quick start manual

nüvi®200W Series

personal travel assistant

2 nüvi 200W Series quick start manual

GettinG Started

What Is in the Box?

nüvi unit

Suction cup mount to mount the nüvi to your windshield.

Vehicle power cable to charge/power your nüvi using a vehicle power outlet.

Dashboard disk to mount the suction cup mount on your dashboard instead.

•

SD card slot

Power and mini-

USB connector

Power key:

Slide to the left to turn the

unit on/off; slide to the

right to lock the screen

Speaker

Reset button

nüvi 200W Series quick start manual 3

Check your state and local trafc laws before mounting. Currently, state laws in California and Minnesota

prohibit drivers from using suction mounts on their windshields while operating motor vehicles. Other

Garmin dashboard or friction mounting options should be used. See page 12 for more details.

Step 1: Mount the nüvi

Select a suitable location to mount the nüvi on your windshield. Clean and dry the

suction cup and the selected area of your windshield.

1. Plug the power cable into the back of the nüvi.

2. Fit the ball on the end of the mount into the

round socket on the cradle and press rmly

until it snaps together.

3. Place the suction cup on the windshield, and

ip the lever back toward the windshield.

4. Press the bottom of the nüvi into the cradle,

and snap the top of the nüvi into place.

5. Plug the power cable into a power outlet

in your vehicle. Your unit should turn on

automatically if it is plugged in and your

vehicle key is turned to ON/ACC.

Ways to Charge the nüvi

Connect the vehicle power cable to the nüvi

and to a power outlet in your vehicle.

Connect an AC adapter (optional accessory)

to the nüvi and a wall outlet.

•

Cradle

Suction cup mount

Cradle

Suction cup mount

Vehicle power

cable

Vehicle power

cable

4 nüvi 200W Series quick start manual

Step 2: Congure the nüvi

To turn on your nüvi, slide the

Power key to the left. Follow the

on-screen instructions.

To turn off your nüvi, slide the

Power key to the left.

Step 3: Acquire Satellites

Before the nüvi can nd your current

location and navigate a route, you must

do the following:

1. Go outdoors to an open area, away

from tall buildings and trees.

2. Turn on the nüvi. Acquiring satellite

signals can take a few minutes.

The bars indicate satellite strength.

When at least one of the bars are green,

the nüvi has acquired satellite signals.

Now you can select a destination and

navigate to it.

NOTE: Software on your nüvi

could differ from the screen shots

in this manual.

Step 4: Use the nüvi

Help When You Need It

To get more information when and

where you need it, use the nüvi’s built-

in Help system. Touch > Help.

Touch a topic to view information

about it.

For help about the nüvi’s settings,

touch > Settings. Select a setting

category, and then touch .

Touch to adjust

the volume.

Touch to view

the map.

Touch to nd a

destination.

Touch to open

the Tool Kit.

nüvi 200W Series quick start manual 5

FindinG adeStination

Finding a Restaurant

1. Touch Where to > Points

of Interest > Food.

2. Select a category. Touch and

to see more choices.

3. Select a destination, and touch Go.

Finding an Address

1. Touch Where to > Address.

2. Select a country and state/province,

if necessary.

3. Touch Spell City. Enter the city/

postal code, touch Done, and select

the city/postal code in the list.

4. Enter the number of the address,

and touch Done.

5. Enter the street name, touch Done,

and select the street in the list.

6. Touch the address, if necessary.

Go Page Options

Touch an item in the search results list

to view the Go page.

Touch Go to create a turn-by-turn route

to this location.

Touch Show Map to view this location

on the map.

Touch Save to save this location

in Favorites.

Expanding Your Search

Your nüvi automatically searches for

places near your current location. To

search in a different area, touch Where

to > Near. Select an option. Touch OK.

6 nüvi 200W Series quick start manual

Spelling the Name

You can spell the name or part of the

name of the location you are looking

for using the on-screen keyboard.

1. Touch Where to > Points of

Interest.

2. Touch Spell Name.

3. Using the on-screen keyboard, enter

letters in the name. Touch Done.

