Galeo PC600-7 Manuale
SEAM053202T
Operation&Maintenance
Manual
PC600
-7
PC600LC
-7
HYDRAULIC EXCAVATOR
SERIAL NUMBERS PC600-7 20001 and up
PC600LC-7 20001and up
This material is proprietary to Komatsu America Corp. and is not to be reproduced, used, or disclosed except in
accordance with written authorization from Komatsu America Corp..
It is our policy to improve our products whenever it is possible and practical to do so. We reserve the right to make
changes or improvements at any time without incurring any obligation to install such changes on products sold
previously.
Due to this continuous program of research and development, revisions may be made to this publication. It is
recommended that customers contact their distributor for information on the latest revision.
Copyright 2006 Komatsu
Printed in U.S.A.
Komatsu America Corp.
October 2006
1-1
FOREWORD
11
FOREWORD FOREWORD
1-2
FOREWORD 1
This manual provides rules and guidelines which will help you use this machine safely and effectively. The pre-
cautions in this manual must be followed at all times when performing operation and maintenance. Most accidents
are caused by the failure to follow fundamental safety rules for the operation and maintenance of machines. Acci-
dents can be prevented by knowing beforehand conditions that may cause a hazard when performing operation
and maintenance.
WARNING
Operators and maintenance personnel must always do as follows before beginning operation or mainte-
nance.
Always be sure to read and understand this manual thoroughly before performing operation and mainte-
nance.
Read the safety messages given in this manual and the safety labels affixed to the machine thoroughly
and be sure that you understand them fully.
Keep this manual at the storage location for the Operation and Maintenance Manual given below, and have
all personnel read it periodically.
If this manual has been lost or has become dirty and cannot be read, request a replacement manual imme-
diately from Komatsu or your Komatsu distributor.
If you sell the machine, be sure to give this manual to the new owners together with the machine.
Komatsu delivers machines that comply with all applicable regulations and standards of the country to
which it has been shipped. If this machine has been purchased in another country or purchased from
someone in another country, it may lack certain safety devices and specifications that are necessary for
use in your country. If there is any question about whether your product complies with the applicable
standards and regulations of your country, consult Komatsu or your Komatsu distributor before operating
the machine.
Storage location for the Operation and Maintenance Manual:
magazine box on the left side of the operator's seat.
FOREWORD FOREWORD
1-3
FOREWORD FOREWORD
1-4
FOREWORD SAFETY INFORMATION
1-5
SAFETY INFORMATION 1
To enable you to use this machine safely, safety precautions and labels are given in this manual and affixed to the
machine to give explanations of situations involving potential hazards and of the methods of avoiding such situa-
tions.
Signal words
The following signal words are used to inform you that there is a potential hazardous situation that may lead to per-
sonal injury or damage.
In this manual and on machine labels, the following signal words are used to express the potential level of hazard.
Indicates an imminently hazardous situation which, if not avoided, will result in death or seri-
ous injury.
Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
Indicates a potentially hazardous situation which, if not avoided, may result in minor or mod-
erate injury. This word is used also to alert against unsafe practices that may cause prop-
erty damage.
Example of safety message using signal word
WARNING
When standing up from the operator's seat, always place the
lock lever in the LOCK position.
If you accidentally touch the control levers when they are not
locked, this may cause a serious injury or death.
Other signal words
In addition to the above, the following signal words are used to indicate precautions that should be followed to pro-
tect the machine or to give information that is useful to know.
This word is used for precautions that must be taken to avoid actions which could shorten
the life of the machine.
This word is used for information that is useful to know.
SAFETY INFORMATION FOREWORD
1-6
qSafety labels
Safety labels are affixed to the machine to inform the operator or maintenance worker on the spot when carrying
out operation or maintenance of the machine that may involve hazard.
This machine uses "Safety labels using words" and "Safety labels using pictograms" to indicate safety procedures.
Example of safety label using words
Safety labels using pictogram
Safety pictograms use a picture to express a level of hazardous
condition equivalent to the signal word. These safety pictograms
use pictures in order to let the operator or maintenance worker
know the level and type of hazardous condition at all times.
Safety pictograms show the type of hazardous condition at the
top or the left side, and the method to avoid hazardous condition
at the bottom or the right side. The type of hazardous condition is
also displayed inside a triangle.
Komatsu cannot predict every circumstance that might involve a potential hazard in operation and maintenance.
Therefore, the safety messages in this manual and on the machine may not include all possible safety precau-
tions.
If any procedures or actions not specifically recommended or allowed in this manual are used, it is your responsi-
bility to take the necessary steps to ensure safety.
In no event should you engage in prohibited uses or actions described in this manual.
The explanations, values, and illustrations in this manual were prepared based on the latest information available
at that time. Continuing improvements in the design of this machine can lead to changes in detail which may not
be reflected in this manual. Consult Komatsu or your Komatsu distributor for the latest available information of
your machine or for questions regarding information in this manual.
The numbers in circles in the illustrations correspond to the numbers in ( ) in the text. (For example: 1-> (1))
FOREWORD INTRODUCTION
1-7
INTRODUCTION 1
This Komatsu machine is designed to be used mainly for the following work:
qDigging work
qLeveling work
qDitching work
qLoading work
qDemolition work
See the section "RECOMMENDED APPLICATIONS (3-119)" for further details.
DIRECTIONS OF MACHINE 1
In this manual, the terms front, rear, left, and right refer to the travel direction as seen from the operator's seat
when the operator's seat is facing the front and the sprocket is at the rear of the machine.
INTRODUCTION FOREWORD
1-8
BREAKING-IN THE NEW MACHINE 1
NOTICE
Your Komatsu machine has been thoroughly adjusted and tested before shipment from the factory. How-
ever, operating the machine under full load before breaking the machine in can adversely affect the perfor-
mance and shorten the machine life.
Be sure to break in the machine for the initial 100 hours (as indicated on the service meter).
Make sure that you fully understand the content of this manual, and pay careful attention to the following points
when breaking in the machine.
qRun the engine at idling for 15 seconds after starting it. During this time, do not operate the control levers or
fuel control dial.
qIdle the engine for 5 minutes after starting it up.
qAvoid operation with heavy loads or at high speeds.
qImmediately after starting the engine, avoid sudden starts, sudden acceleration, unnecessary sudden stops,
and sudden changes in direction.
FOREWORD PRODUCT INFORMATION
1-9
PRODUCT INFORMATION 1
When requesting service or ordering replacement parts, please inform your Komatsu distributor of the following
items.
PRODUCT IDENTIFICATION NUMBER (PIN)/MACHINE SERIAL NO. PLATE 1
On the front bottom right of the operator's cab (side of upper frame)
The design of the nameplate differs according to the territory.
ENGINE SERIAL NUMBER PLATE AND ITS LOCATION 1
This is at the side of the oil cooler housing on the left side face of the engine cylinder block.
(The EPA restrictions plate is on the top surface of the intake manifold at the front of the chassis.)
EPA: Environmental Protection Agency, U.S.A.
