FACTORY PARTS CATALOG

ELECTRIC RANGE

P.O. Box 212378

Augusta, Georgia 30917

PRODUCT NO. BASE MODEL NO. COLOR MARKET

FEF305PHDB FEF305PH ALMOND USA

FEF305PHWB FEF305PH WHITE USA

FEF305PHSA FEF305PH WHITE/WHITE USA

FEF305PHSB FEF305PH WHITE/WHITE USA

FEF305PHTA FEF305PH ALMOND/ALMOND USA

FEF305PHTB FEF305PH ALMOND/ALMOND USA

Publication No.

5995341509

000721

-EN/SERVICE /CML

369

WIRING DIAGRAM # - 316002675

OWNER’S GUIDE # - 316000629

INSTALLATION GUIDE # - 316003025 ELECTRIC - RANGE

FEF305PHDB

FEF305PHWB

FEF305PHSA

FEF305PHSB

FEF305PHTA

FEF305PHTB

07/00 2

Publication number

5995341509 FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

# - Fast Moving Parts

* - Non Illustrated Parts 3 6/98

Publication number

FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB 5995341509

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

A = FEF305PH (FEF305PHDB)

B = FEF305PH (FEF305PHSA)

C = FEF305PH (FEF305PHSB)

D = FEF305PH (FEF305PHTA)

E = FEF305PH (FEF305PHTB)

F = FEF305PH (FEF305PHWB)

POS. NO PART NO DESCRIPTION

* 316021105 A B C D E F Screw,hex ,8-18 x 0.375 ,back\bodyside

* 316021108 A B C D E F Screw,cup pt ,8-18 x 0.375 ,hinge,ind lght brkt,manifold pnl

* 316021110 A B C D E F Screw,semi gim ,8-18 X 1/2 ,black

* 5303272555 A B C D E F Clip-backguard

1 3131123 A B C D E F Shield-backguard,rear wall

9 316133501 - B C - - F Trim-splasher,white

9 316133502 A - - D E - Trim-splasher,almond

11 316057002 A ----F Trim-wrapper

12 # 316032408 A - C - E F Thermostat-oven

12 # 5303212745 - B - D - - Thermostat-oven

14 3201726 A B C D E F Light/Lamp,indicator ,blue ,250 V

16 316042602 A B C D E F Plate,instrument mtg

19 316034120 A ----F Panel-control,black

19 316034128 - B C - - - Panel-control,white

19 316034129 ---DE- Panel-control,almond

30A 316064300 A B C D E F Nut,nylon

32 316123306 - - C - - - Knob-thermostat, white

32 316123307 A ----F Knob-thermostat,black

32 316123308 ----E- Knob-thermostat,almond

32 316123300 - B ---- Knob-thermostat,white

32 316123302 ---D-- Knob-thermostat,almond

36 316123303 A ----F Knob-infinite switch, black

36 316123304 - B C - - - Knob-infinite switch, white

36 316123305 ---DE- Knob-infinite switch, almond

40 316064009 A ----F Panel-manifold,black

40 316064015 ---DE- Panel-manifold,almond

40 316064030 - B C - - - Panel-manifold,white

44 3131468 A B C D E F Bracket,backguard

45A 316056902 A ----F Bolt-fastener,nylon

45A 316056903 ---DE- Bolt-fastener,nylon ,white

45A 316056904 - B C - - - Bolt-fastener,nylon ,almond ,(2)

46 316065801 A B C D E F Lens-light/lamp,indicator ,red

50 316096900 A ----F Bezel-nameplate,black

51 316095420 A ----F Nameplate, black

54 # 5303285142 A B C D E F Switch-6" element

54A# 5303285143 A B C D E F Switch-8" element

07/00 4

Publication number

5995341509 FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 5 07/00

Publication number

FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB 5995341509

CAUTION: Use the part number on all orders, not the position number.

BODY

A = FEF305PH (FEF305PHDB)

B = FEF305PH (FEF305PHSA)

C = FEF305PH (FEF305PHSB)

D = FEF305PH (FEF305PHTA)

E = FEF305PH (FEF305PHTB)

F = FEF305PH (FEF305PHWB)

POS. NO PART NO DESCRIPTION

* 316021105 A B C D E F Screw,hex ,8-18 x 0.375 ,back\bodyside

* 316021108 A B C D E F Screw,cup pt ,8-18 x 0.375,hinge,ind lght brkt,manifold pnl

* 5303051099 A B C D E F Nut,hex ,#10-32

* 5308014215 A B C D E F Screw

*# 316001559 A B C D E F Harness-main

* 3131903 A B C D E F Bumper-door/drawer

* 3203550 A B C D E F Plug-button

* 3051367 A B C D E F Clip-wire

1 316080804 A B C D E F Back-main

3 316081034 - B C - - F Panel-bodyside,white ,RH

3 316081036 A - - D E - Panel bodyside,almond ,RH

3* 316081035 - B C - - F Panel-bodyside,white ,LH

3A 316081037 A - - D E - Panel-body side,almond ,LH

4 5303271756 A B C D E F Burner Box

5 316129200 A B C D E F Screw-leveling,plastic ,with stop

6 316067902 A B C D E F Rack-oven

7 316007007 A B C D E F Hinge-oven door,(2)

8 3203540 A B C D E F Panel-oven bottom

9 316081900 A B C D E F Pan-broiler

10 316082000 A B C D E F Insert-broiler pan

21 3014099 A B C D E F Spacer-bodyside, (8)

