DATASHEET FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK

Page 1 / 6 http://ts.fujitsu.com/mobile

DATASHEET

FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK

SMALL SIZE, BIG BUSINESS

ESPRIMO MOBILE U9210

You are frequently “on the road”? Travelling from city to city, from one meeting to the next? Then the

ESPRIMO Mobile U series is exactly the right travel companion for you. This small solid notebook ESPRIMO

Mobile U9210 with WXGA display in 30.7 cm (12.1-inch) format and the latest Intel®Centrino®dual

processor technology enables you to access all your relevant business data wherever you are. It is the

perfect combination: small in size, long battery life and unlimited connectivity. With its new clear-line

design the ESPRIMO Mobile U ts perfectly into your ofce environment.

A SMALL NOTEBOOK TO MEET BIG CHALLENGES

Compact notebook containing all the latest state-of-the-art components

30.7 cm (12.1-inch) WXGA display Intel®Centrino®dual processor technology

UNLIMITED MOBILITY

High performance and unrestricted connectivity enables constant data access and maximum productivity.

Intel®Centrino®dual processor technology, 3G/UMTS, WLAN, Bluetooth, optional integrated ConfCam

EXTREME RELIABILITY

Stable housing and innovative functions, built to meet the highest requirements.

ShockSensor, spill-proof keyboard, robust magnesium cover and housing

GREAT FLEXIBILITY

The family concept offers standardized accessory components for the ESPRIMO Mobile U, M, D, X series.

Standardized port replicator, power supply unit and modular bay for optical drive, second battery,

second hard disk or ExpressCard

MAXIMUM SECURITY

Protect your company data against unauthorized third-party access.

Computrace®enabled BIOS, integrated SmartCard reader, optional TPM module and SmartCase

Logon+

BEST CONNECTIVITY

FAMILY CONCEPT

CONFCAM

DATASHEET FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK

Page 2 / 6 http://ts.fujitsu.com/mobile

COMPONENTS

PROCESSOR Intel®Core™2 Duo processor T9600 (2.8 GHz, 6 MB, 1066 MHz)

Intel®Core™2 Duo processor P8800 (2.66 GHz, 3 MB, 1066 MHz)

Intel®Core™2 Duo processor P8700 (2.53 GHz, 3 MB, 1066 MHz)

Intel®Celeron®processor 585 (2.16 GHz, 1 MB, 667 MHz)

MEMORY MODULES 1 GB (1 module(s) 1 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM

2 GB (1 module(s) 2 GB) DDR3, 1066 MHz, PC3-8500, SO DIMM

Supported capacity RAM (max.) 4 GB

Memory slots total 2

Memory slot type DIMM (DDR3)

Memory notes 8 GB - with future memory modules.

HARD DISK DRIVES (INTERNAL) 320 GB, 7200 rpm, SATA, 2.5-inch S.M.A.R.T.

320 GB, 5400 rpm, SATA, 2.5-inch S.M.A.R.T.

320 GB, 5400 rpm, FDE-4, 2.5-inch S.M.A.R.T.

160 GB, 7200 rpm, SATA, 2.5-inch S.M.A.R.T.

160 GB, 5400 rpm, SATA, 2.5-inch S.M.A.R.T.

Hard disk notes ShockSensor for HDD shock protection

One Gigabyte equals one billion bytes, when referring to hard disk drive capacity.

Accessible capacity may vary, also depending on used software

WLAN (OPTIONAL) Atheros Minicard b/g 802.11 b/g

Intel®Wireless WiFi Link 5300 AGN 11/13ch

WIRELESS TECHNOLOGIES

Antennas 3 Dual band WLAN antennas, 2 UMTS antennas

WLAN notes Import and usage according to country-specic regulations.

