Quick Start Manual

nüvi®780

personal travel assistant with

MSN®Direct Receiver

What’s in the Box?

nüvi GPS device and vehicle suction cup

mount.

Vehicle power cable with built-in MSN

Direct Receiver to provide external power

and MSN Direct content.

USB cable to connect the nüvi to your

computer. Your nüvi connects to your

computer as a mass storage device.

Dashboard disk to mount the suction cup

mount on your dashboard.

Ways to Charge Your nüvi

Use the vehicle power cable.

Use the USB cable.

Use an optional AC adapter.

•

SD card slot

Headphone/audio

out jack

Microphone

Power key:

slide to the left to turn the unit on/off;

slide to the right to lock the screen

SpeakerGPS antenna

Mini-USB connector

Serial number

External antenna connector

WARNING: See the Important Safety and Product Information guide in the product box for product warnings

and other important information.

WARNING: This product contains a non-user-replaceable lithium-ion battery. See the Important Safety and

Product Information guide in the product box for important battery safety information.

State law in Minnesota and California prohibits and/or restricts drivers from using suction mounts on their

windshields while operating motor vehicles. (See California Vehicle Code 26708(a); Minnesota Statutes

Section 169.71.) Other Garmin dashboard or friction mounting options should be used in those states. Check

your state and local laws and ordinances where you drive, as other states may enact similar prohibitions or

related restrictions against windshield objects that obstruct the driver’s vision (Michigan and New Jersey law

currently prohibits windshield objects that obstruct the driver’s vision). Remember to always mount your

Garmin unit in a location that does not obstruct the driver’s view of the road. Garmin does not assume any

responsibility for any nes, penalties, or damages that may be incurred as a result of disregarding this notice or

as a result of any other state or local law or ordinance relating to use of the unit.

Step 1: Mount the nüvi

1. Plug the vehicle power cable into the power

connector on the right side of the cradle.

2. Snap the cradle onto the suction cup arm.

3. Clean and dry your windshield and the suction

cup with a lint-free cloth. Remove the clear plastic

from the suction cup. Place the suction cup on the

windshield.

4. Flip the lever back, toward the windshield.

5. Fit the bottom of your nüvi into the cradle.

6. Tilt the nüvi back until it snaps into place.

7. Plug the other end of the vehicle power cable into

a power outlet in your vehicle. Your unit should turn

on automatically if it is plugged in and your vehicle is

running.

Cradle

Power cable

Suction cup mount

Step 2: Congure the nüvi

To turn on your nüvi, slide the Power

key to the left. Follow the on-screen

instructions.

Step 3: Acquire Satellites

Go outdoors to an open area, out of garages,

and away from tall buildings. Stop your

vehicle, and turn on the nüvi. Acquiring

satellite signals may take a few minutes.

The bars indicate GPS satellite

strength. When one bar is green, the nüvi

has acquired satellite signals. Now you can

select a destination and navigate to it.

Step 4: Activate Your MSN®

Direct Receiver

Your use of the MSN Direct service, as well as your use

of the MSN Direct content delivered to and displayed on

your device, is subject to the MSN Direct Subscription

Agreement, Terms of Use, and Privacy Statement located

at www.msndirect.com. By using and activating your

navigation device, you hereby accept such Subscription

Agreement, Terms of Use and Privacy Statement, and

acknowledge that you are aware of and have had an

opportunity to fully review them at the URL referenced

above.

To receive MSN Direct content, rst you

must activate your service (3-months free

service included).

1. Connect the vehicle power cable to your

nüvi and your vehicle’s power outlet.

Turn your vehicle’s key to the ON/ACC

position, if necessary, to power the nüvi.

2. Touch Tools > MSN Direct.

3. Write down the product key.

4. Call (866) 658.7032 or go to

http://garmin.msndirect.com/activate

and follow the directions.

5. Within two days, complete the following

steps:

Connect the vehicle power cable, and

turn the key to ON/ACC.

Make sure you are in an MSN Direct

coverage area (see http://garmin

.msndirect.com/coverage).

Touch Tools > MSN Direct. If the

Subscription Inactive page appears,

verify that one signal bar is green.

It may take up to 20 minutes for your

subscription to be activated. After it

is activated, the MSN Direct menu is

accessible.

•

Step 4: Use the nüvi

BA C D

E F

G H I

AGPS satellite strength.

BBluetooth®technology status.

CBattery status.

DCurrent time; touch to change time

settings.

ETouchtondadestination.

FTouch to view the map.

GTouch to make a call when connected to

a compatible mobile phone.

HTouch to adjust the volume.

