compact unit can be placed

at ground level, hung on an

outside wall or placed on the

roof of a building

hard-wired

INDOOR UNIT

converts warm indoor

air to cold indoor air,

conditioning and

dehumidifying the room.

Unit is mounted high on

the wall.

REFRIGERANT LINES AND

ELECTRICAL pass through

a 3” wall opening and run

along the exterior of the

building to the condensing

unit. Electrical hard-wiring

is required.

zone 1

70° in

conference

room

zone 4

prefers

76°

zone 2

attending

seminar, unit

turned o

zone 3

constant

temperature

changes

Precise comfort from one

system in up to four dierent

rooms. That’s the beauty– and

eciency of a Friedrich Multi-

Zone system.

Commercial applications

including restaurant dining areas

and kitchens

setpoint

Initial

startup

2nd

startup

3rd

startup

1st

shutdown

2nd

shutdown

Inverter Technology Standard Technology

Standard Energy Usage

Inverter reaches

setpoint faster, then

adjusts capacity as

required to maintain

accurate temp

Inverter Energy Usage

multiple conguration choices

Over 20 single, dual, tri- and quad-zone systems provide a wide range of

heating and cooling options for even the toughest remodels, additions and

improvements. A new level of system exibility and control is at your ngertips

on Friedrich single and multi-zone systems.

advanced inverter technology

Inverter Technology lets you reach the desired temperature faster, maintain it

more accurately, and reduce energy costs. It eliminates constant compressor

start-ups/shut-downs

that traditional

technology requires

to maintain the set

temperature.

variable capacity

advantages

Inverter Technology

allows each system to

adjust capacity and

cooling output to

provide only the amount of cooling needed at a given time. For example, an

18,000 BTU/h system will operate even more eciently as a 15,500 if that is all

that’s needed.

Multi-zone flexibility.

commercial applications

• Room additions/renovations

• Homes without ductwork

• Bedrooms and family rooms

• Garage workshops

• Four season sunrooms

• Guest quarters

• Wine cellars

residential applications

• Computer rooms/server rooms

• Restaurant kitchen and prep areas

• Oces in warehouse spaces

• Storage facilities

• Buildings where security concerns prevent

the use of window units

• Internal areas without exterior wall access

Wall-mounted single zone

One wall-mounted indoor unit

connected to one outdoor unit.

features

• Auto swing louvers (up/down)

• Continuous ‘Air Sweep’

• Auto-restart after power interruptions

• Auto-shut flaps close when unit is off

for a sleeker appearance

• Washable, reusable air filters

• Removable front grille

• Auto-changeover (heat pump models)

Wall-mounted multi-zone heat pump

Two, three or four wall-mounted indoor

units connected to one outdoor unit.

features

• Auto swing louvers (up/down)

• Continuous ‘Air Sweep’

• Auto-restart after power interruptions

• Auto-shut flaps close when unit is off

• Washable, reusable air filters

• Removable front grille

• Auto-changeover

• Low-ambient operation

multi-zone cool/heat pump

zone 1 zone 2 zone 3 zone 4

model btu/h total btu seer

M18DYF 9500 9500 — — 19000 16.5

11000 11000 22000

M21DYF 9500 12000 — — 21500 16.5

11000 14000 25000

M24DYF 12000 12000 — — 24000 16.5

14000 14000 28000

M27TYF 9200 9200 9200 —27600 15.0

11200 11200 11200 33600

M30TYF 9300 9300 11800 —30400 15.0

11000 11000 14000 36000

M33TYF 9400 11800 11800 —33000 15.0

10700 13600 13600 37900

M36TYF1 9100 9100 17000 —35200 15.0

9800 9800 18400 38000

M36TYF2 11700 11700 11700 —35100 15.0

12700 12700 12700 38100

M36QYF 8800 8800 8800 8800 35200 15.0

9500 9500 9500 9500 38000

cool only

model btu/h seer

MO9CF 9700 14.3

M12CF 12300 13.5

M18CF 18000 19.0

M24CF 24200 18.0

M30CF 30700 15.0

cool/ heat pump

model btu/h seer

M09YF 9700

9600 14.3

M12YF 12300

12800 13.7

M18YF 18000

21600 19.0

M24YF 24200

27600 18.0

Pictured: Single zone model MW24CF indoor unit. Multi-zone system M36QYF.

Appearance varies by model.

Fully featured and fully

programmable for

total convenience

Auto-shut flaps close

when unit is off for a

sleeker appearance.

