START HERE

iQue® M5

integrated handheld

setup guide

190-00427-11 Rev. C

Getting Started

Thank you for choosing the Garmin® iQue®

M5 integrated handheld! Please take a

moment now to compare the contents of this

package with the packing list on the outside

of the box. If any parts are missing, contact

your Garmin dealer.

To get the most out of your new iQue M5,

follow all of the instructions in this guide.

Do not skip steps!

Step 1—Insert the Battery

1. Locate the black or gray lithium-ion

battery that came in the product box.

2. With your iQue M5 in one hand, press

gently on the back of the iQue M5

battery cover and pull down to remove

the cover.

Gently pull down the battery cover.

3. Locate the metal contact points on one

end of the lithium-ion battery. Insert

the battery so that the metal contact

points on the battery match up with the

metal contact points inside the battery

compartment. Gently press the battery

down until it clicks into place.

metal contacts

4. Reinsert the battery cover by lining up

the cover with the “Battery Door” line

on the back of the unit. Then gently

slide the cover up until it is closed.

Line up the

battery cover

with the line on

the back of the

unit.Then slide

the cover up

gently.

Step 2—Charge the Battery

Before you can continue setting up your iQue M5, you

should charge the battery for four full hours.

To charge the battery:

1. Locate the Sync cradle and the AC charger from

the product packaging.

2. Plug one end of the AC charger into the back

of the Sync cradle. Plug the other end into a

standard wall outlet.

NOTE: Do not connect the Sync cradle to your

computer until you are instructed to do so in a

later step!

3. Insert the iQue M5 into the cradle by aligning the

sides of the unit with the sides of the cradle. Then

slide the unit gently down until it clicks into place.

Step 3—Set Up the iQue M5

After four hours have passed, turn on the iQue M5 by

pressing the Power button, shown to the right. If the

iQue M5 is charged completely, the LED light on the top

of the unit should illuminate in green. If it is illuminated

in orange, the unit needs to ﬁnish charging. When the

unit is completely charged, follow the on-screen setup

instructions.

Power button

Note: You may see a “Backup Battery

Very Low” warning, even after you

have charged the lithium-ion battery

completely. This warning relates to

the internal memory battery, which

retains data when the main battery is

removed. It may take up to two days

to charge the internal memory battery

completely. During this time, you can

still use your iQue M5 out of

the cradle.

Please insert this DVD-ROM

into your DVD-ROM drive now.

Step 4—Insert the Companion

DVD

1. Insert the Microsoft® Companion DVD

into your DVD-ROM drive.

2. If the welcome screen does not

automatically appear, click Start and

then Run on your personal computer.

Type the letter of your DVD-ROM

drive followed by setup.exe (example:

E:\setup.exe). Then press Enter.

3. Click the Getting Started link in the

upper right corner of the welcome

screen. Then click Start Here on the

Main Menu.

Click here

Step 5—Install Microsoft Outlook®

2002

If you do not have Microsoft Outlook 98 or

newer installed on your computer, or if you

want to upgrade to Outlook 2002, follow these

instructions. Otherwise, go directly to the next

step, Install Microsoft ActiveSync.

1. Click Install Outlook 2002. Then click

Install.

Click Install

2. An installation message appears; click

OK to acknowledge the message.

When the File Download window

appears, click Open or Run this

program from its current location to

start the installer.

3. Follow the instructions on the screen to

install Outlook 2002.

Step 6—Install Microsoft

ActiveSync®

Install ActiveSync so that you can continue

setting up your iQue M5 and load detailed

map data. You must install the included ver-

sion of ActiveSync to continue setting up your

iQue M5 correctly, even if you have previ-

ously installed any version of ActiveSync. If

you are upgrading ActiveSync, be sure to

disconnect all Pocket PC devices from your

computer ﬁrst.

To install ActiveSync:

1. Click Install ActiveSync. Then click

Install.

Click Install

2. Click OK to acknowledge the

installation message. When the File

Download window appears, click Open

or Run this program from its current

location to start the installer.

3. When the Microsoft ActiveSync

installer appears, click Next.

