Ganz MDCH-IR312NA Manuale utente

Dome Cameras

Dome Cameras

Dome Cameras

Outdoor Vandal- esistant Day/Night I Dome Cameras

MDCH-I 312NA

• 3.3-12mm computar®I Coated Auto-iris Varifocal Lens

• Light Activated Photocell Turns on I Lights at Night

• 18 I LEDS Provide over 50’ Illumination ange

• High esolution 480 TVL

• Single Model for Surface or Flush Mounting

• Manual Pan / Tilt otation Mechanism

• 12VDC / 24VAC Dual Voltage (Auto-sensing)

• Optional Service Monitor Cable (ZCA-SM200)

• IP66 ating for all Weather Conditions

www.computarganz.com

www.computarganz.com

MDCH-I 312NA Outdoor Vandal- esistant Day/Night I Dome Cameras

 Specifications

Model MDCH-IR312NA

TV system NTSC

Scannin system 2:1 Interlace

Ima e sensor 1/3” Super HAD CCD

Effective elements 768 (H) x 494 (V)

Scannin frequency 15.734kHz (H) / 59.94Hz (V)

Video output 1 Vp-p/75Ω

Horizontal resolution 480 TVL

Min. Illuminance 0 lux (B/W ode - w/ IR LED ON)

Day / Ni ht Digital Day / Night

S/N ratio ore than 50dB (AGC off)

Gamma characteristic 0.45

IR Illumination 18 IR LEDs

Sync. System Internal only

Electronic shutter 1/60 sec. Fixed

White balance Auto (2500°K to 15000°K)

Power supply AC 24V ± 10% 50Hz/60Hz ± 1Hz / DC 12V ± 10%

Power Consumption 5.5W

Ambient temperature Operation: 14°F to +122°F / Storage: -4°F to +140°F

Ambient humidity (non condensin ) Operation: ax. 85%RH / Storage: ax. 95%RH

IP ratin IP66

External dimensions 5.5” (ø) x 4.1”(H)

Wei ht 1.7 lbs. (750g)

Accessories Additional power connector, plastic anchors, screws, instruction manual

Lens Specifications

Max. aperture ratio 1:1.2

Focal len th 3.3mm ~ 12mm

Iris (DC auto iris) F1.4 ~ F360C

An le of view

(Wide to Tele)

D 125.7º~ 29.9º

H 89.8º~ 23.9º

V 63.6º~ 17.9º

 Inside View  Mounting Options

Pendant Mount

ZC4-PM2

Pendant Mount

ZC4-WM2

All specifications are subject to change without notice

NY: 55 Mall Drive Commack, NY 11725 • 1 (800) 422-6707 • (631) 864-9700 • FAX: (631) 543-5426

CA: 20521 Earl Street Torrance, CA 90503 • 1 (877) 407-9555 • (310) 793-1500 • FAX: (310) 793-1506

www.computarganz.com © 2010 CBC (AME ICA) Corp. All ights eserved. 08/10
