Fujitsu FI-5530C2 Guida alla configurazione

BEFORE CLEANING

Open the ADF while pulling the cover open lever

Consumables Part Number

Pad PA03334-0002

Pick Roller PA03334-0001

Cleaning Materials SC-CLE-KIT1

1Pad Assy

Wipe downwards. When cleaning take care to prevent the cloth from catching on the metal parts.

ADF Glass Surfaces x 2

Located on the ADF cover and opposite side. Clean lightly.

Clean lightly taking care not to scratch the surface.

Pick Roller

Clean lightly while rotating with your finger. Take care not to roughen the surface.

Plastic Rollers x 4

Turn the Scanner OFF while cleaning the following locations

It is recommended that these items be

cleaned EVERY 1,000 SCANS

Using cleaning paper moistened with F1 Cleaner

Cleaning Instructions for

fi-5530C2 Image Scanner

Pad Assy

Plastic Rollers

Pick Roller

Feed

Rollers

Glass

Eject Rollers

P.T.O.

ADF Button

Open the ADF only if the Function Number Display is showing “1” through “9”.

Simultaneously hold down the “Send to” and “Scan” buttons on the operator panel.

The Feed and Eject Rollers start to

rotate slowly.

As a guideline, seven presses of the

“Send to” and “Scan” buttons make

the rollers rotate one full turn.

Turn the Scanner ON while cleaning the following locations

Using cleaning paper moistened with F1 Cleaner

For further information please refer to the

fi-5530C2 Image Scanner Operators Guide

which can be found on our Website:

www.fel.fujitsu.com/scanner

September 2007

Cleaning Instructions for fi-5530C2 Image ScannerFujitsu Europe LImited

Pad Assy

Plastic Rollers

Pick Roller

Feed

Rollers

Glass

Eject Rollers

Function Number

Display

Function

Send To

Scan

Power Button

LED

5Clean lightly taking care not to roughen the surface.

Feed Rollers x 2

Clean lightly taking care not to roughen the surface.

Eject Rollers x 2
