Fujitsu Siemens Computers SCALEOVIEW L17-6 Manuale utente

Monitor

Erste Schritte / Getting Started

Deutsch, English, Français,

Español, Português,

Italiano, Svenska,

Nederlands, Dansk, Suomi,

Pycckий, Norsk, Eesti keel,

Ελληνικά, Lietuviškas,

Latviski, Polski, Slovensko,

Slovenský, Česky, Magyar

SCALEOVIEW

L17-6

Sie haben ...

... technische Fragen oder Probleme?

Wenden Sie sich bitte an

unseren Help Desk (siehe Garantieheft).

Aktuelle Informationen zu unseren Produkten, Tipps, Updates usw. finden Sie im Internet:

http://www.fujitsu-siemens.com

Are there ...

... any technical problems or other questions you need clarified?

Please contact

our Help Desk (see Warranty Booklet).

The latest information on our products, tips, updates, etc., can be found on the Internet under:

http://www.fujitsu-siemens.com

SCALEOVIEW L17-6

⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯

Technical data

Dimensions and weight (LCD monitor)

Visible diagonals: 43 cm (17”)

Screen size : 338 mm x 270 mm

Dimensions (W x H x D)

incl. monitor base : 377 mm x 392 mm x 170 mm

Dimensions box (W x H x D): 421 mm x 424 mm x 152 mm

Weight : approx. 4,9 kg

Dot pitch : 0,264 mm

Maximal resolution : 1280 x 1024 pixels

Electrical data

Video: analogue, positiv, 0.7 Vpp, 75 Ω; digital, DVI-D

Synchronisation : Seperate Synch. TTL, positive or negative

Horizontal frequency: 30 kHz …. 81 kHz

Refresh rate: 55 Hz …. 76 Hz

Maximum pixel rate: 135 MHz

Power supply: switches automatically

100 V – 240 V, 50 Hz – 60 Hz, 0.9 A max.

Total power consumption: < 45 W

< 2 W in the energy-saving modes

(standby mode, suspend mode)

< 1 W in the off mode

Environmental conditions

Environment class 3K2, IEC 721

Operating range: 5 °C …. 35°C

umidity: 20 % …. 85 %

Condensation must be avoided.

Preset operating modes

The picture position and size have been set set to optimum values at the factory for the

operating modes listed above.

Horizontal frequency Refresh rate Display resolution

31.5 kHz

37.5 kHz

37.9 kHz

46.9 kHz

48.4 kHz

60.0 kHz

64.0 kHz

79.9 kHz

70 Hz

60 Hz

75 Hz

60 Hz

75 Hz

60 Hz

75 Hz

60 Hz

75 Hz

720 x 400

640 x 480

800 x 600

1024 x 768

1280 x 1024

Dieses Handbuch wurde erstellt von

cognitas. Gesellschaft für Technik-Dokumentation mbH – www.cognitas.de

Herausgegeben von/Published by

Fujitsu Siemens Computers GmbH

Printed in Taiwan

AG 0107 01/07

Ausgabe/Edition 1

Bestell-Nr./Order No.: A26361-K1169-Z200-1-M119

Edition 1

Deutsch

Magyar

SCALEOVIEW

L17-6

Erste Schritte

Getting Started

Русский

English

TCO

Norsk

Français

WEEE

Eesti keeles

Español

Ελληνικά

Português

Lietuviškas

Italiano

Latviski

Svenska

Polski

Nederlands

Slovensko

Dansk

Slovenský

Suomi

Česky

Ausgabe Januar 2007

January 2007 edition

VESA, DDC und DPMS sind eingetragene Warenzeichen der Video Electronics Standards

Association.

Nachdrucks, der Wiedergabe durch Kopieren oder ähnliche Verfahren.

Zuwiderhandlungen verpflichten zu Schadenersatz.

Liefermöglichkeiten und technische Änderungen vorbehalten.

Keine Haftung für Inhalt und Druckfehler.

VESA, DDC and DPMS are registered trademarks of Video Electronics Standards

Association.

All rights, including rights of translation, reproduction by printing, copying or similar methods,

even of parts are reserved.

Offenders will be liable for damages.

All rights, including rights created by patent grant or registration of a utility model or design,

are reserved.

Delivery subject to availability. Right of technical modification reserved.

edition 1 English

Contents

Introduction........................................................................................................................................... 1

Additional information................................................................................................................... 1

Important notes..................................................................................................................................... 2

Safety notes.................................................................................................................................. 2

Power cable.................................................................................................................................. 3

Transport ...................................................................................................................................... 3

Cleaning ....................................................................................................................................... 4

CE marking................................................................................................................................... 4

Checking the contents of the consignment........................................................................................... 4

Connecting the monitor ........................................................................................................................ 5

Operation of the monitor....................................................................................................................... 6

Troubleshooting.................................................................................................................................... 7

Assembling the monitor base ............................................................................................................... 9
