FujiFilm YV4.3X2.8SA-2 Manuale utente

［Lens Image］

5.4（MAX.）

3.8

65.5（MAX.）

48.8

1:1.4/2.8-12mm

45.7

26.7

11.814.8

YV4.3x2.8SA-2

Focal Length

（mm）

2.8 - 12 (4.3x)

Iris Range

F1.4 - Close

Operation

Zoom

Manual

Focus

Manual

Iris

Manual

Angle Of View

(H×V)

1/3" WIDE

100°02' × 74°03'

TELE

23°26' × 17°36'

1/4" WIDE

74°03' × 55°06'

TELE

17°36' × 13°13'

Angle Of View

(H×V)

Aspect Ratio

16：9

1/3" WIDE

109°33' × 60°80'

TELE

25°31' × 14°23'

1/4" WIDE

80°56' × 44°51'

TELE

19°10' × 10°48'

Focusing Range

（From Front Of The Lens）（ m）

- 0.3

Object

Dimensions

at M.O.D.

(H×V) (mm)

1/3" WIDE

753 × 476

TELE

131 × 98

1/4" WIDE

476 × 329

TELE

98 × 73

Object Dimensions

at M.O.D.

(H×V) (mm)

Aspect Ratio 16:9

1/3" WIDE

895 × 365

TELE

143 × 80

1/4" WIDE

538 × 260

TELE

106 × 60

Back Focal Distance

（in air）（ mm）

7.83

Exit Pupil Position

（From Image Plane）（ mm）

455

Filter Thread

（mm）

–

Mount

Mass

（g）

Remarks

•With Metal Mount

Aspherical

Lens

Vari-Focal Wide Angle Manual Iris CS Mount Metal Mount RoHS

Compliant

Large

Aperture Ratio

Telephoto

Long Focal

YV4.3x2.8SA-2

Focal Length

（mm）

2.8 - 12 (4.3x)

Iris Range

F1.4 - Close

Operation

Zoom

Manual

Focus

Manual

Iris

Manual

Angle Of View

(H×V)

1/3" WIDE

100°02' × 74°03'

TELE

23°26' × 17°36'

1/4" WIDE

74°03' × 55°06'

TELE

17°36' × 13°13'

Angle Of View

(H×V)

Aspect Ratio

16：9

1/3" WIDE

109°33' × 60°80'

TELE

25°31' × 14°23'

1/4" WIDE

80°56' × 44°51'

TELE

19°10' × 10°48'

Focusing Range

（From Front Of The Lens）（ m）

- 0.3

Object

Dimensions

at M.O.D.

(H×V) (mm)

1/3" WIDE

753 × 476

TELE

131 × 98

1/4" WIDE

476 × 329

TELE

98 × 73

Object Dimensions

at M.O.D.

(H×V) (mm)

Aspect Ratio 16:9

1/3" WIDE

895 × 365

TELE

143 × 80

1/4" WIDE

538 × 260

TELE

106 × 60

Back Focal Distance

（in air）（ mm）

7.83

Exit Pupil Position

（From Image Plane）（ mm）

455

Filter Thread

（mm）

–

Mount

Mass

（g）

Remarks

•With Metal Mount

4.3

HD Vari-Focal(2.8

12mm)

YV4.3x2.8SA-2

For Security

Unit : mm

Applicable camera

(model)

1/3 1/41/22/31

2.8mm

12mm
