FujiFilm FinePix Z3 Manuale utente

BL00547-200(1) E

Camera Controls

FPT/Y-608104-PY

Picture Taking

Refer to Owner’s Manual for more detailed instructions

OPEN

A. Loading the Battery

Make sure that the indicators are aligned. Push the battery release

catch down while loading the battery.

Check that the battery is firmly held in place.

C. Setting up the Camera

B. Charging the Battery

Set the camera in the cradle.

Plug the connecting

cable into the power

outlet.

When connecting is completed, battery charging begins. Charging

ends when the indicator lamp turns off (about 2 hours).

Open the lens cover completely to turn

the camera on.

screen appears on the LCD

monitor.

SET NO

START MENU

/ LANG.

Press n, o, p, or q to select the

language.

D. Taking Pictures

Still images that can be viewed on FinePix Z3

You can use this camera to view still images recorded on FinePix Z3 or still

images (excluding some uncompressed images) recorded on a FUJIFILM

digital camera that supports xD-Picture Card.

Press the shutter button down halfway to

adjust the focus.

Press the shutter button down fully to

take a picture. The camera makes a

“Click” sound and takes the picture.

FinePix Z3 has internal memory that can store images without

xD-Picture Card. Use an xD-Picture Card (sold separately) when

recording a large number of images.

Press p or q to select Year, Month,

Day, Hour, or Minute. Press n or o to

correct the setting.

✽ Refer to the Owner’s Manual for

“Turning On and Off”.

Halfway pressed

You can select your preferred date

format.

SET NO

DATE / TIME NOT SET

YY.MM.DD 1. 1 12:00

E. Viewing the Images

Press w.

Press p or q to move through your

images.

Double

beep

Click

Set the Mode switch to q.

Plug the connecting

cable into the AC

power adapter.

Flash

Microphone

Lens

Speaker

Mode switch

Shutter button

Self-timer lamp

POWER switch/

Lens cover

DISP/BACK

/OK

W (Wide zoom)

button

T (Tele zoom)

button

Photo mode

(p) button

Strap mount

MENU/OK button

Picture stabilization

button

DISP (Display)/

BACK button

Indicator lamp

w (Playback) button

LCD monitor

4-direction nopq button

Battery cover

Cradle connection socket

xD-Picture Card slot

Battery release catch

Battery compartment

Battery release catch

Indicators

Plug the AC power

adapter connector into

the DC IN 5V socket

on the cradle.

Fully pressed

Press MENU/OK to confirm the setting.

Viewing Images on your PC

For more information

Refer to “How to use FinePixViewer” in the HELP menu, or “Software

Installation” in the Owner’s Manual, or visit Fujifilm “Q&A Search” in the

following website.

( http://home.fujifilm.com/products/digital/ )

For Macintosh users, refer to “Software Installation” in the Owner’s

Manual.

A. Installing Software

Do not connect the camera to your PC until the software

installation is completed.

1. Turn on your PC and start up Windows.

●

Users of Windows 2000 Professional or Windows XP

should log in by using a system administrator account (e.g.

“Administrator”).

2. Quit all other active applications until no applications are

shown in the taskbar.

3. Load the enclosed CD-ROM into

the CD-ROM drive. The installer

starts up automatically.

4. The Setup screen appears.

Click the [Installing

FinePixViewer] button.

5. After installation completed, press [Close] button.

B. Connecting the Camera to your PC

1. Insert the xD-Picture Card with images into the camera.

2. Connect the camera to your PC using the USB cable (mini-B).

C. Saving the Images

1. The Save Image Wizard starts up. Click the [Start] button.

2. Check that the files are downloaded from the camera to your

PC and that a folder with the date is created.

Ex. \My Documents \ My Pictures \ 2006_0624

Select “Preview” in the View menu to display an enlarged image.

D. Viewing the Images

1. Click the [Show List of Images] button.

Windows XP

The “Found New Hardware” help message appears in the

bottom-right corner of your screen. This message will close

when the settings are completed. No action is required.

FinePixViewer starts up automatically.

A.Installing Software

B.Connecting the Camera to your PC

C.Saving the Images

3. Press POWER on the cradle to turn the camera on in

Playback mode.

Windows 98/98 SE/Me/2000 Professional

FinePixViewer starts up automatically.

AC-5VC

USB cable (mini-B)