UMTS/HSUPA (OPTIONAL) Option UMTS GTM 382 (downlink 7.2 Mbit/s, uplink 2.0 Mbit/s)

BLUETOOTH (OPTIONAL) Bluetooth 2.1

DISPLAY

Base unit name ESPRIMO Mobile U9210

Display 30.7 cm (12.1-inch); TFT; (WXGA); anti-glare display; 1280 x 800 pixel

MODULAR BAY OPTIONS 2nd battery

2nd hard disk drive

DVD Super Multi

Weight saver

Base unit ESPRIMO Mobile U9210

GENERAL SYSTEM INFORMATION

Chipset Intel®GM45, ICH 9-M

Intel platform Intel®Centrino®technology

BIOS features BIOS based on Phoenix TrustedCore Notebook

GRAPHICS

Max. resolution external display 1920 x 1200 / true color / 60 Hz

Graphics brand name Mobile Intel®GMA 4500M HD

Graphics features DualView (Windows®XP & Windows®Vista)

INTERFACES

Memory card slots 1 (SD/MMC/MS/MSPro/XD)

ExpressCard slots Optional in bay module

SIM card slot 1

Modem (RJ-11) Optional

DATASHEET FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK

Page 3 / 6 http://ts.fujitsu.com/mobile

INTERFACES

USB 2.0 total 3 (2x USB 2.0, 1x eSATA & USB port)

VGA 1

Ethernet (RJ-45) 1

DC-in 1

Audio: line-in / microphone 1

Audio: line-out / headphone 1

Internal microphones 2

Docking connector for Port Replicator 1

Kensington Lock support 1

WIRED COMMUNICATION

Modem type Optional: 56 K V.92 modem MDC1.5

LAN Built-in 10/100/1000 MBit/s Intel®82567 LF

KEYBOARD AND POINTING DEVICES

Spill-resistant keyboard

Number of keyboard keys: 86, Keyboard pitch: 19 mm, Keyboard stroke: 2.7 mm

Touchpad with two mouse buttons

Application buttons

INPUT DEVICES (OPTIONAL) Optional: TouchStick

MULTIMEDIA

Audio type On board

Audio codec Realtek ALC262

Audio features Stereo speakers, Internal microphone (array)

Camera Optional: Built-in webcam, 1.3 megapixel, VGA camera

POWER SUPPLY

AC adapter 20 V / 90 W (4.5 A)

Rated voltage range 100 - 240 V (AC Input)

Rated frequency range 50 - 60 Hz

1st battery Li-Ion battery 6-cell, 5200 mAh, 57 Wh

2nd battery (optional) Optional: Li-Ion battery 6-cell, 3800 mAh, 40 Wh

Battery features Dynamic charge supported (rapid charge)

Runtime 1st battery up to 6 h

Runtime 1st + 2nd battery up to 10 h

Battery notes Battery life may vary depending on product model, conguration, applications, power management settings and features

utilized. Battery recharge time depends on usage.

POWER CONSUMPTION

Power consumption note See white paper Energy Consumption

Link to Energy White Paper http://docs.ts.fujitsu.com/dl.aspx?id=fbb0bd8b-cef6-4312-9f34-57e0e79181aa

DIMENSIONS / WEIGHT / ENVIRONMENTAL

Dimensions (W x D x H) 300 x 229 x 36.5 mm

Weight 1.95 kg

Weight notes Actual weight may vary depending on conguration

Operating ambient temperature 5 - 35°C

Operating relative humidity 20 - 85 % (running)

OPERATING SYSTEM

Operating system optional preinstalled Microsoft®Windows®7 Professional 32-bit

Microsoft®Windows Vista®Business 32-bit

Microsoft®Windows Vista®Home Basic 32-bit

TwinLoad Microsoft®Windows®XP Professional (DVD)

Operating system compatible Microsoft®Windows®XP Professional

Operating system notes Driver support for Microsoft®Windows®XP

DATASHEET FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK

Page 4 / 6 http://ts.fujitsu.com/mobile

ADDITIONAL SOFTWARE

Additional software (preinstalled) Adobe Acrobat Reader

Camera

EasyGuide online user documentation

Nero Essentials (burning software)

Norton Internet Security (incl. Firewall) on Drivers & Utilities DVD for Microsoft Windows XP

Drivers & Utilities DVD (DUDVD)

Toshiba Bluetooth Stack (only with Windows Vista®or Windows®XP operating systems)

Mobile Software Suite:

Application Button Utility

Wireless Selector Utility

ShockSensor Utility

Fan Control Utility

Power Saving Utility

Additional software (optional) Windows Vista®recovery media

Drivers & Utilities DVD (DUDVD)

UMTS connection manager (optional with UMTS)

DVD playback software

MANAGEABILITY

Manageability features DeskUpdate Driver management

DeskView Migrate (optional)

DeskView Control (optional)

Manageability type DeskView 10.x client management including:

DeskView features On/Ofine remote client management

Detailed system inventory management and reports

BIOS Management

Remote power management

System notications

Security Remote Control

DeskView Helpdesk Integration

WoL (Wake on LAN)

Supported standards PXE

BootP (made4you)

WMI

Manageability link http://ts.fujitsu.com/solutions/it_infrastructure_solutions/manageability/featurender.html

SECURITY

Physical security Kensington Lock support

System security Optional: Trusted platform module (TPM 1.2)

Symantec Norton Internet Security (90 day test version)

User security Hard disk password

User and supervisor BIOS password

Separate SmartCard slot

SystemLock 2 BIOS SmartCard Security

COMPLIANCE

Germany GS

Europe CE

CE!

Nordic Swan

USA/Canada FCC Class B (depending on wireless conguration)

cUL

Global RoHS (Restriction of hazardous substances)

WEEE (Waste electrical and electronical equipment)

ENERGY STAR®5.0

Microsoft Operating Systems (HCT / HCL entry / WHQL)

WiFi certied

Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx

PORTREPLICATOR INTERFACES (OPTIONAL)

DC-in 1

Power on switch 1

DATASHEET FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK

Page 5 / 6 http://ts.fujitsu.com/mobile

PORTREPLICATOR INTERFACES (OPTIONAL)

Audio: headphone 1

Audio: microphone 1

USB 2.0 total 4

VGA 1

DVI 1, DVI-D single link, maximal resolution 1920 x 1200 pixel (WUXGA)

Serial (RS-232) 1

Mouse / Keyboard (PS/2) 1

Ethernet (RJ-45) 1

Parallel 1

Kensington Lock support 2

eSATA 1

RECOMMENDED ACCESSORIES

AC Adapter S26391-F740-L100

1st battery S26391-F746-L500

2nd battery S26391-F746-L100

Memory (2GB) S26391-F736-L200

2nd hard disk S26391-F727-L300

S26391-F728-L300

DVD super Multi S26391-F725-L200

Port replicator S26391-F740-L500

Port replicator / AC adapter / cable kit S26391-F740-L2001 (EU cable)

S26391-F740-L3002 (UK cable)

Recommended cases S26391-F119-L50

S26391-F119-L73

WARRANTY

Standard Warranty 1 year

Service level Collect & Return Service / Bring-In Service (depending on country)

MAINTENANCE AND SUPPORT SERVICES - THE PERFECT EXTENSION

Recommended Service 3 years, On-site Service

Spare Parts availability 5 years

Service Weblink htttp://ts.fujitsu.com/Supportservice

DATASHEET FUJITSU ESPRIMO MOBILE U9210 NOTEBOOK

Page 6 / 6 http://ts.fujitsu.com/mobile

CONTACT

FUJITSU Technology Solutions

Website: http://ts.fujitsu.com

2010-01-25 CE-EN

FUJITSU PLATFORM SOLUTIONS

In addition to Fujitsu ESPRIMO Mobile U9210,

Fujitsu provides a range of platform solutions.

They combine reliable Fujitsu products with

the best in services, know-how and worldwide

partnerships.

Dynamic Infrastructures

With the Fujitsu Dynamic Infrastructures

approach,Fujitsu offers a full portfolio of IT

products, solutions and services, ranging

from clients to datacenter solutions, Managed

Infrastructure and Infrastructureas-a-Service.

How much you benet from Fujitsu technologies

and services depends on the level of cooperation

you choose. This takes IT exibility and efciency

to the next level.

Computing Products

www.fujitsu.com/global/services/computing/

Software

www.fujitsu.com/software/

MORE INFORMATION

Learn more about Fujitsu ESPRIMO Mobile

U9210, please contact your Fujitsu sales

representative or Fujitsu Business partner, or

visit our website.

http://ts.fujitsu.com/mobile

FUJITSU GREEN POLICY INNOVATION

Fujitsu Green Policy Innovation is our worldwide

project for reducing burdens on the environment.