4. Click Next to accept the default folder

settings.

5. Wait while the installer copies ﬁles and

folders to your computer.

6. When the installation is complete,

the Get Connected Window appears.

At this time, plug the USB connector

on the Sync cradle into a USB port

on your computer.

Make sure your iQue M5 is turned on

and is in the cradle.

7. Your computer should detect your

iQue M5 automatically. If it does not,

click Next and follow the instructions

that appear.

8. The New Partnership window appears.

Click Next.

9. Select the method you want to use

to synchronize (most people use

“Synchronize with this desktop

computer”). Then click Next.

10. Select which types of items you want to

synchronize with your iQue M5. Then

click Next.

NOTE: To synchronize e-mail,

contacts, appointments, and tasks

from Microsoft Outlook, you must have

Outlook 2000 or newer installed on

your personal computer.

11. Click Finish to complete the setup

process. Your iQue M5 synchronizes

with your computer.

Step 7—Install Mapping Software

on Your Personal Computer

To load detailed map data on your iQue M5,

you must load MapSource® mapping software

on your personal computer.

To install mapping software:

1. Click Install MapSource. Then click

Install.

2. Click OK to acknowledge the

installation message. When the File

Download window appears, click Open

or Run this program from its current

location to start the installer.

3. At the MapSource Welcome screen,

click Next.

4. Read the License Agreement and click

Yes if you wish to continue with the

installation.

5. Click Next to install MapSource in the

default location.

6. Follow the additional setup instructions

to install MapSource.

Step 8—Unlock Maps

The UnlockWizard automatically starts at the

end of the MapSource installation. It allows

you to unlock your maps so that you can load

detailed map data onto your iQue M5. You

must unlock your maps before you can load

them on your iQue M5.

1. When the MapSource UnlockWizard

Welcome screen appears, click Next.

2. Select “Yes, I have a 25-character

unlock code.” Then click Next.

3. Select “The unlock code is in my GPS,

please get it from my GPS.” Then click

Next. (If the wizard is unable to retrieve

the Unlock Code from your iQue M5,

you can type in the code from the

Unlock certiﬁcate in the product box.)

4. Follow the additional UnlockWizard

prompts to register your purchase and/

or exit the program. If you ever need to

re-install MapSource, you do not need

to re-register the software.

Note: We strongly recommend

that you register your iQue M5.

Registering allows you to unlock

maps for additional Garmin GPS

units and secure any needed repairs

to your unit if it is ever damaged.

Use the Quick Reference Guide

in this pocket as a reference

while you are learning to use

your new iQue M5.

Refer to these instructions to learn

how to use your iQue M5:

• The Que Applications Guide, in-

cluded in the product box, gives you

detailed, easy-to-follow instructions

for navigating with the iQue M5.

• The Operating Instructions, located

on the Companion DVD, help you

become familiar with the non-GPS

features of the iQue M5.

Step 9—Install Detailed Maps

Use MapSource to select and install detailed

maps on your iQue M5.

To install detailed maps:

1. Open MapSource on your personal

computer.

2. Click the Map tool on the toolbar

(or click Tools and then Map).

3. Click the map to select detailed

map areas. Each map area appears

outlined in gray. When you select a

map area, it appears shaded in pink.

Map tool

Send To Device icon

Size of maps selected Selected

map areas

4. To deselect a map area, click a shaded

pink area with the Map tool.

NOTE: You can also click and drag to

select multiple maps, or click and drag

while pressing Ctrl on your keyboard to

deselect multiple maps.

5. Check the Maps tab to the left of the

map area to make sure the maps you

have selected will ﬁt on your iQue M5

(64 MB total RAM on the unit; you can

also save them to an SD card). If you

have too much data selected, deselect

a few map areas.

6. Click the Send To Device icon

. Select your iQue M5 from the

menu that appears. Select where you

want to save the maps. Then click

Send.

7. Wait while MapSource transfers maps

to your iQue M5.

Congratulations! You are now ready to use the

iQue M5. Refer to the Que Applications Guide

for complete instructions on how to navigate.