4. Touch the place you are looking for,

and touch Go.

Go Home

Set your home location for the place

you return to most often. Touch Where

to > Favorites > Go Home.

Select an option to set your home

location.

After you set your home location, route

to it at any time by touching Where to

> Favorites > Go Home.

Adding a Stop to the Route

You can add one via point (stop) to the

route. The nüvi routes you to the via

point and then to your destination.

1. With a route active, touch Menu

> Where to,and search for the via

point.

2. Touch the place you are looking for,

and touch Go.

3. Select Add as Via Point.

Taking a Detour

If you need to take a detour when you

are navigating a route, touch Menu >

Detour. The nüvi attempts to get you

back on your original route, as soon as

possible. If the route you are currently

taking is the only reasonable option, the

nüvi might not calculate a detour.

Stopping the Route

To stop navigating a route, touch Menu

> Stop.

nüvi 200W Series quick start manual 7

ViewinG the Map paGe

Touch View map to open the Map page. The vehicle icon shows your

current location. Touch to save your current location. Touch the map and drag

to view different parts of the map. Touch any object on the map; an arrow appears

pointing at the object.

After you touch Go, the Map page opens with your route marked with a magenta

line. As you travel, your nüvi guides you to your destination with voice prompts,

arrows on the map, and directions at the top of the Map page. A checkered

ag marks your destination. If you depart from the original route, your nüvi

recalculates the route and provides new directions.

Touch Arrival or

Speed to open the

Trip Information page.

Touch Turn In to open

the Next Turn page.

Touch the text bar to

open the Turn List.

Touch to zoom out.

Touch to zoom in.

Touch Menu to return

to the Menu page.

Turn List Next Turn PageTrip Information

8 nüvi 200W Series quick start manual

CuStoMizinG Your nüVi

Locking Your nüvi

1. Touch > Settings > Security.

2. Touch the button next to Garmin

Lock. Touch OK.

3. Enter a four-digit PIN. Touch Yes to

accept the PIN.

4. Touch OK. Drive to a security

location (any location to which you

return frequently, such as your home

or ofce). Touch Set.

Each time you turn on the nüvi, enter

the four-digit PIN or drive to the

security location. To unlock your nüvi

at your security location, the nüvi must

have acquired satellite signals.

NOTE: If you forget your PIN and

your security location, you must

send your nüvi to Garmin to get

it unlocked. You must also send a

valid product registration or proof

of purchase.

Adjusting the Volume

Touch . Touch to lower the

volume or to raise the volume.

Adjusting the Screen

Brightness

Touch > Settings > Display >

Brightness. Touch to lower the

brightness and to raise it.

Locking the Screen

To prevent accidental screen taps, slide

the Power key to the right ( ). To

unlock the screen, slide the Power key

to the center position.

myGarmin™

Go to http://my.garmin.com to access

the latest services for your Garmin

products and to register your Garmin

unit.

nüvi 200W Series quick start manual 9

Resetting Your nüvi

If your unit stops responding, turn off

the unit, and then turn it back on. If this

does not help, reset your nüvi.

1. Disconnect the nüvi from external

power.

2. Press the Reset button on the

bottom of the nüvi.

3. Connect the nüvi to a power source.

Contact Garmin

In the USA, contact Garmin Product

Support by phone: (913) 397-8200

or (800) 800-1020, Monday–Friday,

8 AM–5 PM Central Time; or go to

www.garmin.com/support.

In Europe, contact Garmin (Europe)

Ltd. at +44 (0) 870.8501241 (outside

the UK) or 0808 2380000 (in the UK).

Clearing User Data



CAUTION: This deletes all user-

entered information.

1. Hold your nger on the lower-right

corner of the nüvi’s screen while

turning on the nüvi.

2. Keep your nger pressed until the

pop-up window appears.

3. Touch Yes to clear all user data.

All original settings are restored. Any

items that you have saved are erased.