The continuous ‘Air

Sweep’ auto louvers

gently distribute cool or

warm air throughout

the room.

Auto-changeover on

heat pump models

automatically switches

the unit from cool to

heat; or from heat to

cool to maintain desired

temperature.

A multi-zone system

allows you to

condition up to four

rooms or areas.

Each indoor unit can

be independently

controlled for

optimum flexibility,

best comfort and

increased energy

savings.

wireless remote

• Remote for each indoor unit

• 24-hour timer and sleep timer

• Auto/cool/dry/fan/heat* modes

• Four fan speeds heating* or cooling:

high/medium/low/quiet, plus auto-fan

• Secured remote control holder

• Four different transmitter codes to prevent

unintentional interference with nearby units

* Heat pump models only

= cooling capacity

= heating capacity

TECHNOLOGY

INVERTER

Ceiling suspended heat/cool

Ceiling cassette heat pump

features

• Auto-swing louvers (up/down)

• Continuous ‘Air Sweep’

• Auto-restart after power

interruptions

• Auto-changeover

• Washable, reusable air filters

• Low-ambient operation

• Fresh air intake

• Two branch ducts for

adjoining rooms

(requires additional fan)

• Condensate pump: 31" lift

• Auto-shut flaps close when unit is off

wired remote

• Seven-day programmable on/off timer

controls up to 16 units– individually or

by zones

• Auto/cool/dry/fan/heat modes

• Self-diagnostics

• Three fan speeds heating or cooling:

high/medium/low, plus auto-fan

features

• Auto swing louvers (up/down, left/right)

• Continuous ‘Air Sweep’

• Auto-restart after power interruptions

• Auto-shut flaps

• Washable, reusable

air filters

• Fresh air capability

• Low-ambient operation

• Optional DP-36 condensate pump

low profile– 9 ¼" above ceiling

Floor/ceiling universal heat pump

Universal system may be located low

against the wall or on the ceiling.

features

• Auto swing louvers (up/down, left/right)

• Continuous ‘Air Sweep’

• Auto-restart after power interruptions

• Auto-shut flaps close when unit is off

for a sleeker appearance

• Washable, reusable air filters

• Fresh air capability

wireless remote

•24-hour timer and sleep timer

• Auto/cool/dry/fan/heat modes

• Three fan speeds heating or cooling:

high/medium/low, plus auto-fan

• Four different transmitter codes

• Secured remote control holder

• Self-diagnostics

mounts on the ceiling

or low against the wall

cool/ heat pump

S24YF 22,200 BTU/h 15.0 SEER

24,200 BTU/h

wireless remote

• 24-hour timer and sleep timer

• Auto/cool/dry/fan/heat modes

• Three fan speeds heating or

cooling: high/medium/low,

plus auto-fan

• Four dierent transmitter codes

• Secured remote control holder

• Self-diagnostics

91/4"

cool/ heat pump

C24YF 22,200 BTU/h 15.0 SEER

24,200 BTU/h

cool/ heat pump

S36YF 34,100 BTU/h 14.0 SEER

38,200 BTU/h

PERFORMANCE RATINGS

SYSTEM MODEL NO. M09YF M12YF M18YF M24YF

INDOOR MODEL MW09Y1F MW12Y1F MW18Y3F MW24Y3F

OUTDOOR MODEL MR09Y1F MR12Y1F MR18Y3F MR24Y3F

Capacity Cooling BTU/h 9700 12300 18000 24200

Capacity Heating @47°F BTU/h 9600 12800 21600 27600

Capacity Heating @17°F BTU/h 7600 9900 16600 21000

HSPF 8.2 8.2 10 10

SEER 14.3 13.7 19.0 18.0

Moisture Removal Pts/h 2.1 3.2 5.9 5.3

Airflow (Quiet, Low, Med, High) CFM 185/220/260/295 215/250/305/355 240/290/355/415 380/450/560/650

Sound Rating - Indoor dB-A 26/31/36/40 28/35/40/45 25/32/38/44 32/36/41/47

Sound Rating - Outdoor dB-A 43 45 50 52

Operating Range COOL (HEAT) °F 0 - 115 (17-75) 0 - 115 (17-75) 0 - 115 (5-75) 0 - 115 (5-75)

