FujiFilm FinePix S6000fd Manuale utente

FPT/Y-608107-PY

BL00549-200(1) E

A. Loading the Batteries

Camera Controls

Picture Taking

Still images that can be viewed on FinePix S6000fd / FinePix S6500fd

You can use this camera to view still images recorded on FinePix S6000fd

/ FinePix S6500fd or still images (excluding some uncompressed images)

recorded on a FUJIFILM digital camera that supports xD-Picture Card.

S6000 S6500

FinePix S6000fd / FinePix S6500fd has internal memory that can

store images without xD-Picture Card. Use an xD-Picture Card (sold

separately) when recording a large number of images.

Refer to Owner’s Manual for more detailed instructions

Open the battery cover.

Check that the camera is turned off

before opening the battery cover.

Press on the battery cover to push

the batteries down. Slide the cover

closed.

Press por qto select Year, Month,

Day, Hour, or Minute. Press nor o

to correct the setting.

✽Refer to the Owner’s Manual for

“Turning On and Off”.

Load the batteries correctly as

indicated by the polarity icons.

C. Taking Pictures

D. Viewing the Images

Set the Power switch to w.

Press por qto move through your

images.

Set the Power switch to qand set the

Mode dial to B.

Press the shutter button down halfway

to adjust the focus.

Halfway pressed

Double

beep

Press the shutter button down fully to

take a picture. The camera makes a

“Click” sound and takes the picture.

Fully pressed

Click

B. Setting up the Camera

Set the Power switch to qor wto

turn the camera on.

screen appears on the

screen.

SET

START MENU

/ LANG.

Press n, o, p, or qto select the

language.

Press MENU/OK to confirm the

setting.

You can select your preferred date

format.

SET

DATE / TIME NOT SET

YY.MM.DD

1. 1 12:00

Microphone

AF-assist illuminator/

Self-timer lamp

Lens hood

A/V OUT (Audio/Visual output) socket

DC IN 5V (power input) socket

USB socket (mini-B)

xD-Picture Card

slot

Auto

Scene Position

Picture Stabilization

Programmed Auto

Natural light/Natural &

Shutter-priority Auto

Portrait

Aperture-priority Auto

Landscape

Manual

Still photography

Movie recording

Movie

Terminal cover

Slot cover

Speaker

Strap mount

(One-touch AF) button

Focus mode selector switch

Flash

Focus ring

Zoom ring

Power switch

Shutter button

Exposure

compensation

button

Continuous

shooting button

Mode dial

Diopter adjustment dial

Indicator lamp

LCD monitor

DISP (Display)/

BACK button

Tripod mount

Viewfinder (EVF)

Intelligent Face Detection button

EVF/LCD (monitor

selector) button

Digital zoom button

4-direction ( )

button

MENU/OK button

Photo mode ( ) button

Battery cover

Power-OFF

Playback mode

Photography mode

Viewing Images on your PC

For more information

Refer to “How to use FinePixViewer” in the HELP menu, or “Software

Installation” in the Owner’s Manual, or visit Fujifilm “Q&A Search” in the

following website.

( http://www.fujifilm.com/products/digital/ )

For Macintosh users, refer to “Software Installation” in the Owner’s

Manual.

A. Installing Software

Do not connect the camera to your PC until the software

installation is completed.

1. Turn on your PC and start up Windows.

●

Users of Windows 2000 Professional or Windows XP

should log in by using a system administrator account (e.g.

“Administrator”).

2. Quit all other active applications until no applications are

shown in the taskbar.

3. Load the enclosed CD-ROM into

the CD-ROM drive. The installer

starts up automatically.

4. The Setup screen appears.

Click the [Installing

FinePixViewer] button.

5. After installation completed, press [Close] button.

B. Connecting the Camera to your PC

1. Insert the xD-Picture Card with images into the camera.

2. Connect the camera to your PC using the USB cable (mini-B).

C. Saving the Images

1. The Save Image Wizard starts up. Click the [Start]button.

2. Check that the files are downloaded from the camera to your

PC and that a folder with the date is created.

Ex. \My Documents \ My Pictures \ 2006_0824

Select “Preview” in the View menu to display an enlarged image.

D. Viewing the Images

1. Click the [Show List of Images] button.

Windows XP

The “Found New Hardware” help message appears in the

bottom-right corner of your screen. This message will close

when the settings are completed. No action is required.

FinePixViewer starts up automatically.

A.Installing Software

B.Connecting the Camera to your PC

C.Saving the Images

AC-5VX

(sold separately)

USB socket

(mini-B)

3. Set the Power switch to wto turn the camera on.

Windows 98 SE/Me/2000 Professional

FinePixViewer starts up automatically.
