Frigidaire FEF352BFWB Manuale utente

FACTORY PARTS CATALOG

ELECTRIC RANGE

P.O. Box 212378

Augusta, Georgia 30917

PRODUCT NO. BASE MODEL NO. COLOR MARKET

FEF352BFWB FEF352BF WHITE USA

Publication No.

5995319828

990419

-EN/SERVICE /VLM

369

WIRING DIAGRAM # - 316002625

ELECTRIC - RANGE

MEF352BFWB

04/99 2

Publication number

5995319828 MEF352BFWB

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

# - Fast Moving Parts

* - Non Illustrated Parts 3 6/98

Publication number

MEF352BFWB 5995319828

CAUTION: Use the part number on all orders, not the position number.

BACKGUARD

POS. NO PART NO DESCRIPTION

1 316081601 Shield-backguard,rear wall

2 316015907 Shield-backguard,inner

11 316061841 Trim-wrapper,black

14 316022503 Light/Lamp, indicator , surface ,250 V

15 316023108 Support-backguard,RH

15A 316023109 Support-backguard,LH

19 316076564 Panel-control,metal

19 316076566 Panel-control,metal

20 # 316101103 Clock/Timer,trimline,dial 3

20* 316101508 Overlay-clock

23 316100400 Bracket-clock mtg

24 316005602 Switch-rocker,oven light ,black

32 316101301 Knob-thermostat

36 316015203 Knob-control,(6)

40 316062329 Panel-manifold,black

46 316040201 Lens-light/lamp,indicator ,red

54 # 316021500 Switch-infinite, 6" element

54A# 316021501 Switch-infinite, 8" element

60 316021105 Screw,hex ,8-18 x 3/8 ,back\bodyside

69 5303292005 Screw-switch/handle,8-32 x 5/32

* 316021108 Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316096900 Bezel-nameplate,black

04/99 4

Publication number

5995319828 MEF352BFWB

CAUTION: Use the part number on all orders, not the position number.

BODY

# - Fast Moving Parts

* - Non Illustrated Parts 5 04/99

Publication number

MEF352BFWB 5995319828

CAUTION: Use the part number on all orders, not the position number.

BODY

POS. NO PART NO DESCRIPTION

1 316080801 Back-main

3 316081028 Panel-bodyside,white ,RH

3* 316081029 Panel-bodyside,white ,LH

4 5303271756 Burner Box

5 5303203397 Screw-leveling

5* 3934058 Anti-tip Kit

5* 316078600 Screw,anti-tip ,(4)

5* 5303288460 Nut,T-type ,leveling screw

6 316067901 Rack-oven

7 316007002 Hinge-oven door,(2)

8 3203540 Panel-oven bottom

9 316073800 Pan-broiler

10 3205234 Insert-broiler pan

12 316027701 Switch-oven light

13 316026800 Rod-light switch /door

14 3014073 Socket-light/lamp,oven

15 5303013071 Light Bulb/Lamp

16 08011086 Lens-light/lamp,glass ,oven

17 316087500 Retainer-lens

18 # 316036300 Latch-door

21 3014099 Spacer-bodyside,(8)

25 3200848 Shield-heat,lower

29 3051162 Glide-drawer,front

30 5303283574 Bracket-hinge,main top RH

30A 5303283575 Bracket-hinge,main top LH

37 # 316111200 Probe-oven temp

41 3131570 Cover-hinge cutout

44 3131903 Bumper-door/drawer,rubber

57 316081101 Cover-access

58 3200847 Insulation,oven bottom

58A 316047708 Insulation, 2" ,oven wrapper

58B 316054202 Insulation, 1" ,oven back

58C 3131304 Insulation,oven top

59 316073600 Tube-oven vent

62 # 5303935061 Terminal Block

63 5301145190 Plate-ground strap

66 # 5303051140 Element-broil

67 # 316075102 Element-bake,lower oven

68 316075300 Support-element, broil

71 316015805 Shield-rear wall

72 5303285692 Cover-light/switch rod

82 5303289913 Shield-insulation

87 316081200 Bracket-cable mtg

88 316026400 Rod-latch,auto

89 # 316028101 Motor-latch/lock

* 3203550 Plug-button

* 316021108 Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 5303051099 Nut,hex ,#10-32

04/99 6

Publication number

5995319828 MEF352BFWB

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

# - Fast Moving Parts

* - Non Illustrated Parts 7 04/99

Publication number

MEF352BFWB 5995319828

CAUTION: Use the part number on all orders, not the position number.

TOP/DRAWER

POS. NO PART NO DESCRIPTION

1 316011501 Drawer-utility

2 3131975 Shield-panel

4 316084405 Panel-drawer,white

4* 316021112 Screw-8-18x1/2 Tr Sqd White

7 3051163 Glide-drawer,rear

15 # 5303015715 Element-surface,large/8 inch

15A# 5303015716 Element-surface,small/6 inch

16 316020907 Main Top,white

17 316057601 Rod-maintop support

18 5303273062 Hinge-main top,RH

18A 5303273063 Hinge-main top,LH

19 5303935054 Pan-surface element,large/8 inch

19A 5303935057 Pan-surface element,small/6 inch

27 # 5303912666 Terminal Block Kit,surface element

28 3017801 Medallion,stainless steel ,surf elem

44 3131903 Bumper-door/drawer,rubber

* 316021105 Screw,hex ,8-18 x 3/8 ,back\bodyside

* 3203618 Rivet-pop,warning-plate

* 316021108 Screw,cup pt ,#8-18 x 3/8 ,hinge ,

ind lght brkt,manifold pnl

* 316089600 Spacer-drawer,(2)

* 5303280311 Screw,waf hd sdr ,10-32 x 5/16 ,(2)

* 5308014215 Screw,#6-20 x 5/16 ,(4)

* # 316001725 Harness-wiring,surface element

04/99 8

Publication number

5995319828 MEF352BFWB

CAUTION: Use the part number on all orders, not the position number.

DOOR

# - Fast Moving Parts

* - Non Illustrated Parts 9 04/99

Publication number

MEF352BFWB 5995319828

CAUTION: Use the part number on all orders, not the position number.

DOOR

POS. NO PART NO DESCRIPTION

3 316067802 Trim-oven door,black

4 316089000 Glass-oven door,black ,outer

5 316088700 Glass-oven door,airwash

6 316088401 Shield-wool

7 316076403 Insulation-door

8 316088600 Glass-oven door,inner

9 316066610 Liner-oven door

10 5303281378 Screw-handle mtg,wafer head ,10-24F x 3

12 5303131601 Seal-oven door

14 5303208656 Reflector,aluminum foil

14A 5303208655 Reflector,aluminum foil

15 316081401 Bracket-glass mtg

16 316085700 Glass-oven door,heat barrier

39 5303273127 Handle-door,black ,oven

49 3016755 End Cap,black ,(2)

52 316081303 Shield-oven door,black ,top

* 316065301 Plate warning/caution

* 5303212671 Screw,cr pan hd sems ,8-32BP x 1.00

* 5303271648 Screw,wafer hd sq dr ,8-18AB x 1/2

* 5303280311 Screw,waf hd sdr ,10-32 x 5/16 ,(2)

* 5303285179 Screw-oven door,wafer head ,8-32T x 1/2

04/99 10

Publication number

5995319828 MEF352BFWB

CAUTION: Use the part number on all orders, not the position number.

WIRING DIAGRAM
