FujiFilm X-H2 Manuale del proprietario
Manual (Network and USB Settings)
New Features Guide
Version 2.00
Features added or changed as a result of rmware updates may no
longer match the descriptions in the original documentation for this
product. Visit our website for information on the updates available
for dierent products:
https://fujifilm-x.com/support/download/firmware/cameras/
BL00005295-200 EN
Contents
X-H2 rmware version 2.00 adds or updates the features
listed below. For the latest manuals, visit the following
website.
https://fujifilm-dsc.com/en/manual/
No. Description X-H2
P
See
PVer.
1
1
Photos and movies can now be uploaded to Frame.io.
A Frame.io Camera to Cloud item has been added to the
network/USB settings menu for this purpose.
viii
3
4
29
76
79
88
1
2
3
5
16
19
20
2.00
2
2
A Bluetooth DEVICE LIST item has been added to
Bluetooth/SMARTPHONE SETTING in the network/USB
setting menu.
73 21 1.20
1
Changes and Additions
Changes and additions are as follows.
X-H2 Manual (Network and USB Settings): Pviii
The FT-XH File Transmitter (Available Separately) Ver. 2.00
• When an optional FT-XH le transmitter is attached, you can:
- take photographs remotely via wired or wireless LAN (teth-
ered photography),*
- upload les to Frame.io via wired or wireless LAN or using
the USB tethering feature on a smartphone or tablet,
- upload pictures to an FTP server via wired or wireless LAN us-
ing the USB tethering feature on a smartphone or tablet, and
- lm movies remotely while using a web browser to control
the camera (or multiple cameras, each with its own wireless
transmitter attached) from a computer, smartphone, or tab-
let.
* The FT-XH le transmitter supports 2×2 MIMO wireless LAN for
transmission speeds faster than are available with the camera
alone.
• Menu items marked with an ficon are available when a le
transmitter is attached.
• A list of the cameras that support le transmitters is available
from the website below. Consult the camera manual for infor-
mation on such topics as attaching le transmitters.
https://fujifilm-dsc.com/en/manual/
2
X-H2 Manual (Network and USB Settings): P3
Supported Features Ver. 2.00
Features Available When an Optional FT-XH File Transmitter Is Attached
Feature
Feature
Description
Description
Tethered photography
Tethered photography
Take pictures from a computer to which the camera is
connected (“tethered”) via high-speed wireless LAN or
USB.
Upload to Frame.io
Upload to Frame.io Upload files to Frame.io.
FTP upload
FTP upload Upload files to an FTP server.
Remote movie
Remote movie
recording
recording
Control the camera and take pictures remotely using a
web browser on a computer or tablet.
With the exception of upload to Frame.io, these features can
be accessed by selecting a connection setting prole to which
the desired settings and connection type have been saved us-
ing CREATE/EDIT CONNECTION SETTING. Settings for upload to
Frame.io can be accessed via the network/USB settings menu.
O• Access to the network/USB features in only available when a battery
is inserted in the camera and at least one battery is inserted in the
transmitter.
• If the le transmitter battery runs low while the transmitter is in use,
upload and remote (“tethered”) photography will continue—albeit
at reduced speeds—powered by the camera battery. Charge the le
transmitter battery or insert a fully-charged battery.
3
X-H2 Manual (Network and USB Settings): P4
The File Transmitter Indicator Lamp Ver. 2.00
The le transmitter indicator lamp shows
the status of its connection to comput-
ers, Frame.io, FTP servers, and the like.
NOnly the left lamp lights or ashes.
Indicator lamp
Indicator lamp
Connection status
Connection status
Blinks red No network connection.
Glows red No network connection; pictures awaiting upload.
Blinks orange Connected to network but not to computer teth-
ered photography software, Frame.io, or FTP server.
Blinks orange and red
Connected to network but not to computer teth-
ered photography software, Frame.io, or FTP server;
pictures awaiting upload.
Blinks green
Ready for tethered photography, upload to Frame.io,
or FTP upload.
Blinks green and red Ready for tethered photography, upload to
Frame.io, or FTP upload; pictures awaiting upload.
4
The EVF/LCD Displays
The status of the connection to computers,
Frame.io, FTP servers, and the like is also shown
by an icon in the electronic viewnder or LCD
monitor.
