Installation Manual

Multi Function Display

MFDBB

SAFETY INSTRUCTIONS............................................................................i

SYSTEM CONFIGURATION.......................................................................ii

EQUIPMENT LISTS....................................................................................iii

1. MOUNTING............................................................................................1

1.1 Mounting the Control Unit.............................................................................................1

1.2 Mounting the Processor Unit ........................................................................................7

2. WIRING..................................................................................................9

2.1 Processor Unit Wiring...................................................................................................9

2.2 Control Unit Wiring .....................................................................................................14

3. SETTING UP THE EQUIPMENT .........................................................15

3.1 Setup for Single MFD in the Network .........................................................................17

3.2 Setup for Multiple MFDs in the Network.....................................................................28

PACKING LISTS......................................................................................A-1

OUTLINE DRAWINGS.............................................................................D-1

INTERCONNECTION DIAGRAM............................................................ S-1

WARNING

Indicates a potentially hazardous situation which, if not avoided,

could result in death or serious injury.

CAUTION

Indicates a potentially hazardous situation which, if not avoided,

may result in minor or moderate injury.

Warning, Caution

Mandatory Action

Prohibitive Action

SAFETY INSTRUCTIONS

The user and installer must read the appropriate safety instructions before attempting to install

or operate the equipment.

WARNING CAUTION

Ground the equipment to prevent

electrical shock and mutual interference.

Observe the following compass safe distances

to prevent interference to a magnetic compass:

ELECTRICAL SHOCK HAZARD

Do not open the equipment unless

totally familiar with electrical circuits.

Only qualified personnel should work

inside the equipment.

Turn off the power at the switchboard

before beginning the installation.

Fire or electrical shock can result if the

power is left on.

Be sure that the power supply is

compatible with the voltage rating of the

equipment.

Connection of an incorrect power supply

can cause fire or damage the equipment.

Standard

compass Steering

compass

MPU-001 1.45 m 0.90 m

MCU-001 0.55 m 0.40 m

DCU12 0.70 m 0.45 m

Use the proper fuse.

Use of an incorrect fuse may damage the equipment.

SYSTEM CONFIGURATION

MONITOR

MU-155C/170C, etc.

VIDEO IN (CCD

CAMERA, MAX. 4)

LINE OUT

(SPKR, ETC.)

12-24 VDC*2

DISPLAY CONTROL

UNIT DCU12

CONTROL UNIT

MCU-001

AND/OR*3

HUB-101

GPS NAVIGATOR

GP-320B/330B

AIS RECEIVER,

HEADING SENSOR or

EXTERNAL BUZZER

USB DEVICE

(MOUSE, KYBD)

NMEA 2000

(SENSOR, ETC.)

POWER SUPPLY UNIT

PSU-013*1

: Standard Supply

: Optional Supply

: Local Supply

*1 Required with DRS25A

*2 See the table and figure below for

configurations for the PSU and rectifiers.

*3 Max. two units

PROCESSOR UNIT

MPU-001

RADAR SENSOR

DRS4A/DRS6A/DRS12A/DRS25A

RADAR SENSOR

DRS2D/DRS4D

FISH FINDER

(DFF series, ETR-6/10N, ETR-30N)

Matrix for radar model, PSU and rectifiers

DRS2D/4D/

4A/6A/12A

MFDBB

RU-1746B-2

DRS25A

MFDBB

PSU-013

DRS25A

MFDBB

PSU-013

Radar

Model PSU Rectifier for

MFDBB Rectifier for

PSU Rectifier for

MFDBB+PSU

DRS2D Not

required RU-1746B-2

DRS4D

DRS4A

DRS6A

DRS12A

DRS25A PSU-013* RU-1746B-2 RU-3424

* Standard supply with DRS25A.

12-24 VDC*2

RU-1746B-2

12-24 VDC2

LINE IN (MIC,

for future use)

DRS25A

DRS4A

DRS6A

DRS12A

RU-1746B-2 RU-3424

JUNCTION

BOX FI-5002

iii

EQUIPMENT LISTS

Standard supply

*See the lists at the back of this manual.

Optional supply

Name Type Code No. Qty Remarks

Processor Unit MPU-001 - 1

Control Unit MCU-001 - 1 Choose one.

Display Control Unit DCU12 - 1

Installation Materials CP19-00600 000-011-664 1 set For MPU-001, Cable, CP19-

00601*

CP19-00700 000-011-663 1 set For MCU-001,

cable, CP19-

00701*

Choose one.

