Gama Sonic Infinity Manuale utente

Introduction

Thank you for your purchase! GAMA SONIC®solar charged accent lighting eliminates

the problems associated with most solar lighting available today. GAMA SONIC®solar

charged lights are brighter and last all night with a typical solar charge. Unique

design, superior light output and numerous installation options confirm the

outstanding value of our product.

GAMA SONIC®has been recognized as a worldwide leader in the lighting industry for

over 20 years.

Technical Assistance/Warranty Claims/Replacement Parts

Toll Free Number: +1-800-835-4113 (only within the US),

Email: [email protected], or

Visit our website to download the latest version of your instruction manual:

www.gamasonic.com or www.gamasonic.com/user-guides

INFINITY SOLAR UP AND DOWN

WALL LIGHT

Instruction Manual

Model: GS-120

Please read the instruction manual carefully to obtain the best results from your

purchase.

NOTE: If you are replacing an existing gas/electric wall light, you must consult a

certified technician to disconnect the current outlet before installation.

Solar Wall Light Location

For optimum light duration throughout the night, it is very important to mount your

solar light in a spot where it will receive the maximum amount of direct sunlight

throughout the day. A minimum of 2 hours of direct sunlight is required for basic

operation.

NOTE: The following steps are for reference only. Consult your local hardware store

for the best installation method for your chosen surface.

Assembly Instructions (Fig. 1):

Step 1:

Remove the wall bracket by unscrewing the two screws on the side of the fixture.

Step 2:

You are ready to mount the light fixture on

the wall.

1. Use a drill to make two holes in the wall

where the lamp will be mounted. (use the

wall bracket as a template for drilling

locations)

2. Place the anchors into the holes and place

the wall bracket in line with the holes.

3. Secure using the provided screws.

Step 3:

Attach the light to the wall bracket using the

screws you removed in Step 1.

Fig. 1

Turn the light ON (Fig. 2):

Locate the operation switches at the bottom of

the light fixture.

1) Turn the operation switch to the LOW

or HIGH position according to your

preferences:

•(Low) For softer light and longer

duration.

•(High) For brighter light output.

2) Choose between Warm White (WARM)

or Bright White (COOL) color output.

NOTE: The solar lamp will automatically

operate at dusk.

Replacing the Battery (Fig. 2):

(After several years of use, the battery may need replacing.)

1. Make sure the Low/OFF/High switch is in the OFF position.

2. Remove the lamp from the wall by unscrewing the mounting screws

on the sides.

3. Unscrew the battery compartment door screw.

4. Pull the battery door down until the battery is fully exposed and you

can see the battery connector.

5. Unclip the connector and remove the old battery.

6. Make sure the new battery is a Gama Sonic –

3.2V/3,000mAh, Li-ion Rechargeable battery with same connector.

7. Clip on the new battery and install it into the battery compartment.

8. Re-Install the battery compartment cover and attach the lamp back to

the wall.

9. Turn the light back ON (see Turn the light ON for more details).

** Gama Sonic batteries are available at www.gamasonic.com

You can purchase it directly at: https://gamasonic.com/product-category/parts-and-

accessories/ . Make sure the new battery is a Gama Sonic - 3.2V/3,000mAh, Li-ion

Rechargeable Battery with a connector.

Fig. 2

Maintenance

Clean the solar module regularly with a damp towel to guarantee optimum

performance of the solar panel. Do not use any type of solvent for cleaning and be

careful not to put too much pressure on the module while cleaning.

Troubleshooting

If your solar light does not come on at dusk despite observance of all the

instructions, please try the following steps:

1. Make sure that the solar light is not being affected by any other light

source.

2. Ensure the solar light is not positioned in the shade during the day.

3. Make sure the switch is NOT in the “OFF” position.

4. Check that the batteries are installed correctly.

WINTERTIME TIPS: Keep snow and debris cleaned off the solar panels so the

batteries can recharge. If the lights are covered with snow for an extended period of

time, after the snow melts, allow all the batteries to charge in full, direct sunlight for

at least 6 hours to their maximum capacity.

WARNING: Please keep out of reach of children. Do not dispose of Li-Ion battery in

the regular trash, municipal waste stream or by fire as batteries may leak or explode.

Do not open, short circuit, or mutilate batteries as injury may occur. Preserve our

environment by recycling Li-Ion batteries or disposing of them in accordance with

local, state and federal regulations. Do not mix old and new batteries.
