Issue April 2007

AMILO Pro V3505 Edition

Your gateway to

professional mobile working Pages 3

The AMILO Pro V3505 is a versatile all-round notebook, equally suitable for occasional or professional users, and

heavy-duty operation by mobile field sales people.

This professional notebook features a superb 15.4-inch WXGA display, an ergonomic keyboard and a built-in DVD

writer drive. Modem and LAN are integrated for easier connection, courtesy of the latest Intel®CentrinoTM Duo Mobile

Technology. It has great connections; four USB ports and an integrated 3in1 Card Reader. Connect to printers,

scanners, cameras or any other accessory.

Elegance

Designed for the most demanding mobile users,

AMILO Pro is the perfect synthesis of form, function

and style.

Power-saving Intel®CentrinoTM Duo Mobile

Technology for long independent working

Increased productivity due to latest Intel 945GM

chipset which supports new technology standards:

DDR2 memory, PCI Express and S-ATA

Ergonomics

Enjoy the viewing quality of brilliant 15.4-inch

TFT display

Convenient working with full sized keyboard

Connectivity

Ideal connectivity through WLAN.

Antennas are integrated for best signal reception.

Variety of interfaces for best connection to the

peripherals

Reliability

Germany‘s quality standard

Award-winning best-in-class manufacturing

Mechanical and function stability through extensive

quality tests

Short reaction and transportation time

Data Sheet ⏐Issue: April 2007⏐AMILO Pro V3505 Page 2 / 3

System AMILO Pro V3505 Edition

Processor

Intel® Core™ Duo Processor up to T2450 (2.00 GHz)

Second level cache 2048 KB

Front side bus (FSB) 533 MHz

Intel® Core2™ Duo Processor up to T7200 (2.00 GHz)

Second level cache 4096 KB

Front side bus (FSB) 667 MHz

Chipset

Northbridge Intel 945GM

Southbridge ICH 7-M

Memory

DIMM slots (533, 667 MHz support) 2

DDR2-533 SDRAM, 533 MHz up to 2 GB

BIOS

BIOS Flash EPROM Phoenix First BIOS

Interfaces

Type I/II PC Card slot 1

3in1 Card Reader (SD, MMC and memory stick) 1

USB 2.0 4

S-Video out (TV-out) 1

VGA 1

Modem RJ-11 1

LAN RJ-45 1

Audio-in (line-in / microphone) 1

Audio-out (line-out / headphone) 1

DC-in 1

Kensington Lock 1

Port Replicator interfaces (optional):

Modem on board

56K V.92 modem MDC1.5 x

LAN on board

built-in 10/100/1000 Mbps Marvell 88E8055 x

Wireless Technologies (WLAN)

Import and usage according to country-specific regulations.

Dual band antenna

Intel PRO/Wireless 3945 a/b/g x

Bluetooth

Bluetooth V2.0 x

Audio

Stereo speakers x

Sound chip RealTek ALC861

Internal microphone x

Keyboard and pointing device

Keyboard 85 keys, 19mm pitch 2.5mm key stroke

Touchpad with two mouse buttons

Status LED x

Graphics

Intel GMA 950 with 256-bit graphics core with dynamic video memory

technology up to 128MB, 32-bit color depth x

Direct X9 x

Pixelshader 2.0 x

DualView (Windows XP) x

Display

15.4-inch TFT WXGA / 1280 x 800 pixel x

Max. resolution for external displays 1600 x 1200 / true color / 85 Hz (tbc.)

Hard disk drives (internal) *

S.M.A.R.T. x

120 GB S-ATA 150 (5400 rpm) x

* 1 Gbyte equals one billion bytes, when referring to hard disk drive

capacity; accessible capacity may vary, also depending on used software

and tool.

** for made4you customizing projects only

Modular Drives

Fixed drives

Super Multi DVD writer (incl DVD RAM, 8x double layer support) x

More information in specific Data Sheet:

http://www.fujitsu-siemens.com/optical_drives/

Manageability

DeskUpdate x

Driver Management x

Supported Standard

WMI / CIM / WBEM -

PXE x

Security

Physical security

Kensington Lock support x

System Security

Norton Internet Security Symantec x

User Security

Integrated Security Panel with PIN code -

User and supervisor BIOS password x

SystemLock BIOS SmartCard security -

Hard disk password x

* for made4you customizing projects only

Data Sheet ⏐Issue: April 2007⏐AMILO Pro V3505 Page 3 / 3

All rights, including rights created by patent grant or registration of a utility model or design as well

as rights of technical modifications are reserved. Delivery subject to availability. Designations may

be trademarks, the use of which by third parties for their own purposes may violate the rights of the

trademark owners.

Published by

Fujitsu Siemens Computers

http://www.fujitsu-siemens.com/

Company stamp

Power supply

1st Li-Ion battery 6 cell 4400 mAH (48 Wh) x

10.8V or 11.1V

First battery * (Mobile Mark 2002) [up to] 4 h

AC adapter 19V/65W Adapter

Rated voltage (AC input) 100 - 240 V

Rated frequency 50 - 60 Hz

DC output 19 V, 3.42 A

AC adapter 20V/65W Adapter

Rated voltage (AC input) 100 - 240 V

Rated frequency 50 - 60 Hz

DC output 20 V, 3.25 A

Dynamic charge supported (rapid charge) x

* Battery life may vary depending on product model, configuration,

applications, power management settings and features utilized. Battery

recharge time depends on usage.

** for made4you customizing projects only

Operating temperatures

Relative humidity (non-condensing) 20% - 85%

Ambient temperature 5° - 35° C

Dimensions / Weight

Dimensions (H x W x D) 34~45 x 360 x 260 mm

Weight* 2.75 kg

* Weight may vary depending on actual configuration

Certificates

CE according to EU Directives 89/336/EEC (EMC)

73/23/EEC (Product safety) x

CE according to 99/5/EEC (R&TTE) x

CE! (Wireless) x (with integrated WLAN)

CE (Emission/Immunity) x

R&TTE x

UL/cUL x

CB Generic Report x

CB (Safety) x

RoHS x

WHQL x

TBR21 x

Energy Star x

Operating System

Microsoft Windows XP Professional x

Microsoft Windows Vista™ x

Software (compatibility / preinstalled)

Adobe Acrobat Reader x

Driver and Utility DVD (DUDVD) x

Easy Guide on-line user documentation x

Nero x

Norton Internet Security (incl. Firewall) on DUDVD (for Windows XP only) x

Bluetooth Toshiba Stack 4.x x

WindDVD 7 (for Windows XP only) S26361-F2598-L20

Accessories (order number)

AC-adapter S26391-F321-L100

Case Value case

S26391-F119-L50

Port Replicator S26391-F6007-L100

Battery S26391-F400-L400 (6 cells)

Modem adapter set 1: D, UK

Modem adapter set 2: SW, NO, FI, DK

Modem adapter set 3: CH, A, B, NL, F, I, E, POR

S26361-F3145-L10

S26361-F3145-L20

S26361-F3145-L30

http://www.fujitsu-siemens.com/accessories/

This Data Sheet describes the highest configurations. The product is offered in fixed configurations which vary from country to country and edition to edition.