27 5303284616 A B C D E F Clip-thermo bulb

29 3051162 A B C D E F Glide-drawer,front

41 3131570 A B C D E F Cover-hinge cutout

57 316081101 A B C D E F Cover-access

58 3200847 A B C D E F Insulation,oven bottom

58A 316047707 A B C D E F Insulation, 1" ,oven wrapper

58B 316054202 A B C D E F Insulation, 1" ,oven back

59 316073601 A B C D E F Tube-oven vent

62 # 5303935061 A B C D E F Terminal Block

63 5301145190 A B C D E F Plate-ground strap

66 # 5303051140 A B C D E F Element-broil

67 # 316075103 A B C D E F Element-bake

68 316075300 A B C D E F Support-element, broil

69 3051218 A B C D E F Plate-oven light

71 316015805 A B C D E F Shield-rear wall

82 5303289913 A B C D E F Shield-insulation

87 316081200 A B C D E F Bracket-cable mtg

170 316107200 A B C D E F Anti-tip bracket

170* 316116000 A B C D E F Screw-Anti-tip,1.75” concrete

170* 5303935180 A B C D E F Kit-AntiTip bracket (complete w/template & screws)

07/00 6

Publication number

5995341509 FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

# - Fast Moving Parts

* - Non Illustrated Parts 7 07/00

Type your model numbers here

CAUTION: Use the Kenmore part number on all orders, not the position number.

TOP/DRAWER

A = FEF305PH (FEF305PHDB)

B = FEF305PH (FEF305PHSA)

C = FEF305PH (FEF305PHSB)

D = FEF305PH (FEF305PHTA)

E = FEF305PH (FEF305PHTB)

F = FEF305PH (FEF305PHWB)

POS. NO PART NO DESCRIPTION

* 316021105 A B C D E F Screw,hex ,8-18 x 0.375 ,back\bodyside

* 316021108 A B C D E F Screw,cup pt ,8-18 x 0.375 ,hinge,ind lght brkt,manifold pnl

* 316021112 - B C - - F Screw-8-18x1/2 Tr Sqd White

* 316021113 A - - D E - Screw-8-18x1/2 Tr Sqd Almond

* 316021110 A B C D E F Screw,semi gim ,8-18 X 1/2 ,black

* 316089600 A B C D E F Spacer-drawer,(2)

* 5303280311 A B C D E F Screw, waf hd sdr , 10-32 x 5/16 , (2)

* 5308014215 A B C D E F Screw

* # 316001731 A B C D E F Wiring Harness,surface element

1 316011501 A B C D E F Drawer-utility

2 3131975 A B C D E F Shield-panel

4 316084405 - B C - - F Panel-drawer,white

4 316084406 A - - D E - Panel-drawer,almond

,7 3051163 A B C D E F Glide-drawer,rear

15 # 3051450 A B C D E F Element-surface, 8" , large

15A# 3051449 A B C D E F Element-surface, small

16 3013512 A - - D E - Main Top,almond

16 5303013511 - B C - - F Main Top,white

17 316066900 A B C D E F Rod-maintop support

18 08067747 A B C D E F Bracket-hinge,main top RH

18A 08067746 A B C D E F Bracket-hinge,main top LH

19 # 316048413 A B C D E F Pan-surface element,chrome ,large/8 inch,(2)

19A# 316048414 A B C D E F Pan-surface element,chrome ,small/6 inch,(2)

27 # 5303912666 A B C D E F Terminal Block Kit,surface element

28 5303017715 A B C D E F Medallion,1 1/2"dia ,black ,surface element

07/00 8

Publication number

5995341509 FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB

CAUTION: Use the part number on all orders, not the position number.

DOOR

# - Fast Moving Parts

* - Non Illustrated Parts 9 07/00

Publication number

FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB 5995341509

CAUTION: Use the part number on all orders, not the position number.

DOOR

A = FEF305PH (FEF305PHDB)

B = FEF305PH (FEF305PHSA)

C = FEF305PH (FEF305PHSB)

D = FEF305PH (FEF305PHTA)

E = FEF305PH (FEF305PHTB)

F = FEF305PH (FEF305PHWB)

POS. NO PART NO DESCRIPTION

* 316021110 A B C D E F Screw,semi gim ,8-18 X 1/2 ,black

* 316102200 A B C D E F Foil-aluminum

* 5303212762 A - - D E - Screw,8-18 X ½,almond

* 316021112 - B C - - F Screw,8-18 X ½,white

* 5303271648 A B C D E F Screw- wafer hd sq dr , 8-18AB x 1/2

* 5303280311 A B C D E F Screw, waf hd sdr , 10-32 x 5/16 , (2)

9 316066611 A B C D E F Liner-oven door

10 5303281378 A B C D E F Screw-handle mtg,wafer head ,10-24F x 3

12 5303202011 A B C D E F Seal-oven door,non self-clean

13 3202315 - B C - - F Panel-oven door,white

13 3202316 A - - D E - Panel-oven door,almond

39 316020202 - B C - - - Handle-door, white , oven

39 316020204 A ----F Handle-door,black ,oven

39 316020205 ---DE- Handle-door, almond , oven

49 3016755 A ----F EndCap,black ,(2)

49 316020101 - B C - - - End Cap-handle, white , (2)

49 316020103 ---DE- EndCap-handle, almond , (2)

07/00 10

Publication number

5995341509 FEF305PHDB, FEF305PHWB,FEF305PHSA,FEF305PHSB,FEF305PHTA,FEF305PHTB

CAUTION: Use the part number on all orders, not the position number.

WIRING DIAGRAM
