Garmin StreetPilot c330 Manuale utente
Step 4: Follow Your Route
Follow the route to your destination using the Map page. As you travel, your c330 guides you to your destination with voice
prompts, arrows on the map, and directions at the top of the Map page. If you depart from the original route, your c330 voice
announces that you are off-route and then provides new route instructions.
Your route is marked with
a red line.
Follow the arrows as you
take turns.
A checkered flag marks
your destination.
Read the driving
instructions at the
top of the page.
Step 2: Configure Your c330
The first time you turn on the unit, follow the on-screen instructions to set up your c330. You only have to do this once.
Step 3: Find Your Destination
Touch Where to? Select a category.
Touch the arrows to see
more categories.
Select a destination.
Touch the arrows to see
more places.
Touch . Enjoy the route!
StreetPilot® c330
quick reference guide
WARNING: For use in vehicles, it is the sole responsibility of the owner/operator of a vehicle with the c330 installed to place and secure the device so it will not interfere with the vehicle operating controls and
safety devices, obstruct the driver’s view of driving conditions, or cause personal injury in the event of an accident.
NOTICE TO STATE OF CALIFORNIA DRIVERS: California Vehicle Code Section 26708 (a) (1) provides that drivers in California should not use suction mounts on their windshield or side or rear windows.
Other Garmin dashboard or friction mounting options should be used. For available accessories, refer to the Garmin Web site at www.garmin.com. Also, refer to the Owner’s Manual for instructions on using the
included mounting disk with the suction cup mount.
Step 1: Mount Your c330
Place the suction cup on your
windshield.
Fit the bottom of your c330 into
the cradle of the suction cup
mount.
Tilt your c330 back until it
snaps in place.
Flip the lever back, toward
the windshield.
Tension knob
To ensure a tight grip, clean and dry your windshield before you mount the suction cup. Plug the cable into a receptacle in
your vehicle. If necessary, use the tension knob to loosen or tighten the tension in the mount to improve your viewing angle.
Your unit will turn on automatically if you have started your vehicle. To manually turn on your c330, press and hold the
Power button on the side of the unit. Refer to the image on the back of this sheet.
Viewing the Map Page
From the Menu page, touch View map to open the Map page. The position icon shows your
current location. Touch buttons on the Map page to see additional information.
Map Page while Navigating a Route
Touch Arrival or Speed to open the
Trip Information page.
Touch Turn In to open the Next Turn
page.
Touch the text bar to open the Current
Route page.
Touch to zoom out.
Touch to zoom in.
Touch Menu to return to the
Menu page.
Trip Information Page Current Route Page Next Turn Page
Saving Places You Find
After you have found a place
you want to save, touch Save.
Touch OK in the pop-up window. The place is
saved in My Locations > Favorites.
Finding Saved Places
Touch .
From the Menu page, touch Where
to? > My Locations > Favorites.
Select a place.
Setting a Home Location
You can set a Home location for the place you return to most often.
Select an option. Touch Where to? Touch My Locations. Touch Set Home.
Going Home
After you have set your Home location, you can route to it at any time by touching My Locations and then Go Home.
Changing Your Home Location
Change your Home location by repeating the steps you took to set it.
Adjusting the Backlight Brightness
From the Menu page, touch the brightness button to
adjust the level of the backlight. Touch the minus (-) lightbulb
to decrease the backlight brightness or the plus (+) lightbulb to
increase the brightness. When you are finished, touch OK.
Adjusting the Volume
To adjust the volume, turn the Volume knob, located above the Power button.
Turning the c330 On and Off
Press and hold the Power button on the side of the unit to turn it on and off.
More Information
For more information about your c330, refer to the Owner’s Manual located at
http://www.garmin.com/products/sp330/. Click on the Manuals link and then
select Download.
Volume
knob
Power
button
USB cable
connector
© Copyright 2005 Garmin Ltd. or its subsidiaries
May 2005 1
90-00436-01 Rev. A Printed in Taiwan