ELECTRICAL DATA

Power Source 115-60-1 115-60-1 230/208-60-1 230/208-60-1

Min. Ampacity A12 15 16 21

Cooling Watts W820 1070 1730 2310

Max. TD Fuse/Breaker A15 20 20 30

REFRIGERATION SYSTEM

Refrigerant R410A R410A R410A R410A

Compressor Type Rotary Rotary Inverter Inverter

Connections Flare Flare Flare Flare

Liquid Line O.D. in 1/4 1/4 1/4 1/4

Suction Line O.D. in 3/8 3/8 1/2 5/8

Factory Precharge ft 25 25 49 49

Max. Line Length ft 49 49 66 98

Max. Height Difference ft 26 26 49 66

DIMENSIONS & WEIGHT

INDOOR UNIT

W x H x D in 31 1/8x 10 7/8x 8 1/231 1/8x 10 7/8x 8 1/231 1/8x 10 7/8x 8 1/239 1/4x 12 5/8x 9

Net Weight lbs 21 21 21 31

Shipping Weight lbs 26 26 26 40

OUTDOOR UNIT

W x H x D in 31 1/8x 21 1/4x 11 3/831 1/8x 21 1/4x 11 3/831 1/8x 22 3/4x 12 3/831 1/8x 22 3/4x 12 3/8

Net Weight lbs 71 79 88 97

Shipping Weight lbs 79 88 98 106

PERFORMANCE RATINGS

SYSTEM MODEL NO. M09CF M12CF M18CF M24CF M30CF

INDOOR MODEL MW09C1F MW12C1F MW18C3F MW24C3F MW30C3F

OUTDOOR MODEL MR09C1F MR12C1F MR18C3F MR24C3F MR30C3F

Capacity Cooling BTU/h 9700 12300 18000 24200 30700

SEER 14.3 13.5 19.0 18.0 15.0

Moisture Removal Pts/h 2.1 3.2 5.9 5.3 9.7

Airflow (Quiet, Low, Med, High) CFM 185/220/260/295 215/250/305/355 240/290/355/415 380/450/560/650 380/450/560/650

Sound Rating - Indoor dB-A 26/31/36/40 28/35/40/45 25/32/38/44 32/36/41/47 32/36/41/47

Sound Rating - Outdoor dB-A 43 45 50 52 53

Operating Range °F 0 - 115 0 - 115 0 - 115 0 - 115 0 - 115

ELECTRICAL DATA

Power Source 115-60-1 115-60-1 230/208-60-1 230/208-60-1 230/208-60-1

Min. Ampacity A12 15 16 21 22

Cooling Watts W820 1060 1730 2310 3460

Max. TD Fuse/Breaker A15 20 20 30 30

REFRIGERATION SYSTEM

Refrigerant R410A R410A R410A R410A R410A

Compressor Type Rotary Rotary Inverter Inverter Inverter

Connections Flare Flare Flare Flare Flare

Liquid Line O.D. in 1/4 1/4 1/4 1/4 3/8

Suction Line O.D. in 3/8 3/8 1/2 5/8 5/8

Factory Precharge ft 25 25 49 49 66

Max. Line Length ft 49 49 66 98 164

Max. Height Difference ft 26 26 49 66 98

DIMENSIONS & WEIGHT

INDOOR UNIT

W x H x D in 31 1/8x 10 7/8x 8 1/231 1/8x 10 7/8x 8 1/231 1/8x 10 7/8x 8 1/239 1/4x 12 5/8x 9 39 1/4x 12 5/8x 9

Net Weight lbs 21 21 21 31 31

Shipping Weight lbs 26 26 26 40 40

OUTDOOR UNIT

W x H x D in 31 1/8x 21 1/4x 11 3/831 1/8x 21 1/4x 11 3/831 1/8x 22 3/4x 12 3/831 1/8x 22 3/4x 12 3/835 3/8x 32 5/8x 13

Net Weight lbs 68 77 88 97 137

Shipping Weight lbs 77 86 98 106 155

Inverter model

wall mounted cooling

wall mounted heat pumps

PERFORMANCE RATINGS

SYSTEM MODEL NO.

M27TYF M30TYF M33TYF M36TYF1 M36TYF2

INDOOR MODEL

3 x MW09Y3FM 2 x MW09Y3FM MW12Y3FM MW09Y3FM 2 x MW12Y3FM 2 x MW09Y3FM MW18Y3FM 3 x MW12Y3FM

OUTDOOR MODEL

MR36TQY3F MR36TQY3F MR36TQY3F MR36TQY3F MR36TQY3F

Capacity Cooling BTU/h

9200 ea. 9300 ea. 11800 9400 11800 ea. 9100 ea. 17000 11700 ea.

