Garmin Aera 500 Manuale di istruzioni

aera 500 series quick start manual 1

automotive

quick start manual

models: 500, 510, 550, 560

™

2 aera 500 series quick start manual

Your aera

Memory card

slot

Mini-USB

connector

Release key:

Slide and release to

open the battery cover

Battery

contacts

Serial number

(under the battery)

Speaker

GPS antenna

Headphone/

audio-out jack

(under weather cap)

Microphone

Power button:

Press and hold to turn the aera on/off.

Press quickly to adjust the volume and the backlight brightness.

External antenna

connector

(under weather cap)

See the Important Safety and Product Information guide in the product box

for product warnings and other important information.

NOTE: Your aera has both automotive and aviation usage modes.

This quick start manual explains the automotive functions of your

aera.

aera 500 series quick start manual 3

Installing the Battery

1. Locate the lithium‑ion battery that came in

the product box.

2. Slide the release key until the battery

cover on the back of the aera pops up.

3. Remove the battery cover.

4. Locate the metal contacts on the end of

the lithium‑ion battery.

5. Insert the battery so that the metal

contacts on the battery match with

the metal contacts inside the battery

compartment.

6. Replace the battery cover.

WARNING: This product contains a lithium-ion

battery. To prevent injury or damage, remove the unit

from the vehicle when exiting or store it out of direct

sunlight.

Charging Your aera

Charge your aera for at least 4 hours before

using on battery power.

Connect the vehicle power cable.

Connect the USB cable to the mini-USB

connector located under the battery cover.

Connect an AC adapter (if included).

Use a battery charger (optional accessory).

NOTE: Do not connect the USB cable or AC

adapter to the mini-USB connector on the

cradle.

Mounting Your aera in an

Automobile

1. Plug the vehicle power cable into the

power connector on the right side of the

cradle.

•

Release button

Cradle Vehicle power

cable

2. Remove the clear plastic from the bottom

of the friction mount.

3. Place the friction mount on your

dashboard so it is easily accessible.

4. Lift and push the friction mount arm

toward the windshield.

Friction

mount

arm

5. Snap the cradle onto the friction mount

arm.

6. Fit the bottom of your aera into the cradle.

4 aera 500 series quick start manual

7. Tilt the aera back until it snaps into place.

8. Plug the other end of the vehicle power

cable into a power outlet in your vehicle.

Acquiring Satellites

1. Go outdoors to an open area, out of

garages, and away from tall buildings.

2. Turn on your aera.

Acquiring satellite signals may take a few

minutes. The bars indicate GPS

satellite strength. When one bar is green, the

aera has acquired satellite signals. Now you

can select a destination and navigate to it.

Using the Menu Page

➊➋➌➍

➏

➒➑

➐

➎

➓

➊

GPS satellite strength.

➋

Bluetooth

technology status.

➌

Touch to select automotive or aviation

mode.

➍

Battery status.

➎

Current time. Touch to change settings.

➏

 Touchtondadestination.

➐

Touch to view the map.

➑

Touch to make a call when connected to

a compatible mobile phone.

➒

Touch to adjust the volume.

➓

Touch to use the tools such as settings,

Where Am I?, and Help.

Finding Points of Interest

1. Touch Where To? > Points of Interest.

2. Select a category and a subcategory.

3. Select a destination, and touch Go!.

To enter letters contained in the name, touch

Where To? > Points of Interest > Spell

Name.

To search for a location in a different area,

touch Where To? > Near.

Adding a Stop

1. With a route active, touch Menu > Where

To?.

2. Search for the extra stop.

3. Touch Go!.

4. Touch Add As a Via Point to add this stop

before your destination.

To add more than one stop, edit the current

route. Touch Where To? > Custom Routes.

aera 500 series quick start manual 5

Following Your Route

Your route is marked with a magenta line.

As you travel, your aera guides you to your

destination with voice prompts, arrows on

the map, and directions at the top of the

map. If you depart from the route, your aera

recalculates the route and provides new

directions.

A speed limit icon could appear as you travel

on major roadways.

➊ ➋

➌

➍

➎

➏

➐

➊

Touch to view the Next Turn page or the

Lane Assist page (550 and 560 models).

➋

Touch to view the Turn List page.

