Garmin 2565 Manuale di istruzioni

nüvi

2565

quick start manual

190-01195-26_0A.indd 1 2011/5/24 下午 01:59:55

nüvi 2565 Quick Start Manual 1

Getting Started

WARNING

Refer to the Important Safety and

Product Information guide available

on www.garmin.com for product

warnings and other important

information.

When using your device for the rst

time, complete the following tasks.

1. Connect the device to vehicle

power (page 1).

2. Mount the device (page 3).

3. Register the device (page 4).

4. Updating the Software and Maps

(page 4).

Connecting the Device to

Vehicle Power

WARNING

This product contains a lithium-ion

battery. To prevent the possibility of

personal injury or product damage

caused by battery exposure to extreme

heat, remove the device from the

vehicle when exiting or store it out of

direct sunlight.

Charge your device before using it on

battery power.

1. Fit the bottom of your device into

the mount.

2. Tilt your device back until it snaps

into place.

190-01195-26_0A.indd 1 2011/5/24 下午 01:59:56

2 nüvi 2565 Quick Start Manual

3. Plug the vehicle power cable

➊

into the mini-USB connector

➋

on the mount.

➊

➋

➍

➌

4. Plug the other end of the vehicle

power cable into a power outlet in

your vehicle.

5. If you are using a trafc receiver,

connect the external antenna to the

trafc receiver and secure it to the

windshield using the suction cups.

6. Video in connector

➌

, connecting

rear view camera. Driving

recorder connector

➍

to connect

driving recorder. Rear camera

and driving recorder are optional

subscriptions.

After the device has been connected

to vehicle power, the following

occurs.

• The device turns on.

• The device acquires satellite

signals. When at least one of the

bars is green, your device has

acquired satellite signals.

• NOTE: The device may need a

clear view of the sky to acquire

satellite signals.

• The device charges as you drive.

in the status bar indicates the

190-01195-26_0A.indd 2 2011/5/24 下午 01:59:57

nüvi 2565 Quick Start Manual 3

status of the internal battery.

Mounting Your Device

NOTICE

Before mounting the device, see

the Important Safety and Product

Information guide for information

about laws pertaining to windshield

mounting.

1. Remove the clear plastic from the

suction cup.

2. Clean and dry your windshield

and the suction cup with a lint-free

cloth.

3. Press the suction cup to the

windshield.

4. While pressing, ip the lever back

toward the windshield.

5. Snap the mount

➊

onto the

suction cup arm

➋

➊➋

Mounting Driving Recorder

(Optional)

➊

➋

1. Snap driving recorder- GDR 10 to

the other arm.

2. Connect GDR 10 transmitter to

microUSB port on mount located

aside.

190-01195-26_0A.indd 3 2011/5/24 下午 01:59:57

4 nüvi 2565 Quick Start Manual

Registering the Device

Go to www.my.garmin.com for

registration

Updating the Software and

Maps

Go to www.garmin.com.sg for

software and map updates

nüMaps Guarantee

Your device is eligible for one

free map update within 60 days of

acquiring satellites while driving with

your nüvi. You are not eligible for

the free map update if you register

by phone or wait longer than 60

days after the rst time you acquire

satellites while driving with your

nüvi. For more information, go to

www.garmin.com/numaps.

Device Overview

➊

➋➌

➊

Power key

➋

microSD

™

card slot

➌

External GPS antenna conenctor

Using the Power Key

1. Press and quickly release the

Power key to view additional

options.

2. Select an option:

• To adjust screen brightness,

touch and drag the scroll bar.

• To turn off your device, touch

Off.

• To reset the device, hold the

Power key for 10 seconds.

190-01195-26_0A.indd 4 2011/5/24 下午 01:59:58

nüvi 2565 Quick Start Manual 5

• To exit the menu, press and

release the Power key.

About Points of Interest

The detailed maps loaded in your

device contain points of interest,

such as restaurants, hotels, and auto

services.

Finding a Point of Interest by

Category

1. From the Main menu, touch

Where To? > Points of Interest.

2. Select a category.

3. If necessary, select a subcategory.

4. Select a destination.

5. Touch Go!.

Touch > Save on this page to

save the location to a Favorites

folder on the device. Use the

Favorites folder to save the

location of your workplace, home,

and other common destinations.