Icon
Icon
Connection status
Connection status
No network connection.
Connected to network but not to computer teth-
ered photography software, Frame.io, or FTP server.
Ready for tethered photography, FTP upload, or
upload to Frame.io.
5
X-H2 Manual (Network and USB Settings): P29
Uploading Files to Frame.io Ver. 2.00
Upload les to Frame.io.
• Connecting via Wireless LAN (P5)
• Connecting via Wired LAN (Ethernet) (P7)
• Connecting via USB Tethering (P9)
NConrm that the camera clock is set to the correct time and date be-
fore proceeding.
Connecting via Wireless LAN
Connect to Frame.io via wireless LAN.
1
Select Frame.io Camera to Cloud>
CONNECT.
NETWORK
Frame.io
PROJECT
USER
NOT CONNECTED
UPLOAD STATUS
UPLOAD SETTING
SELECT FILE TYPE
DISCONNECT
CONNECT
Frame.io Camera to Cloud
2 Select WIRELESS LAN.
NETWORK
Frame.io
PROJECT
USER
NOT CONNECTED
GET PAIRING CODE
USB SMARTPHONE TETHERING
WIRED LAN
WIRELESS LAN
CONNECT
3 Select ACCESS POINT SETTING.
Select IP ADDRESS SETTING to
choose the IP address manually as
described in “Connecting Using an IP
Address” (P11).
FINISH
IP ADDRESS SETTING
ACCESS POINT SETTING
WIRELESS LAN
6
4 Select SIMPLE SETUP.
NTo select a wireless LAN router or en-
ter the router SSID manually, choose
MANUAL SETUP.
SET UP CONNECTION TO
DESTINATION PC
(SIMPLE BUTTON OPERATION)
SIMPLE SETUP
MANUAL SETUP
ACCESS POINT SETTING
5 Follow the on-screen instructions to
ready the wireless LAN router.
NYou also have the option of connect-
ing using a PIN. Display the camera
PIN by pressing the focus stick (focus
lever) up and enter it on the wireless
LAN router.
SIMPLE SETUP
PUSH WPS BUTTON ON
Wi-Fi ROUTER UNTIL LAMP ON
Wi-Fi ROUTER STARTS FLASHING
CANCEL
CONNECT BY PIN CODE
6 Press MENU/OK when setup is com-
plete.
SIMPLE SETUP
REGISTRATION COMPLETED
END
7 Once connected, select GET PAIRING
CODE.
A pairing code will be displayed.
AAAAAA003
WIRELESS LAN
SUCCESS
GO TO Frame.io AND
ENTER PAIRING CODE TO CONNECT
GET PAIRING CODE
CHANGE NETWORK
FINISH
8 Sign in to Frame.io from a computer or other device and en-
ter the pairing code displayed on the camera.
9 Upload les to Frame.io (
P13
).
7
Connecting via Wired LAN (Ethernet)
Connect to Frame.io via wired LAN (Ethernet).
1 Connect to the wired LAN by plugging an Ethernet cable into
the le transmitter’s LAN connector.
2
Select Frame.io Camera to Cloud>
CONNECT.
NETWORK
Frame.io
PROJECT
USER
NOT CONNECTED
UPLOAD STATUS
UPLOAD SETTING
SELECT FILE TYPE
DISCONNECT
CONNECT
Frame.io Camera to Cloud
3 Select WIRED LAN.
NETWORK
Frame.io
PROJECT
USER
NOT CONNECTED
GET PAIRING CODE
USB SMARTPHONE TETHERING
WIRED LAN
WIRELESS LAN
CONNECT
4 Adjust IP ADDRESS SETTING.
•
Select AUTO to use an IP address as-
signed by the network.
•
Select MANUAL to choose the IP
address manually as described in
“Connecting Using an IP Address”
(P11).
IP ADDRESS SETTING
IP ADDRESS SETTING
FINISH
5 Once connected, select GET PAIRING
CODE.
A pairing code will be displayed.
AAAAAA003
WIRED LAN
SUCCESS
GO TO Frame.io AND
ENTER PAIRING CODE TO CONNECT
GET PAIRING CODE
CHANGE NETWORK
FINISH