➌

Touch to zoom in and out.

➍

Touch to view the Where Am I? page.

➎

Touch to view the Trip Computer page.

➏

Touch to return to the Menu page.

➐

Touch to change the data displayed here.

Receiving XM®Satellite

Signals

XM is only available on the aera 510 and 560

models. If your aera came with a GXM 40

antenna, you can receive XM satellite signals.

Some features, such as XM WX

™

Weather

and XM Radio, require XM satellite signals.

A subscription to XM services is required

to access the XM WX Weather and XM

Radio features. For more information on XM

subscriptions, go to www.garmin.com/xm.

The service is activated by providing XM

Radio with a coded ID (Radio ID). The

Radio ID can be found on the underside of

your GXM 40 antenna. Refer to the GXM

40 Owner’s Manual for more information on

activating XM Radio.

NOTE: XM is only available in North

America.

1. Place your aera in the automotive cradle

or the aviation mount.

6 aera 500 series quick start manual

2. Plug the GXM 40 antenna into the

mini‑USB port on the back of the cradle.

3. Place the GXM 40 antenna within clear

view of the sky.

Making Hands-Free Phone

Calls

Using Bluetooth wireless technology, your

aera can wirelessly connect to your mobile

phone to become a hands-free device.

To pair and connect, your phone and the aera

must be turned on and be within 10 meters of

each other.

Pairing the aera with Your Mobile

Phone

Before pairing your aera with your phone, go

to www.garmin.com/bluetoothtoconrmthat

your phone is supported by the aera.

1. Enable the Bluetooth component on your

phone. Enable Find Me/Discoverable/

Visible mode. These settings might be in

a Bluetooth, Connections, or Hands‑free

menu.

2. Touch Tools > Settings > Bluetooth.

3. Touch the button under Bluetooth.

4. Select Enabled, and touch OK.

5. From the Bluetooth page, touch the button

under Phone.

6. Select your phone, and touch OK.

7. Enter the aera Bluetooth PIN (1234) in

your phone.

Receiving a Call

When you receive a call, the Incoming Call

window appears. Touch Answer to answer

the call. Touch Ignore to ignore the call and

silence the ring.

Making a Call

When your phone is connected to your aera,

you are ready to make phone calls. Touch

Phone to access the Phone menu.

Not all phones support all features of the aera

Phone menu.

Calling a Number

1. Touch Phone > Dial.

2. Enter the number, and touch Dial.

3. To end the call, touch > End Call.

Loading Files on Your aera

1. Insert a memory card (optional).

2. Connect the USB cable.

3. Transferlestotheaera.

4. Eject and unplug the USB cable.

Listening to MP3 Files

1. Touch Tools > Media Player.

2. Touch Source to open the MP3 player.

3. Touch Browse.

4. Touch a category.

5. Touch Play All.

aera 500 series quick start manual 7

Locking Your aera

1. Ensure you are at your security location

and that your aera is receiving satellite

signals.

2. Touch Tools > Settings > Security.

3. Touch the button below Garmin Lock.

4. Enter a 4‑digit PIN and drive to a security

location.

NOTE: If you forget your PIN and your

security location, you must send your aera

and valid product registration or proof of

purchase to Garmin to unlock your aera.

Resetting the aera

If the aera screen stops functioning, turn the

aera off and on again. If this does not help,

remove the battery and then reinstall the

battery.

nüMaps Guarantee™

To receive one free map update (if available),

.com within 60 days of acquiring satellites

and traveling with your aera (acquiring

satellites for this purpose requires driving

oryingwiththeunitover5milesperhour

for approximately 30 seconds). You are

not eligible for the free map update if you

afterthersttimeyouacquiresatelliteswith

your aera.

NOTE: The nüMaps Guarantee only applies

to the automotive maps loaded on your aera.

For more information on aviation databases,

go to http://y.garmin.com.

More Information

For more information about your aera,

touch Tools > Help. You can download the

latest version of the owner’s manual from

www.garmin.com. For information about

accessories, go to http://buy.garmin.com or

contact your Garmin dealer.

Tips and Shortcuts

To quickly return to the Menu page, touch

and hold Back.

Touch and to see more choices.

Touch and hold to scroll faster.