Extras and Optional

Accessories

For more information about optional

accessories, go to http://shop.garmin

.com or www.garmin.com/extras, or

contact your Garmin dealer.

appendix

10 nüvi 200W Series quick start manual

Mounting on Your

Dashboard

Use the enclosed mounting disk to

mount your unit to the dashboard

and to comply with certain state

regulations.

IMPORTANT: The permanent

mounting adhesive is extremely

difcult to remove after it is

installed.

1. Clean and dry the dashboard where

you are placing the disk.

2. Remove the backing from the

permanent mounting adhesive on the

bottom of the disk.

3. Place the disk on the dashboard.

4. Place the suction cup mount on

top of the disk. Flip the lever down

(toward the disk).

Changing the Fuse



CAUTION: When replacing the

fuse, do not lose any of the small

pieces and make sure they are put

back in the proper place.

If your unit will not charge in your

vehicle, you may need to replace the

fuse located at the tip of the vehicle

adapter.

1. Unscrew and

remove the silver

or black, round end

piece.

2. Remove the fuse (glass and silver

cylinder) and replace with a 1A fast

blow fuse.

3. Ensure that the

silver tip is placed

in the end piece.

Screw on the end

piece.

UnscrewUnscrew

end

piece

silver tip

fuse

end

piece

silver tip

fuse

Altri manuali per nuvi 200W

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Garmin GPS

Garmin

Garmin BMW Motorrad Navigator IV Manuale utente

Garmin

Garmin GPSMAP 4008 - Marine GPS Receiver Manuale utente

Garmin

Garmin nuvi 350 Manuale utente

Garmin

Garmin GMX 200 Manuale utente

Garmin

Garmin Approach G3 North and Latin America Manuale utente

Garmin

Garmin GWS 10 Marine Wind Sensor Manuale utente

Garmin

Garmin NUVI 300 SERIES Guida di riferimento

Garmin

Garmin GMX 200 Manuale utente

Garmin

Garmin Oregon Series Manuale utente

Garmin

Garmin 010-00625-00 - Mobile - For BlackBerry Guida di riferimento

Garmin

Garmin 155XL Manuale utente

Garmin

Garmin Oregon 600t Manuale utente

Garmin

Garmin echomap chirp 50 series Manuale utente

Garmin

Garmin FORETREX 601 Manuale utente

Garmin

Garmin Zumo XT Manuale utente

Garmin

Garmin Skoda Navigation Manuale utente

Garmin

Garmin GPS III Plus Manuale utente

Garmin

Garmin GPSMAP 700 Series Manuale utente

Garmin

Garmin Nuvi 205 Series Manuale di istruzioni

Garmin

Garmin GPSMAP 4008 - Marine GPS Receiver Manuale utente

Garmin

Garmin EDGE 1030 Manuale utente

Garmin

Garmin eTrex 10 Manuale utente

Garmin

Garmin Edge 205/305 Manuale utente

Garmin

Garmin MSN Direct Receiver Guida alla configurazione

Manuali GPS popolari di altre marche

Raven

Raven Cruizer II Manuale

Hama

Hama 53118 Manuale utente

Jigabot

Jigabot EX Manuale utente

Pointer

Pointer Cellocator CelloTrack XT LTE Guida all'installazione

Queclink

Queclink GV55LITE Manuale utente

Voxson

Voxson Voxtrack GPS500 Manuale di istruzioni

Starcom Systems

Starcom Systems Kylos Compact Manuale utente

Cobra

Cobra Marine MC 600Ci Manuale utente

Cellocator

Cellocator CelloTrack T Manuale utente

Enfora

Enfora Mini-MT GSM2228UG001 Manuale utente

Magellan

Magellan eXplorist 100 Manuale utente

LTE

LTE G50B Manuale utente

SkyGolf

SkyGolf SkyCaddie SG1 Manuale utente

Kenwood

Kenwood DNN9330BT Manuale utente

Safelet

Safelet Indra Manuale utente

Bushnell

Bushnell 360100 Manuale utente

Geneq

Geneq SXBlue Manuale utente

ORIGO

ORIGO ED308 Manuale utente

Garmin nuvi 200W Manuale di istruzioni

Manuali GPS popolari di altre marche