CP19-00800 000-011-662 For DCU12,

cables, CP19-

00801*

Spare Parts SP19-00501 001-023-090 1 set For MPU-001, fuses

SP19-00601 001-023-040 1 set For DCU-001, fuses

Accessories FP19-01201 001-033-760 1 For MCU-001, panel remover

FP19-01101 001-023-060 For DCU12, panel remover

Name Types Code No. Remarks

DVI-D Cable DVI-D/D SINGLELINK 000-149-054-10 5 m

DVI-D/D S-LINK 000-150-200-10 10 m

External Buzzer OP03-136 000-086-443

Rectifier RU-1746B-2 -

Network Hub HUB-101 -

Joint Box TL-CAT-012 000-167-140-10 For LAN cable extension

Junction Box FI-5002 000-010-765 For NMEA 2000

Control Unit MCU-001 -

Display Control

Unit DCU12 -

Cable Assy MJ-A7SPF0007-050C 000-154-028-10 5 m, NMEA0183, w/7P

connector

MJ-A6SPF0016-005C 000-159-689-11 For FAX-30, ETR6N/10N

connection

MOD-Z072-020+ 000-167-175-10 2 m, LAN

MOD-Z072-050+ 000-167-176-10 5 m, LAN

MOD-Z072-100+ 000-167-177-10 10 m, LAN

MOD-Z073-030+ 000-167-171-10 3 m, for PC connection

M12-05BM+05BF-010 000-167-962-10 φ6, 1 m, NMEA 2000

M12-05BM+05BF-020 000-167-963-10 φ6, 2 m, NMEA 2000

M12-05BM+05BF-060 000-167-964-10 φ6, 6 m, NMEA 2000

M12-05BFFM-010 000-167-965-10 φ6, 1 m, NMEA 2000

M12-05BFFM-020 000-167-966-10 φ6, 2 m, NMEA 2000

M12-05BFFM-060 000-167-967-10 φ6, 6 m, NMEA 2000

CB-05PM+05BF-010 000-167-968-10 φ10, 1 m, NMEA 2000

CB-05PM+05BF-020 000-167-969-10 φ10, 2 m, NMEA 2000

CB-05PM+05BF-060 000-167-970-10 φ10, 6 m, NMEA 2000

CB-05BFFM-010 000-167-971-10 φ10, 1 m, NMEA 2000

CB-05BFFM-020 000-167-972-10 φ10, 2 m, NMEA 2000

CB-05BFFM-060 000-167-973-10 φ10, 6 m, NMEA 2000

NMEA connector LTWSS-050505-FMF-

TS001 000-168-603-10 NMEA 2000 distributor

(micro style)

LTWMC-05BMMT-

SL8001 000-168-604-10 NMEA 2000 terminator,

male (micro style)

LTWMC-05BFFT-

SL8001 000-168-605-10 NMEA 2000 terminator,

female (micro style)

LTWNC050505FMF-

TS001 000-160-507-10 NMEA 2000 distributor

(mini style)

LTWMN-05AMMT-

SL8001 000-160-508-10 NMEA 2000 terminator,

male (mini style)

LTWMN-05AFFT-

SL8001 000-160-509-10 NMEA 2000 terminator,

female (mini style)

Operator’s Manual OME-44460 -

NMEA 2000 Inter-

face Unit IF-NMEA2K1 -

Name Types Code No. Remarks

1. MOUNTING

1.1 Mounting the Control Unit

There are two types of control units: Control Unit MCU-001 and Display Control Unit DCU12. The

former is the keyboard type, and the latter has an LCD display and keyboard.

When selecting a mounting location for the control unit, keep the following in mind:

• The temperature and humidity at the mounting location should be moderate and stable.

• Locate the unit away from exhaust pipes and ventilators.

• The mounting location should be well ventilated.

• Mount the unit where shock and vibration are minimal.

• Keep the unit away from electromagnetic field generating equipment such as motors and gen-

erators.

• For maintenance and checking purposes, leave sufficient space at the sides and rear of the unit

and leave slack in cables. Minimum recommended space is shown on the outline drawing for

the control units.

• Do not mount the DCU12 on the overhead.

• A magnetic compass will be affected if the control unit is placed too close to it. Observe the

compass safe distances shown in the SAFETY INSTRUCTIONS to prevent disturbance to the

magnetic compass.

1.1.1 Mounting procedure for control unit MCU-001

The control unit MCU-001 is designed to be flush mounted in a console or panel.

1. Prepare a cutout in the mounting location using the template sheet (supplied) for the MCU-

001.

2. Remove the front panel from the MCU-001 by grasping it at its sides and pulling it towards

you.

3. Attach the mounting sponge to the MCU-001.

4. Fix the MCU-001 by using four self-tapping screws (supplied) .

5. Attach the front panel to the MCU-001.

How to detach the front panel from the mounting place

To detach the front panel after mounting the unit, use the remover (supplied) as below. Do not

attempt to remove it by any other method, to prevent damage to the unit.

1. Set the remover to the left-side notch at the bottom of the unit.

Mounting

sponge

MCU-001

Cutout

Self-tapping screws

(4 pcs.)

Front panel

2. Pull the remover to raise the panel slightly.

3. Similarly use the remover to raise the panel at the right-side notch.

4. Insert the remover to the space at the one end of the unit, and pull it to raise the panel slightly.

Repeat this procedure for the opposite side.

5. Use the remover to raise the panel at the two notches on the upper side of the unit.

6. Use your hands to detach the front panel at both sides of it.

1.1.2 Mounting procedure for display control unit DCU12

The Display Control Unit DCU12 can be flush mounted in a console or panel, or mounted on a

desktop or the overhead.

Flush mounting

1. Prepare a cutout in the mounting location using the template sheet (supplied) for the DCU12.

2. Remove the front panel from the DCU12 by grasping it at its sides and pulling it towards you.

3. Attach the mounting sponge to the DCU12.

4. Fix the DCU12 by using four self-tapping screws (supplied).

5. Attach the front panel to the DCU12.

How to detach the front panel from the mounting place

To detach the front panel after mounting the unit, use the remover (supplied) as below. Note that

the front cover may be damaged if you do not follow the methods below.

1. Set the remover to a notch on the lower side of the unit.

Mounting sponge

Cutout

Front panel

Self-tapping screws

(4 pcs.)

DCU12

2. Pull the remover to raise the panel slightly. Do this for all notches on the lower side of the unit.

3. Insert the remover to the space at the one side of the unit, and pull the remover to raise the

panel slightly. Do the same for the opposite side.

4. Use your hands to detach the front panel from the lower side.