Using our global know-how, we aim to resolve

issues of environmental energy efciency

through IT.

Please nd further information at http://www.

fujitsu.com/global/about/environment/

COPYRIGHTS

rights. Changes to technical data reserved.

Delivery subject to availability. Any liability that

the data and illustrations are complete, actual or

correct is excluded.

Designations may be trademarks and/or

copyrights of the respective manufacturer,

the use of which by third parties for their own

purposes may infringe the rights of such owner.

For further information see http://ts.fujitsu.com/

terms_of_use.html

DISCLAIMER

Technical data are subject to modication and

delivery subject to availability. Any liability that

the data and illustrations are complete, actual

or correct is excluded. Designations may be

trademarks and/or copyrights of the respective

manufacturer, the use of which by third parties

for their own purposes may infringe the rights of

such owner

Indice

Altri manuali Fujitsu Computer portatile

Fujitsu

Fujitsu LIFEBOOK P1010 Manuale utente

Fujitsu

Fujitsu Lifebook LH530 Manuale utente

Fujitsu

Fujitsu LIFEBOOK C1110 Manuale utente

Fujitsu

Fujitsu Lifebook AH530 Manuale utente

Fujitsu

Fujitsu U810 - LifeBook Mini-Notebook - 800 MHz Manuale utente

Fujitsu

Fujitsu Lifebook T580 Manuale utente

Fujitsu

Fujitsu Lifebook E751 Manuale utente

Fujitsu

Fujitsu A6210 - LifeBook - Core 2 Duo 2.26 GHz Manuale utente

Fujitsu

Fujitsu Lifebook P1110 Manuale utente

Fujitsu

Fujitsu LIFEBOOK E547 Manuale utente

Fujitsu

Fujitsu LifeBook V700 Manuale utente

Fujitsu

Fujitsu LifeBook A6025 Manuale utente

Fujitsu

Fujitsu lifebook S6311 Manuale utente

Fujitsu

Fujitsu S7211 - LifeBook - Core 2 Duo GHz Manuale di servizio

Fujitsu

Fujitsu FPCM11383 Scheda informativa del prodotto

Fujitsu

Fujitsu A3210 - LifeBook - Turion 64 X2 2 GHz Manuale

Fujitsu

Fujitsu LifeBook S6000 Manuale utente

Fujitsu

Fujitsu LifeBook P772 Manuale utente

Fujitsu

Fujitsu LifeBook U9312 Manuale utente

Fujitsu

Fujitsu Lifebook S2010 Manuale

Fujitsu

Fujitsu LIFEBOOK U7511 Manuale utente

Fujitsu

Fujitsu S6510 - LifeBook - Core 2 Duo GHz Manuale

Fujitsu

Fujitsu N7010 - LifeBook - Core 2 Duo 2.26 GHz Manuale utente

Fujitsu

Fujitsu LifeBook C-6581 Manuale utente

Manuali Computer portatile popolari di altre marche

HP ze2401xt - Pavilion Notebook PC Manuale utente

Velocity

Velocity NoteMagix M10 Manuale utente

Dell

Dell Alienware 17 R2 Manuale utente

Toshiba

Toshiba A105-S2236 Manuale utente

HP ENVY 17 Manuale

Winbook

Winbook LM Manuale utente

Dell

Dell Inspiron 1464 Manuale utente

Dell

Dell Inspiron 15R 5537 Manuale utente

HP PROBOOK 4520S Manuale

Dell

Dell Latitude ATG D620 Manuale utente

Sony

Sony VAIO PCG-FX270 Manuale utente

Dell

Dell Latitude 7310 Manuale utente

Dell

Dell Precision GU806 Manuale utente

Sony

Sony VAIO PCG-R505JLK Manuale utente

Lenovo

Lenovo THINKPAD X32 Manuale utente

HP Compaq tc4200 Guida rapida

Toshiba

Toshiba mini NB300 Manuale utente

Lenovo

Lenovo ThinkPad X201 Tablet Manuale