6. If necessary, select an option:

• Touch Drive to calculate a

route you will navigate by

driving.

• Touch Walk to calculate a

route you will navigate by

walking.

• Touch Public Transit to

calculate a route that combines

public transit and walking.

NOTE: You must have

cityXplorer™maps loaded to

navigate using public transit.

Go to www.garmin.com to

purchase cityXplorer maps.

190-01195-26_0A.indd 5 2011/5/24 下午 01:59:58

6 nüvi 2565 Quick Start Manual

Using the Main Menu

➊

➋ ➌

➍ ➐ ➑ ➒➎ ➏

• Touch

➊

to select a transportation

mode.

• Touch

➋

to nd a destination.

• Touch

➌

to view the map.

• Touch

➍

to stop a route.

• Touch

➎

to detour a route.

• Touch

➏

to make a call when

connected to a compatible mobile

phone. See www.garmin.com/

bluetooth for information.

• Touch

➐

to start Voice Command.

• Touch

➑

to adjust the volume.

• Touch

➒

to open the menu of

tools and settings.

Customise Main Menu

Make your own main menu

1. Find the main menu, touch Tools

> Settings > Main Menu

2. Select Customize and add any

features you like, maximum up to

15 icons.

190-01195-26_0A.indd 6 2011/5/24 下午 01:59:59

nüvi 2565 Quick Start Manual 7

3. Touch Save.

Your Route on the Map

NOTICE

The speed limit icon feature is for

information only and does not replace

the driver’s responsibility to abide

by all posted speed limit signs and to

use safe driving judgment at all times.

Garmin will not be responsible for

any trafc nes or citations that you

may receive for failing to follow all

applicable trafc laws and signs.

Your route is marked with a magenta

line on the map. If you depart from

the original route, your device

recalculates the route. A speed limit

icon could appear as you travel on

major roadways.

Using the Map Functions

➊ ➋

➌

➍➎

➏

➓

➐

➑➒

• Touch

➊

to view the next turn.

If a view of a junction exists,

the junction view appears.

• Touch

➋

to view the turn list.

• Touch

➌

to zoom in and out.

• Touch

➍

to return to the Main

menu.

• Touch and hold

➍

from any

screen to return to the Main

menu.

190-01195-26_0A.indd 7 2011/5/24 下午 01:59:59

8 nüvi 2565 Quick Start Manual

• Touch

➎

to change the data

eld.

• Touch

➏

to view the Where

Am I? page.

• Touch and drag

➐

to view a

different area of the map.

• Touch

➑

to view trip

information.

• Touch

➒

to change the speed

limit if the speed limit shown

on the map is incorrect.

•

➓

means current lane info.

You will not lose direction,

any turn or exist.

Using myTrends

As you drive with the device on,

myTrends™gathers information that

allows the device to predict when you

are traveling to a common destination,

like your workplace or home. When

myTrends is activated, the destination

and estimated time of travel will

appear in the navigation bar on the

map. If a trafc receiver is connected,

trafc information may also appear in

the navigation bar.

myTrends only works for locations

that are saved as Favorites (page 5).

When myTrends information

appears in the navigation bar,

touch the navigation bar to view

route information.

190-01195-26_0A.indd 8 2011/5/24 下午 02:00:00

nüvi 2565 Quick Start Manual 9

Avoiding Road Features

1. Find the main menu, touch

Tools > Settings > Navigation

> Automobile > nuRoute >

Avoidances.

2. Select the road features to avoid

on your route.

3. Touch Save.

Custom Avoidances

1. Find the main menu, touch Tools

> Car > nuRoute > Custom

Avoidances.

2. Select avoid area or avoid road

you wish.

3. Touch Save.

Routes Preview

Navigate to the destination before

travelling and preview 3 routes, select

the most suitable route for navigation.

1. Find the main menu, touch Tools

> Settings > Navigation > Car >

nuRoute > Calculation Mode.

2. If selecting Prompted, GPS will

show three different routes for

preview before navigation.

3. Touch Save.

190-01195-26_0A.indd 9 2011/5/24 下午 02:00:00
