Ganz ZC-BNX8312NBA Manuale utente

IR & Specialty

600 TVL Outdoor True Day/Night IR Bullet

ZC-BN 8312NBA

IR & Specialty

Scan Me!

Features:

• 600 TVL Resolution

• 3.3-12mm computar®IR coated auto-iris varifocal lens

• 30 IR LEDS provide over 100’ illumination range

• Digital Wide Dynamic Range

• Multi-function switch for OSD control

• Backlight / Highlight compensation

• Motion detection

• Privacy masking

• Digital noise reduction (2D)

• Lens shading compensation

• Easy cable management with cable feed-through bracket

• IP67 Rating for all weather conditions

www.computarganz.com

ZC-BNX8312NBA_Layout 2 2/28/12 3:28 PM Pag 1

 Specifications

All specifications are subject to change without notice.

ZC-BN 8312NBA 600 TVL Outdoor True Day/Night IR Bullet

Model ZC-BNX8312NBA

TV System NTSC

Scanning System 2:1 Interlace

Image Sensor 1/3” Sony Super HAD II CCD

Effective Pixels 768 (H) x 494 (V)

Scanning frequency 15.734kHz (H) / 59.94Hz (V)

Video Output 1.0V p-p / 75Ω

Horizontal Resolution 600 TVL

Minimum Illumination 0 lux (B/W Mode - at IR LED N)

Day / Night Performance True Day / Night, Retractable IR Cut Filter

S/N Ratio More than 50dB (at minimum AGC gain)

IR Illumination 30 IR LEDs

Gamma Correction 0.45

Sync System Internal only

Lens 3.3-12mm / F1.4 Auto-iris

Max Aperture Ratio 1: 1.4 ~ 2.9

Angle of View 89.8° ~ 23.9° Horizontal

Electronic Shutter 1/60 sec, FLK, 1/60 ~ 1/100,000 (selectable)

BLC (Backlight Compensation) n / ff / HLC (Highlight compensation)

White Balance ATW1, ATW2, AWC, Manual (selectable)

Power Supply 24V AC ± 10% 60Hz ± 1Hz / 12V DC ± 10%

Power Consumption 5.7W (24V AC) / 6.5W (12V DC)

Operating Temperature -4° F ~ 122° F (-20°C ~ 50°C)

Storage Temperature -4° F ~ 140° F (-20°C ~ 60°C)

Am ient Humidity 85% RH ( peration) / 95% RH (Storage)

IP Rating IP67

External Dimensions 8.2” (L) x 2.8” (Ø) / 209mm (L) x 72mm (Ø)

Weight 1.7 lbs. / 750g (with sunshield)

Switch Multi-function switch for SD control

Accessories Self-tapping screw (3), Template, Instruction Manual, Additional Power Connector, Allen key

Certifications CE, FCC, WEEE

www.computarganz.com

OSD

Navigation

Switch

Zoom & Focus

Adjustm nts

Bottom View

Side View Back View

ZC-BNX8312NBA_Layout 2 2/28/12 3:28 PM Pag 2