•

Garmin

and the Garmin logo are trademarks of Garmin Ltd. or its subsidiaries, registered in the USA and other countries. nüMaps Guarantee

™

and aera

™

are trademarks of

Garmin Ltd. or its subsidiaries. These trademarks may not be used without the express permission of Garmin. The Bluetooth

word mark and logos are owned by the Bluetooth

SIG, Inc., and any use of such name by Garmin is under license. Other trademarks and trade names are those of their respective owners. XM and the XM logos are trademarks

of XM Satellite Radio Inc. XM Radio and XM WX

™

Weather are trademarks of XM Satellite Radio Inc.

For the latest free software updates (excluding map data) throughout the life of your

Garmin products, visit the Garmin Web site at www.garmin.com.

Garmin International, Inc.

1200 East 151st Street, Olathe, Kansas 66062, USA

Garmin (Europe) Ltd.

Liberty House, Hounsdown Business Park, Southampton, Hampshire, SO40 9LR UK

Garmin Corporation

No. 68, Jangshu 2nd Road, Shijr, Taipei County, Taiwan

www.garmin.com

September 2009 Part Number 190‑01117‑01 Rev. B Printed in Taiwan

Altri manuali per aera 500

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Garmin GPS

Garmin

Garmin GTN 725 Manuale

Garmin

Garmin GPSMAP 3205 - Marine GPS Receiver Manuale utente

Garmin

Garmin NVI 1300 Manuale di istruzioni

Garmin

Garmin Nuvi 715 Series Manuale utente

Garmin

Garmin GPS 19x NMEA 2000 Manuale utente

Garmin

Garmin GPS 60 - Hiking GPS Receiver Manuale utente

Garmin

Garmin ECHOMAP UHD2 5X Manuale utente

Garmin

Garmin RUNNING DYNAMICS POD Manuale utente

Garmin

Garmin APOLLO GX SERIES Manuale utente

Garmin

Garmin Approach G5 - GPS-Enabled Golf Handheld Manuale utente

Garmin

Garmin Apollo GX50 Manuale utente

Garmin

Garmin ECHOMAP PLUS 60 series Manuale utente

Garmin

Garmin GPSMAP 76 series Manuale utente

Garmin

Garmin GPSMAP 3006C Manuale utente

Garmin

Garmin ZUMO Zumo 400 Istruzioni per il montaggio

Garmin

Garmin nuvi 1690 Manuale utente

Garmin

Garmin ECHOMAP PLUS 70 series Manuale utente

Garmin

Garmin iQue M4 - Win Mobile Manuale utente

Garmin

Garmin Personal Navigator GPS 100AVD Manuale utente

Garmin

Garmin GPSMAP 4008 - Marine GPS Receiver Guida di riferimento

Garmin

Garmin GPSMAP 76 series Manuale utente

Garmin

Garmin GPSMAP 180 Manuale utente

Garmin

Garmin GPSMAP 178 Sounder Manuale utente

Garmin

Garmin GPSMAP 192C Manuale del proprietario

Manuali GPS popolari di altre marche

Raven

Raven Cruizer II Manuale

Hama

Hama 53118 Manuale utente

Jigabot

Jigabot EX Manuale utente

Pointer

Pointer Cellocator CelloTrack XT LTE Guida all'installazione

Queclink

Queclink GV55LITE Manuale utente

Voxson

Voxson Voxtrack GPS500 Manuale di istruzioni

Starcom Systems

Starcom Systems Kylos Compact Manuale utente

Cobra

Cobra Marine MC 600Ci Manuale utente

Cellocator

Cellocator CelloTrack T Manuale utente

Enfora

Enfora Mini-MT GSM2228UG001 Manuale utente

Magellan

Magellan eXplorist 100 Manuale utente

LTE

LTE G50B Manuale utente

SkyGolf

SkyGolf SkyCaddie SG1 Manuale utente

Kenwood

Kenwood DNN9330BT Manuale utente

Safelet

Safelet Indra Manuale utente

Bushnell

Bushnell 360100 Manuale utente

Geneq

Geneq SXBlue Manuale utente

ORIGO

ORIGO ED308 Manuale utente

Garmin aera 500 Manuale di istruzioni

Manuali GPS popolari di altre marche