ITouch to use the tools such as media

players, settings, and Help.

Finding Points of Interest

1. Touch Where to? > Points of Interest.

2. Select a category and a sub-category.

3. Select a destination, and touch Go.

To enter letters contained in the name, touch

Where to? > Points of Interest > Spell

Name.

To search for a location in a different area,

touch Where to? > Near….

Adding a Via Point

1. With a route active, touch Menu on the

map, and touch Where to?.

2. Search for the via point (extra stop).

3. Touch Go.

4. Touch Add as Via Point.



TIP: To add more than one stop, edit the

current route. Touch Where to > Routes.

Viewing the Main Pages

Touch View map to open the Map page. The vehicle icon shows your current

location. Touch the map and drag to view different parts of the map. Touch anywhere on the

map; an arrow appears pointing at the object.

After you touch Go, the Map page opens. Your route is marked with a magenta line. As you

travel, your nüvi guides you to your destination with voice prompts, arrows on the map, and

directions at the top of the Map page. A checkered ag marks your destination. If you depart

from the original route, your nüvi recalculates the route and provides new directions.

Touch to save your

current location.

Map Page while Navigating a Route

Touch Arrival or Speed to

open the Trip Information.

Touch Turn In to view the

Next Turn.

Touch the text bar to open the Turn List.

Touch to zoom out. Touch to zoom in.

Touch Menu to return to

the Menu page.

Turn List Next TurnTrip Information

Taking a Detour

1. With a route active, touch Menu.

2. Touch Detour.

The nüvi attempts to get you back on your

original route as quickly as possible. If

the route you are currently taking is the

only reasonable option, the nüvi might not

calculate a detour.

Stopping the Route

1. With a route active, touch Menu.

2. Touch Stop.

Adjusting the Volume

From the Menu page, touch Volume. Touch

and to adjust the master volume.

Touch Mute to mute all audio.

Locking the Screen

To prevent accidental screen taps, slide the

Power key to the right ( ). To unlock the

screen, slide the Power key to the center

position.

Locking Your nüvi

1. Touch Tools > Settings > Security.

2. Touch the button below Garmin Lock.

3. Enter a 4-digit PIN and drive to a security

location.



NOTE: If you forget your PIN and your

security location, you must send your nüvi

to Garmin to get it unlocked. You must

also send a valid product registration or

proof of purchase.

Saving Your Current

Location

From the Map page, touch . Touch Save

Location to save your current location.

Saving Places You Find

After you have found a place you want to

save, touch Save. Touch OK. The place is

saved in Favorites.

TIP: Your Last Position is automatically

saved each time you remove the nüvi from

the cradle. Use this feature to nd your car

in a parking lot.

Using MSN®Direct

The MSN Direct Receiver and nüvi must be

in range of an MSN Direct coverage area.

See http://garmin.msndirect.com/coverage

for more information on coverage areas.

Receiving Content

It can take several hours to receive all the

content the rst time you use it, after you

have traveled long distances, or after you

have not used your nüvi and MSN

Direct

Receiver for several days.

There is a rechargeable (non-user-

replaceable) battery in the MSN Direct

Receiver that allows it to receive and store

updates for several days, even when not

connected to external power.



NOTE: Garmin is not responsible for the

accuracy of the MSN Direct content.

MSN Direct Menu

To view MSN Direct content, from the

Menu page, touch Tools > MSN Direct.

Touch a category to view information for it.

Trafc

MSN Direct provides local trafc

information for a large number of

metropolitan areas. To learn more about

the type of trafc data available in your

area, visit http://garmin.msndirect.com/

NavigationTrafcCoverage.html.

When calculating your route, the nüvi

examines the trafc delays and optimizes the

route for the shortest time. If a severe trafc

delay occurs on your route and a better

route is available, the nüvi recalculates

the route to avoid the delay. You might be

routed through trafc if it is the best route

available.

The Map page displays when there is

a trafc delay on your route. The number

represents the number of minutes the trafc

will delay your route. The delay time has

been automatically calculated into the

arrival time. To view the details of the

delays, touch . If there is more than one

delay, touch Details. Touch Avoid to avoid

this delay.

Using Hands-Free Features

Hands-free phone features are available only

if your nüvi and your compatible mobile

phone have Bluetooth wireless technology.

Not all phones support all the hands-free

phone features the nüvi provides. To use

the hands-free features, you must pair your

phone and the nüvi.

Pairing Your Phone

1. Verify that your phone is compatible with

the nüvi (www.garmin.com/bluetooth).

2. From the Menu page, touch Tools >

Settings > Bluetooth.

