Frigidaire FMV152K Manuale utente

frigidaire.com

Drop-In Cooktop

FPEC3085K S

30" Electric

Signature Features

Over-The-Range

Microwaves

FMV152K S / M / W/ B /Q

Ready-Select™ Controls

Easily select options with the touch

of a button.

Two Speed Ventilation

Over-the-range microwave doubles as

a hood with two fan speeds.

Sensor Cooking Options

Microwave automatically adjusts power

levels and cooking times to cook a

variety of items, effortlessly.

One-Touch Options

Our microwaves feature easy-to-use

one-touch buttons so you can cook

baked potatoes, popcorn, or even add

30 seconds with the touch of a button.

Product Dimensions

Height 15-3/4"

Width 29-7/8"

Depth 16-13/32"

More Easy-To-Use Features

Extra-Large 13-1/2" Diameter

Glass Turntable

10 Cooking Power Levels

Auto-Reheat Options

Control Lock Option

Electronic Clock & Timer

Vent Filters

Dishwasher-safe.

Auto-Start Heat Sensor Vent Fan

Ductless Vent Installation

Option Included

Attractive Stainless Steel Exterior1

Available in:

1Select models only.

Stainless

(S)

Bisque

(Q)

Black

(B)

White

(W)

Silver Mist

(M)

Specifications

subject to change.

Accessories information available

on the web at frigidaire.com

Microwaves

FMV152K S / M / W/ B /Q Over-The-Range

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Features

Control / Timing System

Exterior Door Finish

Handle Design

Microwave Capacity (Cu. Ft.)

Convection

Watts (IEC-705 Test Procedure)

Interior Light

Interior Color

Turntable Diameter

Turntable On / O

Control Lock

Clock

Touch Pad Buttons

Power Levels

Accessory Metal Rack

Microwave Control Options

Popcorn Button

Chicken Nugget Button

Baked Potato Button

Sensor Reheat Button

Snack Button

Beverage

Auto Melt / Soften Options

Auto Reheat Options

Snack Menu Options

Auto Cook Options

Auto Defrost Options

Keep Warm

Add-30-Seconds

Sensor Cooking Options

Vegetable Cook Sensor

Delay Start

User Preferences

Ventilation System

Ducted / Ductless

Installation Option

Exhaust Fan (CFM)

Cooktop Light

Auto-Start Heat Sensor

Dishwasher-Safe Vent Filter

(Ductless Installation)

Power Ratings

Frequency (Mhz)

Watts @ 120 Volts

Amps @ 120 Volts

Optional Accessories

36" Stainless Steel Trim Kit

36" White Trim Kit

36" Black Trim Kit

Speciﬁcations

Oven Interior (HxWxD)

Power Supply Connection Location

Voltage Rating

Connected Load

(kW Rating) @ 120 Volts1

Minimum Circuit Required (Amps)

Shipping Weight (Approx.)

Product Dimensions

A - Height

B - Width

C - Depth

15-3/4"

29-7/8"

16-13/32"

Ready-Select™

Stainless Steel (S), Color-

Coordinated (M/W/B/Q)

Black (S/M),

Color-Coordinated (W/B/Q)

1.5

1,000

Yes

White

13-1/2"

Yes

Weight / Time

Yes

2-Speed

170 / 300

Yes

2,450

1,550

PN # MWFILKTSS

PN # MWFILKTWH

PN # MWFILKTBK

9-1/4" x 20-1/4" x 14-13/32"

Right Top Rear

120V / 60Hz / 15A

1.55

Over-the-Range Microwave Oven

Frigidaire Baseline

Cutout Dimensions

Height (Min.)

Height (Max.)

Width (Min.)

Depth (Min.)

Depth (Max.)

16-3/4"

17"

30"

12"

13"

1For use on adequately wired 120V, dedicated circuit having 2-wire

service with a separate ground wire. Appliance must be grounded for

safe operation.

NOTE: For planning purposes only. Always consult local and national electric codes.

Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
