Fujitsu ScanSnap iScanner fi-6010N Guida alla configurazione

BEFORE CLEANING

Push the ADF release button, hold both sides of

the top cover and lift open

ADF Cover

ADF Release Button

1Pad Assy

Wipe downwards. When cleaning take care to prevent the cloth from catching on the metal parts.

ADF Glass Surfaces x 2

Located on the ADF cover and opposite side. Clean lightly.

Clean lightly taking care not to scratch the surface.

Pick Roller

Clean lightly.

Ultrasonic Sensor

Turn the Scanner OFF while cleaning the following locations

It is recommended that these items be

cleaned EVERY 1,000 SCANS

Using cleaning paper moistened with F1 Cleaner

Pad Assy

Ultrasonic

Sensor Pick Roller

Feed Rollers

Glass Eject Rollers

P.T.O.

Consumables Part Number

Pad PA03289-0111

Pick Roller PA03289-0001

Cleaning Materials SC-CLE-KIT1

5Clean lightly taking care not to roughen the surface.

Eject Rollers x 2

Cleaning Instructions for

fi-6010N Network ADF Scanner

On the “Main Menu” screen press the “Maintenance”

button. The Maintenance screen appears.

Press “Roller Cleaning” to access this screen

Open the top cover. Clean lightly taking care not to

roughen the surface.

Press the “c” key on the keyboard to advance the feed

rollers. Press seven times for one complete revolution.

6Feed Rollers x 2

Turn the Scanner ON while cleaning the following locations

Using cleaning paper moistened with F1 Cleaner

Version #2 - October 2008

Cleaning Instructions for fi-6010N Network ADF Scanner

Fujitsu Europe LImited 6

Pad Assy

Ultrasonic

Sensor Pick Roller

Feed Rollers

Glass Eject Rollers

For further information please refer to the

fi-6010N Network ADF Scanner Operators Guide

which can be found on our Website:

www.fel.fujitsu.com/scanner

Keyboard

LCD Touch Panel

Touch Panel and Keyboard

The LCD Touch Panel and

Keyboard should be cleaned

with a soft, dry cloth
