Friedrich ZoneAire P12B Manuale utente
PORTABLE
AIR CONDITIONERS
THE EXPERTS IN ROOM AIR CONDITIONING
Air Conditioner
3-IN-1 SYSTEM:
Air conditioner,
dehumidier and fan.
Heat Pump
4-IN-1 SYSTEM:
Air conditioner, heater,
dehumidier and fan.
Heat pump operation is
more efcient than other
portables that rely on
resistance heat.
Both systems remove up to
72 pts./day when used as a
dehumidier.
Comfort & Convenience
Use remote to select
MODE, FAN SPEED,
adjust TEMPERATURE
and set the TIMER.
NOTE: Unit not shown installed.
Vent hoses must vent outdoors.
Dual hose design for up to 40% faster cooling or
heating and increased energy efficiency.
ZoneAire®
Air Conditioner
COOLING
11600 Btu
8.8 EER
Heat pump
COOLING
13500 Btu
9.5 EER
HEATING
10700 Btu
2.8 COP
PORTABLE AIR CONDITIONER AND HEAT PUMP
FASTER
COOLING &
HIGHER ENERGY
EFFICIENCY
Friedrich portables move easily
from room-to-room to provide
fast cooling and heating comfort.
NOTE: Air conditioners will provide cooling at outdoor temperatures down to 41� F and
heat pumps will provide heating at outdoor temperatures down to 14� F with single hose installation.
DUAL HOSE
Only indoor air is
conditioned and
returned into the
room. Indoor air is
not vented outside
and wasted.
The room is cooled
up to 40% faster
with greater energy
efciency.
SINGLE HOSE
Relies on air ‘leakage’
around doors and
windows to make
up for air volume
lost as indoor air is
exhausted outside.
Inefcient-both
indoor air and
removed heat are
exhausted.
Superior dual-hose design
AIR CONDITIONER
• 3-IN-1 SYSTEM: Air conditioner,
dehumidier and fan
• Built-in drain pump to remove
condensate
• Self-evaporative condensate
system means no bucket to
empty
• Condensate overow protection-
the unit will automatically shut
off if tank should become full.
The unit can be drained through
the water outlet drain
• 24-hour timer
• 3 fan speeds
• Washable, antimicrobial air lter
• Auto restart after power outage
• Stores easily in most closets
HEAT PUMP
• 4-IN-1 SYSTEM: Air conditioner,
heater, dehumidier and fan
• Dual hoses for closed loop
cooling and exhaust functions
for up to 40% faster, more
efcient cooling
• Built-in drain pump to remove
condensate
• Self-evaporative condensate
system means no bucket to
empty
• Condensate overow protection-
the unit will automatically shut
off if tank should become full.
The unit can be drained through
the water outlet drain
• 24-hour timer
• 3 fan speeds
• Washable, antimicrobial air lter
• Auto restart after power outage
• Stores easily in most closets
COOL & HEAT
COOL
INSTALLS QUICKLY AND EASILY
WITH THE INCLUDED WINDOW
INSTALLATION KIT.
Ideal for areas with added
heat loads and for cooling
emergencies
FEATURES/SPECIFICATIONS/INSTALLATION
Due to continuing research in new energy-saving technology, specications are subject to change without notice.
LISTED
PORTABLE AIR CONDITIONERS
183H
Commercial_Portable_Air_Conditioners_Brochure_2014 Printed in USA
Model P12B PH14B
PERFORMANCE
Cooling Capacity Btu 11600 13500
Heating Capacity Btu —10700
Energy Efciency Rating EER 8.8 9.5
Coefcient of Performance COP —2.8
Air Movement CFM 235 250
Moisture Removal Pts/hr. 6.0 6.0
SPECIFICATIONS
Refrigerant Type R410-A
Power Supply Volts 115
Rated Current Cooling Amps 11.5 10.8
Heating Amps —10.8
Watts 1318 1421/1120
Dimensions (Inches) W x H x D 19 1/2 x 33 1/2 x 15 1/2
Weight (Net/Shipping) Lbs. 72/90 78/95
Carton Dimensions (Inches) W x H x D 20 7/8 x 43 1/8 x 16 3/4
Model
Circuit Rating
Breaker or T-D
Fuse
Plug
Face
(NEMA#)
Wall Outlet
Appearance
Power
cord
length
P12B,
PH14B 125V - 15A 5 - 15P 6 ft.
Installation Kit
INSTALLATION KIT- Dual intake and exhaust
hoses. Flexible, heavy duty intake/exhaust
hoses extend from 24” to 60”. The hoses can
be vented through a window or through a wall
opening to the outside.
WINDOW SLIDER KIT (Included)
Fits HORIZONTAL or VERTICAL WINDOWS
WINDOW OPENING:
Minimum: 26"* Maximum: 46"
* Window slider kit can be trimmed to t a smaller
opening.
NOTE: Air conditioners will provide cooling at outdoor temperatures down to 41� F and
heat pumps will provide heating at outdoor temperatures down to 14� F with single hose installation.
Ideal Applications
• Supplemental or emergency
cooling or heating anywhere
• Temporary cooling in computer rooms
• Guard buildings
• Construction trailers/RVs
• Workshops and garages
• Home ofces
• Dorm rooms
• Bedrooms, attics and basements
• Sunrooms/enclosed patios
Installation Features
• Plugs into standard 115 volt outlet
• Easy-roll casters for portability
• All installation accessories included
• Window kit ts both vertical and horizontal
standard and some casement slider windows
• 6 ft. long power cord
Friedrich Air Conditioning Co. l 10001 Reunion Place, Suite 500 l San Antonio, TX 78216 l 877.599.5665
www.friedrich.com