Capacity Heating @ 47°F BTU/h

11200 ea. 11000 ea.14000 10700 13600 ea. 9800 ea.18400 12700 ea.

Capacity Heating @ 17°F BTU/h

8300 ea. 7700 ea. 9800 7200 9200 ea. 6700 ea. 12500 8600 ea.

HSPF

9.0 9.0 9.0 9.0 9.0

SEER

15.0 15.0 15.0 15.0 15.0

Moisture Removal Pts/h

2.9 ea. 2.9 ea. 3.7 2.9 3.7 ea. 2.9 ea. 5.7 3.7 ea.

Airflow (Quiet, Low, Med, High) CFM

185/220/260/295 185/220/260/295 215/250/305/355 185/220/260/295 215/250/305/355 185/220/260/295 240/290/355/415 215/250/305/355

Sound Rating - Indoor dB-A

27/29/33/37 27/29/33/37 30/34/39/42 27/29/33/37 30/34/39/42 27/29/33/37 33/39/42/46 30/34/39/42

Sound Rating - Outdoor dB-A

52 52 52 52 52

Operating Range COOL (HEAT) °F

0 - 115 (14-75) 0 - 115 (14-75) 0 - 115 (14-75) 0 - 115 (14-75) 0 - 115 (14-75)

ELECTRICAL DATA (all indoor units receive power from outdoor unit; values listed are total)

Power Source

230/208-60-1 230/208-60-1 230/208-60-1 230/208-60-1 230/208-60-1

Min. Ampacity A

22.5 22.5 22.5 22.5 22.5

Cooling Watts W

2710 3180 3710 4000 3980

Max. TD Fuse/Breaker A

30 30 30 30 30

REFRIGERATION SYSTEM

Refrigerant

R410A R410A R410A R410A R410A

Compressor Type

Inverter Inverter Inverter Inverter Inverter

Connections

Flare Flare Flare Flare Flare

Liquid Line O.D. in

1/4 1/4 1/4 1/4 1/4 1/4

Suction Line O.D. in

3/8 3/8 3/8 3/8 1/2 3/8

Factory Precharge ft

165 165 165 165 165

Max. Line Length ft

Each unit:82 Total:230 Each unit:82 Total:230 Each unit:82 Total:230 Each unit:82 Total:230 Each unit:82 Total:230

Max. Height Difference ft

49 49 49 49 49

DIMENSIONS & WEIGHT

INDOOR UNIT

W x H x D in

31 1/8x 10 7/8x 8 1/2ea. 31 1/8x 10 7/8x 8 1/2ea. 31 1/8x 10 7/8x 8 1/231 1/8x 10 7/8x 8 1/231 1/8x 10 7/8x 8 1/231 1/8x 10 7/8x 8 1/2

Net Weight lbs

21 ea. 21 ea. 21 21 21 ea. 21 ea. 21 21 ea.

Shipping Weight lbs

26 ea. 26 ea. 26 26 26 ea. 26 ea. 26 26 ea.

OUTDOOR UNIT

W x H x D in

35 3/8x 32 5/8x 13 35 3/8x 32 5/8x 13 35 3/8x 32 5/8x 13 35 3/8x 32 5/8x 13 35 3/8x 32 5/8x 13

Net Weight lbs

159 159 159 159 159

Shipping Weight lbs

172 172 172 172 172

PERFORMANCE RATINGS

SYSTEM MODEL NO. M18DYF M21DYF M24DYF M36QYF

INDOOR MODEL 2 x MW09Y3FM MW09Y3FM MW12Y3FM 2 x MW12Y3FM 4 x MW09Y3FM

OUTDOOR MODEL MR24DY3F MR24DY3F MR24DY3F MR36TQY3F

Capacity Cooling BTU/h 9500 ea. 9500 ea. 12000 12000 ea. 8800 ea.

Capacity Heating @ 47°F BTU/h 11000 ea. 11000 ea. 14000 14000 ea. 9500 ea.

Capacity Heating @ 17°F BTU/h 9500 ea. 9500 ea. 11000 10500 ea. 6600 ea.

HSPF 9.0 9.0 9.0 9.0

SEER 16.5 16.5 16.5 15.0

Moisture Removal Pts/h 2.9 ea. 2.9 ea 3.7 ea. 3.7 ea. 2.9 ea.