3. Touch the Add button.

4. Enable your phone’s Bluetooth

component and enable Find Me/

Discoverable/Visible mode. These

settings might be in a Bluetooth,

Connections, or Hands-free menu.

5. Touch OK on the nüvi.

6. Select your phone, and touch OK.

7. Enter the nüvi’s Bluetooth PIN (1234) in

your phone.

Phone Menu

Calling a Number

1. Touch Phone > Dial.

2. Enter the number, and touch Dial.

3. To end the call, touch > End Call.

Receiving a Call

When you receive a call, a message appears

on the nüvi. Touch Answer.

Using Call Waiting

If you get a call waiting call, the nüvi

displays a message. Touch Answer. The rst

call is put on hold. To end the call, touch

> End Call; this does not disconnect the call

on hold.

Loading Files on Your nüvi

1. Connect the USB cable to the mini-USB

connector on the nüvi and to an available

USB port on your computer. Your nüvi’s

internal memory and SD card appear

as removable drives in My Computer on

Windows®computers, and as mounted

volumes on Mac®computers.

2. Copyandpastelesfromyourcomputer

into the nüvi drives/volumes.

3. Whenyouarenishedtransferringles,

click the Eject icon or drag the volume

icon to the Trash.

4. Unplug your nüvi.

Listening to MP3 Files

1. LoadMP3lestotheinternalmemoryor

SD card.

2. Touch Tools > Media Player. Touch

Source to open the music player.

3. Touch Browse.

4. Touch a category.

5. To play the entire category from the

beginning of the list, touch Play All. To

playaspecicsong,touchthetitle.

To create, edit, and listen to playlists, touch

Browse > Playlist.

Altri manuali per CAMPER 780

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Garmin Sistema di navigazione per auto

Garmin

Garmin StreetPilot 2730 Manuale utente

Garmin

Garmin nuvi 705 series Manuale di istruzioni

Garmin

Garmin StreetPilot c340 Manuale utente

Garmin

Garmin NVI 755 Manuale

Garmin

Garmin StreetPilot c330 Manuale utente

Garmin

Garmin StreetPilot c330 Manuale utente

Garmin

Garmin nuvi 2505 series Manuale di istruzioni

Garmin

Garmin StreetPilot c510 Manuale utente

Garmin

Garmin nuvi 705 series Manuale di istruzioni

Garmin

Garmin StreetPilot 7500 Manuale utente

Garmin

Garmin StreetPilot c330 Manuale utente

Garmin

Garmin Nuvi 205 Series Manuale di istruzioni

Garmin

Garmin nuvi 800 series Manuale di istruzioni

Garmin

Garmin Streetpilot C320 Manuale utente

Garmin

Garmin nuvi 705 series Manuale utente

Garmin

Garmin Map Pilot Manuale utente

Garmin

Garmin GPSMAP 800 Series Manuale utente

Garmin

Garmin 2610/2650 Manuale utente

Garmin

Garmin nuvi2575 Manuale di istruzioni

Garmin

Garmin RV-IN800 Series Manuale utente

Garmin

Garmin StreetPilot c510 Guida di riferimento

Garmin

Garmin nüvi 2240 Manuale di istruzioni

Garmin

Garmin 612 Manuale utente

Garmin

Garmin Cessna Caravan G1000 Manuale utente

Manuali Sistema di navigazione per auto popolari di altre marche

Clarion

Clarion Navigation In-Car Entertainment Manuale utente

Rosen

Rosen DP-1001 Manuale utente

Alpine

Alpine INE-W970HD Manuale utente

Skoda

Skoda AMUNDSEN+ Manuale utente

Blaupunkt

Blaupunkt TravelPilot DX-N Manuale utente

Pioneer

Pioneer MZ360500EX Manuale utente

Sanyo

Sanyo NVM-4030 - Easy Street - Automotive GPS... Manuale utente

Kenwood

Kenwood DNN991HD Manuale utente

AvMap

AvMap Geosat 2C Manuale utente

Eonon

Eonon GE01B Manuale utente

Pioneer

Pioneer AVIC-Z920DAB Manuale utente

Nextar

Nextar M3-MX - Automotive GPS Receiver Manuale utente

Furrion

Furrion NV2200 Manuale utente

Mio

Mio MOOV 200-Series Manuale utente

Prestigio

Prestigio GeoVision 5150 Manuale utente

Hummer

Hummer 2006 H3 Manuale utente

Magellan

Magellan Maestro 4210 - Automotive GPS Receiver Guida alla configurazione

Mazda

Mazda 107006AN Manuale utente
