Future Automation LSM-TU4 Supplemento

Page 1of 5 // email info@futureautomation.co.uk US tel +1(603) 742 9181 Europe tel +44 (0) 1438 833577

LSM-TU4 Family Application Notes

(from v7.5.0)

Contents Page

Features............................................................................................................... 1

Configuring programmable heights................................................................... 2

Controlling the Mechanism ................................................................................ 4

User operation.................................................................................................... 4

Programming Mode............................................................................................ 5

Page 2of 5 // email info@futureautomation.co.uk US tel +1(603) 742 9181 Europe tel +44 (0) 1438 833577

Features

Programmable maximum height

3 programmable intermediate heights

Home position (Lift out, telescope retracted)

Configuring programmable heights

1. Apply power.

2. Use the FA remote for the whole of the setup procedure

3. For all commands beginning with [STORE], press each button sequentially with

no more than 2 seconds between each press

4. In order to store programmable heights you must first enter programming mode.

In programming mode the lift then the telescope will move sequentially

a. Press [STORE] [STORE] [PRESET] to enter programming mode.

b. IMPORTANT- The mechanism will start to move out as soon as

[STORE] [STORE] [PRESET] has been keyed in.

c. Once in programming mode the lift will move fully out, followed by the

telescope. Once this has happened the [IN] and [OUT] commands will

only control the telescope.

5. Program the Maximum OUT position (max telescope extension)

a. Position the lift at the correct height using the IN and OUT commands

b. Press [STORE] [OUT] to store the current height as the maximum

extension.

Page 3of 5 // email info@futureautomation.co.uk US tel +1(603) 742 9181 Europe tel +44 (0) 1438 833577

c. Press [STORE] [STOP] [OUT] if you need to clear maximum extension.

IMPORTANT - The telescope shall revert to a maximum extension

located at the physical OUT switch.

d. The MAXIMUM HEIGHT can be verified in programming mode at any time

by pressing [OUT]

6. Program any required intermediate telescope extensions

a. There are 3 intermediate positions available, accessed by the [A], [B] and

[C] commands

b. Position the telescope at the required intermediate position.

c. Press [STORE] [A] to set the current position as position A.

d. Press [STORE] [B] to set the current position as position B.

e. Press [STORE] [C] to set the current position as position C.

f. The programmed position can be verified in programming mode at any

time by pressing [A], [B] or [C] respectively

7. IMPORTANT: To exit programming mode, press [STORE] [STOP] [PRESET].

The telescope and lift shall now return to running together when commanded.

Page 4of 5 // email info@futureautomation.co.uk US tel +1(603) 742 9181 Europe tel +44 (0) 1438 833577

Controlling the Mechanism

RS232 commands are all terminated with carriage return but no line feed. In Crestron this is

represented by \r

IR sequences involving multiple key-presses require each successive key to be pressed within 2

seconds

User operation

RS232

CC Pin (see note

below)

Action

Comments

fa_in

Pin 8

or Pin 5 short removed

Mechanism fully

OUT

fa_out

Pin 7

or Pin 5 shorted

Raise to full

extension

Raises to out switch if no

maximum extension is

configured

HOME

fa_home

Lift raised with the

telescope

retracted

fa_a

Lift raised with the

telescope at

intermediate

position A

fa_b

Lift raised with the

telescope at

intermediate

position B

fa_c

Lift raised with the

telescope at

intermediate

position C

STOP

fa_stop

Pin 6

Stop mechanism

Page 5of 5 // email info@futureautomation.co.uk US tel +1(603) 742 9181 Europe tel +44 (0) 1438 833577

Programming Mode

RS232

CC Pin (see note

below)

Action

Comments

STORE

PRESET

Enter programming

mode

STORE

STOP

PRESET

Exit programming

mode

STORE

OUT

Set maximum

extension

STORE

STOP

OUT

Clear maximum

extension

STORE

Set intermediate

extension A

STORE

Set intermediate

extension B

STORE

Set intermediate

extension C