Airflow (Quiet, Low, Med, High) CFM 185/220/260/295 185/220/260/295 215/250/305/355 215/250/305/355 185/220/260/295

Sound Rating - Indoor dB-A 27/29/33/37 27/29/33/37 30/34/39/42 30/34/39/42 27/29/33/37

Sound Rating - Outdoor dB-A 52 52 52 52

Operating Range COOL (HEAT) °F 0 - 115 (14-75) 0 - 115 (14-75) 0 - 115 (14-75) 0 - 115 (14-75)

ELECTRICAL DATA (all indoor units receive power from outdoor unit; values listed are total)

Power Source 230/208-60-1 230/208-60-1 230/208-60-1 230/208-60-1

Min. Ampacity A 15 15 15 22.5

Cooling Watts W 1600 1900 2300 3900

Max. TD Fuse/Breaker A 20 20 20 30

REFRIGERATION SYSTEM

Refrigerant R410A R410A R410A R410A

Compressor Type Inverter Inverter Inverter Inverter

Connections Flare Flare Flare Flare

Liquid Line O.D. in 1/4 1/4 1/4 1/4 1/4

Suction Line O.D. in 3/8 3/8 3/8 3/8 3/8

Factory Precharge ft 98 98 98 165

Max. Line Length ft Each unit:82 Total:98 Each unit:82 Total:98 Each unit:82 Total:98 Each unit:82 Total:230

Max. Height Difference ft 33 33 33 49

DIMENSIONS & WEIGHT

INDOOR UNIT

W x H x D in 31 1/8x 10 7/8x 8 1/2ea. 31 1/8x 10 7/8x 8 1/2ea. 31 1/8x 10 7/8x 8 1/2ea. 31 1/8 x 10 7/8 x 8 1/2 ea.

Net Weight lbs 21 ea. 21 21 21 ea. 21 ea.

Shipping Weight lbs 26 ea. 26 26 26 ea. 26 ea.

OUTDOOR UNIT

W x H x D in 35 3/8x 32 5/8x 13 35 3/8x 32 5/8x 13 35 3/8x 32 5/8 x 13 35 3/8 x 32 5/8 x 13

Net Weight lbs 151 151 151 159

Shipping Weight lbs 164 164 164 172

dual-zone heat pumps quad-zone heat pumps

tri-zone heat pumps

inverter model

USED WITH: LENGTH-FT. LIQUID SUCTION KIT#

All 9000 and 12000 BTU/h

Indoor Units

15 1/4” 3/8” T32150

35 1/4” 3/8” T32350

All 18000 BTU/h Indoor Units 15 1/4” 1/2” T42150

35 1/4” 1/2” T42350

All MW24Y3F and MW24C3F Units 15 1/4” 5/8” T52150

35 1/4” 5/8” T52350

All 30000 BTU/h Indoor Units and

S24YF, S36YF and C24YF Units

15 3/8” 5/8” T53150

35 3/8” 5/8” T53350

floor/ceiling universal ceiling suspended ceiling cassette

PERFORMANCE RATINGS

SYSTEM MODEL NO. S24YF S36YF C24YF

INDOOR MODEL MS24Y3F MS36Y3F MC24Y3F

OUTDOOR MODEL MR24UY3F MR36Y3F MR24UY3F

Capacity Cooling BTU/h 22200 34100 22200

Capacity Heating @47°F BTU/h 24200 38200 24200

Capacity Heating @17°F BTU/h 20100 27100 20100

HSPF 8.5 8.5 8.5

SEER 15.0 14.0 15.0

Moisture Removal Pts/h 7.4 7.4 6.4

Airflow (Low, Med, High) CFM 371/436/518 842/977/1089 436/536/618

Sound Rating - Indoor dB-A 38/43/47 41/45/48 38/43/45

Sound Rating - Outdoor dB-A 53 54 53

Operating Range COOL (HEAT) °F 0 to 115

(14-75)

0 to 115

(14-75)

0 to 115

(14-75)

ELECTRICAL DATA

Power Source 230/208-60-1 230/208-60-1 230/208-60-1

Min. Ampacity A 15.5 23 15.5

Cooling Watts W 2250 4220 2100

Max. TD Fuse/Breaker A 20 30 20

REFRIGERATION SYSTEM

Refrigerant R410A R410A R410A

Compressor Type Inverter (Twin Rotary) Inverter (Twin Rotary) Inverter (Twin Rotary)

