Frigidaire FFEF3015LS Istruzioni per l'installazione

frigidaire.com

Drop-In Cooktop

FPEC3085K S

30" Electric30" Electric

Signature Features

Large Capacity

Our large capacity oven gives you

room to cook more at once.

Ready-Select® Controls

Select options or control cooking

temperature with our easy-to-use

controls.

Product Dimensions

Height (Max.) 47-1/2"

Width 29-7/8"

Depth (Including Handle) 28-1/2"

More Easy-To-Use Features

Store-More™ Storage Drawer

Our convenient drawer gives you extra

storage space in your kitchen.

Quick Clean

For a quick, light oven cleaning.

Extra-Large Window

Our extra-large oven window lets you

easily see what’s inside.

Hi /Lo Broil Option

Offers two-position broiling and

variable temperature control for

more control.

Auto Shut-O

As an extra safety measure, the oven will

automatically shut off after 12 hours.

Timed Cook Option

Bright Lighting

Our bright lighting makes it easy

to see what’s inside.

Chrome Drip Bowls

Attractive Stainless Steel Exterior1

Available in:

Elements

Right Front

Right Rear

Left Front

Left Rear

Watts

1,250

2,100

1,250

Size

Even Baking Technology

Our latest technology ensures

even baking every time.

One-Touch Self Clean

Start the self-cleaning cycle with

just the touch of a button. 1Select model only.

Freestanding Ranges

FFEF3015L S / W/ B

Stainless

(S)

White

(W)

Black

(B)

Specifications

subject to change.

Accessories information available

on the web at frigidaire.com

NOTE: For planning purposes only. Always consult local and national electric codes.

Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.

30" Electric Freestanding Ranges

Frigidaire Baseline

36"

(Adjustable)

Features

Oven Control / Timing System

Surface Type

Window

Exterior Door Finish

Handle Design

Exterior Finish (Side Panels)

Convection System

Oven Cleaning System

Drawer Functionality

Oven Controls

Bake

Broil

Add-a-Minute

Delay Bake

Self-Clean

Quick Clean Option

Delay Clean

Kitchen Timer

Timed Cook Option

Auto Oven Shuto

Cooktop Features

Right Front Element (Watts)

Right Rear Element (Watts)

Left Front Element (Watts)

Left Rear Element (Watts)

Center Element (Watts)

Hot Surface Indicator Light

Coil Cooktop / Drip Bowls

Oven Features

Capacity (Cu. Ft.)

Oven Light

Hidden Bake Element

Rack Conﬁguration

Even Baking System

Broiling System

Bake Element / Broil Element (Watts)

Speciﬁcations

Oven Interior ( H x W x D )

Power Supply Connection Location

Voltage Rating

Connected Load

(kW Rating) @ 240 / 208 Volts

Minimum Circuit Required (Amps)

Shipping Weight (Approx.)

Ready-Select® Controls

Black Porcelain ( S ),

Color-Coordinated Porcelain

( W/B )

Extra-Large

Stainless Steel ( S ),

Color-Coordinated ( W/B )

Black ( S ),

Color-Coordinated ( W/B )

Black ( S ),

Color-Coordinated ( W/B )

Self Clean

Storage

Yes

Low and High

Yes

12 Hours

6" – 1,250

8" – 2,100

6" – 1,250

Yes / Chrome

5.3

2 Standard

Yes

Vari-Broil™ Hi / Lo

2,600 / 3,000

21" x 24-3/8" x 19-1/8"

Middle Bottom Rear

240V / 208V / 60Hz

10.0 / 7.5

138 Lbs.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Freestanding Ranges

FFEF3015L S / W / B 30" Electric

Product Dimensions

A - Height (Max.)

B - Width

C - Depth (Including Handle)

Depth with Door Open 90˚

47-1/2"

29-7/8"

28-1/2"

48-3/8"

Cutout Dimensions

Height (Standard)

Width (Min.)

Depth (Min.)

36"

30"

24"

Specifications

subject to change.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

General Installation Guidelines

with Side-by-Side Refrigerator

Top

Use these dimensions and clearance instructions for planning purposes only. For detailed installation

instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.

Front

Top

Front

Specifications

subject to change.

USA

•

10200 David Taylor Drive

•

Charlotte, NC 28262

•

1-800-FRIGIDAIRE

•

frigidaire.com

CANADA

•

5855 Terry Fox Way

•

Mississauga, ON L5V 3E4

•

1-800-265-8352

•

frigidaire.ca

Use these dimensions and clearance instructions for planning purposes only. For detailed installation

instructions, refer to installation guide, packed with product, or on the web at frigidaire.com.

Front

Top

Front

Top

General Installation Guidelines

with Top Mount Refrigerator
