Baking Instructions
Keep your food frozen until ready to bake. The surface area of the baking
rack is approximately 17" x 17" square so the oven is large enough to
accommodate many types of frozen food including 16" pizza. Place food
onto the baking rack and slide the rack into the oven. Set the OVEN TEMP
dial to the desired temperature and set the TIMER dial to desired bake time.
Note: You must turn the TIMER past the 2 minute mark in order to activate
the oven.
The FUSION COMMERCIAL 16” Deluxe Pizza & Snack Oven offers a HOLD
option that enables you to use the oven without setting the 30 minute
timer. This feature is important during busy times when you don’t want to
take the time to preheat the oven.
Always check your food midway through the baking cycle, rotating if
necessary to ensure even baking.
Operating and Cleaning Guidelines
• The power light on the front of the oven indicates that the oven is
actively heating. The light WILL cycle OFF once the oven reaches the
temperature set by the temperature control and will cycle ON as the
oven may need to heat back up. This is true whether the oven timer is
“counting down” or in the “HOLD” position.
• We do not recommend the use of an extension cord, however if an
extension cord is required caution is necessary. The cord must be 14
gauge and have a minimum electrical rating of 120 volts and 15 amps.
The electrical rating will be marked on the cord. Make sure the cord is
arranged so people can not accidentally pull or trip over it.
• If the electric circuit is overloaded, the circuit breaker will trip and
your pizza oven will not operate. Make sure your outlet has a 20 amp
electrical circuit and separate from other appliances.
• To operate oven, firmly hold handle and remove food rack. Place food
in center of the rack. Return loaded food rack to oven, set OVEN TEMP
and TIMER to desired settings. Your oven will automatically shut off
when the baking cycle is completed.
• Remove the food rack slowly from the oven to insure that food does not
slide off the rack onto the heating elements.
• When finished baking, remove plug from wall socket and allow to cool
before cleaning.
• To clean the outside of oven, wipe with damp cloth and dry thoroughly.
• To clean the crumb tray, remove and rinse with warm soapy water, wipe
with damp cloth and dry thoroughly before placing back into the oven.
• Use caution when cleaning as the fabrication nature of this
oven may present some sharp edges on the crumb tray and
surrounding openings to the oven.
To keep your oven clean and ready to use at all times, simply
remove the crumb tray at the end of each use and wipe clean.
Proper cleaning and maintenance will reduce the risk of food
accumulation that may create smoke caused by carbon build up.
One Year Limited Warranty
Tomlinson guarantees to the original purchaser of each Tomlinson Fusion
Commercial 515FC 16" Deluxe Pizza and Snack Oven that any part thereof
which proves to be defective in material or workmanship within one year of
the date of shipment will be repaired or a replacement part furnished F.O.B.
our factory. Warranty will not apply if our examination shows oven to be
defective as the result of negligence, abuse, misapplication or alteration by
other than ourselves. Tomlinson will not be responsible for unauthorized
field service. Contact factory at 1-800-945-4589 ext. 112 for instructions.
To register your product and activate the warranty, go to
www.tomlinsonind.com. Click on the SUPPORT tab,
then click on PRODUCT REGISTRATION.