Connections Flare Flare Flare

Liquid Line O.D. in 3/8 3/8 3/8

Suction Line O.D. in 5/8 5/8 5/8

Factory Precharge ft 50 50 50

Max. Line Length ft 165 165 165

Max. Height Difference ft 66 98 66

DIMENSIONS & WEIGHT

INDOOR UNIT

W x H x D in 39 x 7 7/8x 25 3/465 3/8x 9 1/2x 27 1/232 5/8x 9 5/8x 32 5/8

Net Weight lbs 62 106 75

Shipping Weight lbs 82 134 97

OUTDOOR UNIT

W x H x D in 35 3/8x 32 5/8x 13 35 3/8x 32 5/8x 13 35 3/8x 32 5/8x 13

Net Weight lbs 141 141 141

Shipping Weight lbs 154 154 154

DSS-08 Printed in USA

Insulated line sets are available for all Friedrich split systems in 15 ft. and 35 ft. lengths. Each line set is equipped with flare nuts on both ends. Both liquid and

suction lines are insulated. Line sets can be joined together with field supplied double female connectors. Each system requires one line set for each indoor

unit installed. On multi-zone systems, line sets should be ordered based on individual indoor unit capacities not total system capacity. For example, a M18DYF

uses 2 line sets for 9,000 btu units, not 1 for the 18,000 btu product.

DRAIN PUMP USED WITH

DP-36 S36YF

NOTE: All models have low ambient capabilities built-in. Capacity is reduced as 0 degrees Fahrenheit is approached.

NOTE: All R410A models have 1/2˝ UNF 20 thread per inch charging and vacuuming ports. An adapter must be used

for 1/4˝ gauges. Adapter part number 67270018 is available through Friedrich parts distributors.

all models use

R-410A

R E F R I G E R A N T

inverter model

ceiling and oor/ceiling universal heat pumps

refrigeration line sets

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Friedrich Condizionatore d'aria

Friedrich

Friedrich Twintemp EQ08 Manuale utente

Friedrich

Friedrich ZoneAire P09B Manuale utente

Friedrich

Friedrich KUHL R-410A Manuale utente

Friedrich

Friedrich CP10 Manuale utente

Friedrich

Friedrich Hazardgard SH15M30 Manuale utente

Friedrich

Friedrich CP05N10A Istruzioni per la costruzione

Friedrich

Friedrich CP10E10 Series Istruzioni per la costruzione

Friedrich

Friedrich MR36Y3J Manuale utente

Friedrich

Friedrich M30CF Manuale utente

Friedrich

Friedrich QUIETMASTER 2008 Manuale utente

Friedrich

Friedrich Hazardgard SH15L30-C Manuale utente

Friedrich

Friedrich UNI-FIT US08B10A Istruzioni per la costruzione

Friedrich

Friedrich MRM18Y3J Manuale utente

Friedrich

Friedrich Ductless split system Manuale utente

Friedrich

Friedrich EP08 Manuale utente

Friedrich

Friedrich MW24Y3H Manuale utente

Friedrich

Friedrich VERT-I-PAK 920-075-13 (1-11) Manuale utente

Friedrich

Friedrich MS24Y3F Manuale utente

Friedrich

Friedrich MC24Y3F Manuale utente

Friedrich

Friedrich Chill Premiere Series Manuale utente

Friedrich

Friedrich MW09Y3H Istruzioni per la costruzione

Friedrich

Friedrich MR30C3G Manuale utente

Friedrich

Friedrich QuietMaster Deluxe RS10 Manuale utente

Friedrich

Friedrich VERT-I-PAK VEA09 Istruzioni operative originali

Manuali Condizionatore d'aria popolari di altre marche

Spheros

Spheros CC 355 Manuale utente

Bosch

Bosch Climate 5000 SCI 24 CAS/ OU- OUE Manuale utente

Panasonic

Panasonic CS-E12HKEW Manuale utente

nedis

nedis ACMB1WT7 Manuale utente

Samsung

Samsung AR KV Series Guida

Daikin

Daikin FCFV50A Manuale utente

Fujitsu

Fujitsu Inverter ASBA30JFC Manuale utente

Toshiba

Toshiba RAS-M10SMUV-E Manuale utente

Daikin

Daikin FXLQ20MAVE Manuale utente

Hitachi

Hitachi RAS-E24CAK Manuale utente

CIAT

CIAT Magister 2 Series Guida

Bestron

Bestron AAC6000 Manuale utente

Hisense

Hisense 7K Manuale tecnico

Frigidaire

Frigidaire FFRE0533S1E0 Manuale utente

Samsung

Samsung AS09HM3N Manuale utente

Frigidaire

Frigidaire CRA073PU11 Manuale del proprietario

Soleus Air

Soleus Air GB-PAC-08E4 Manuale utente

McQuay

McQuay MCK020A Manuale utente
