nüvi

2200 series

quick start manual

for use with these nüvi models:

2200, 2240, 2250

2 nüvi2200SeriesQuickStartManual

Getting Started



WARNING

See the Important Safety and Product

Information guide in the product

box for product warnings and other

important information.

When using your device for the rst

time, complete the following tasks.

1. Mount the device (page 2).

2. Connect the device to vehicle

power (page 3).

3. Register the device (page 5).

4. Check for updates.

• Software updates (page 5).

• Free map update (page 5).

5. Download the full owner’s manual

(page 5).

Mounting Your Device

Notice

Before mounting the device, see

the Important Safety and Product

Information guide for information

about laws pertaining to windshield

mounting.

1. Remove the clear plastic from the

suction cup.

2. Clean and dry your windshield

and the suction cup with a lint-free

cloth.

3. Press the suction cup to the

windshield.

4. While pressing, ip the lever back

toward the windshield.

nüvi2200SeriesQuickStartManual 3

5. Snap the mount

➊

onto the

suction cup arm

➋

➊

➋

6. Fit the bottom of your device into

the mount.

7. Tilt your device back until it

snaps into place.

Connecting the Device

to Vehicle Power



WARNING

This product contains a lithium-ion

battery. To prevent the possibility of

personal injury or product damage

caused by battery exposure to

extreme heat, remove the device from

the vehicle when exiting or store it

out of direct sunlight.

Charge your device before using it on

battery power.

1. Plug the vehicle power cable into

the mini-USB connector

➊

on the

back of the device.

➊

4 nüvi2200SeriesQuickStartManual

2. Plug the other end of the vehicle

power cable into a power outlet in

your vehicle.

3. If you are using a trafc receiver

in Europe, connect the external

antenna to the trafc receiver and

secure it to the windshield using

the suction cups.

After the device has been connected

to vehicle power, the following

should occur.

• The device turns on.

• The device acquires satellite

signals. When at least one of the

bars is green, your device has

acquired satellite signals.

NOTE: The device may need a

clear view of the sky to acquire

satellite signals.

• The device charges as you drive.

in the status bar indicates the

status of the internal battery.

About myDashboard

You can use myDashboard to register

your device, check for software and

map updates, access manuals, contact

product support, and more.

For more information, go to www

.garmin.com/dashboard.

Setting Up myDashboard

1. Connect the USB cable to the

USB connector on the device.

2. Connect the USB cable to the

USB port on your computer.

3. Double-click to open the

myDashboard Web page.

NOTE: If does not open, or

you are using Windows 7 or a

Mac® computer, go to www

.garmin.com/agent.

4. Follow the on-screen instructions.

nüvi2200SeriesQuickStartManual 5

Registering the Device

1. From myDashboard, click

2. Follow on-screen instructions.

3. Keep the original sales receipt, or

a photocopy, in a safe place.

Updating the Software

1. Open myDashboard (page 4).

2. Register the device (page 5).

3. Under Software Updates, click

Update Now.

4. Follow the on-screen instructions.

nüMaps Guarantee™

Your device is eligible for one

free map update within 60 days of

acquiring satellites while driving with

your nüvi. You are not eligible for

the free map update if you register

by phone or wait longer than 60

days after the rst time you acquire

satellites while driving with your

nüvi. For more information, go to

www.garmin.com/numaps.

Updating Maps

1. Open myDashboard (page 4).

2. Register the device (page 5).

3. Under Map Updates, click Update

Now.

4. Follow the on-screen instructions.

Downloading the Owner’s

Manual

The owner’s manual for your device

is available on the Garmin Web site.

1. Open myDashboard (page 4).

2. Register the device (page 5).

3. Click Manuals.

A list of the product manuals in

several languages appears.

4. Click Download next to the

manual for your device.

5. Click to save the le to your

computer.

6 nüvi2200SeriesQuickStartManual

Device Overview

➊

➋

➊

Power key

➋

microSD™ card slot

Using the Power Key

Press and quickly release the

Power key to view additional

options.

• Touch and drag the scroll bar

to adjust screen brightness.

• Touch Power Off to turn off

your device.

• Press and hold the Power key

to reset the device.

• Press and quickly release the

Power key to exit the menu.

About Points of Interest

The detailed maps loaded in your

device contain points of interest,

such as restaurants, hotels, and auto

services.

Finding a Point of Interest by

Category

1. From the Main menu, touch

Where To? > Points of Interest.

2. Select a category.

3. If necessary, select a subcategory.

4. Select a destination.

5. Touch Go!.

Touch > Save to save the

location to a Favorites folder on

the device. Use Favorites to save

the location of your workplace,

home, and other common

destinations.

nüvi2200SeriesQuickStartManual 7

6. If necessary, select an option.

• Touch Drive to calculate a

route you will navigate by

driving.

• Touch Walk to calculate a

route you will navigate by

walking.

• Touch Public Transit to

calculate a route that combines

public transit and walking.

NOTE: You must have

cityXplorer™ maps loaded to

navigate using public transit.

Go to www.garmin.com to

purchase cityXplorer maps.

Main Menu

➊

➋➌

➍ ➐➎ ➏

• Touch

➊

to select a transportation

mode.

• Touch

➋

to nd a destination.

• Touch

➌

to view the map.

• Touch

➍

to stop a route.

• Touch

➎

to detour a route.

• Touch

➏

to adjust the volume.

• Touch

➐

to open the menu of

tools and settings.

8 nüvi2200SeriesQuickStartManual

Your Route on the Map

Notice

The speed limit icon feature is for

information only and does not replace

the driver’s responsibility to abide

by all posted speed limit signs and to

use safe driving judgment at all times.

Garmin will not be responsible for

any trafc nes or citations that you

may receive for failing to follow all

applicable trafc laws and signs.

➊ ➋

➌

➏

➐

➍ ➎ ➑➒

Your route is marked with a magenta

line on the map. If you depart from

the original route, your device

recalculates the route. A speed limit

icon could appear as you travel on

major roadways.

• Touch

➊

to view the next turn.

• Touch

➋

to view the turn list.

• Touch

➌

to zoom in and out.

• Touch

➍

to return to the Main

menu.

Touch and hold to return to the

Main menu.

• Touch

➎

to change the data eld.

• Touch and drag

➏

to view a

different area of the map.

• Touch

➐

to view the Where Am

I? page.

• Touch

➑

to view the trip

computer.

• Touch

➒

to change the speed limit

if the speed limit icon shown on

the map is incorrect.

nüvi2200SeriesQuickStartManual 9

Using myTrends

As you drive with the device on,

myTrends™ gathers information that

allows the device to predict when

you are traveling to a common

destination, like your workplace or

home. When myTrends is activated,

the destination and estimated time of

travel will appear in the navigation

bar on the map.

myTrends only works for locations

that are saved as Favorites (page 6).

When myTrends information

appears in the navigation bar,

touch the navigation bar to view

route information.

About the Transportation

Modes

Automobile mode

Pedestrian mode

Routes are calculated differently

based on your transportation mode.

For example, in Automobile mode,

estimated time of arrival is calculated

using the speed limit of the roads on

the route. Pedestrian mode calculates

time of arrival based on walking

speed.

Changing Your Transportation

Mode

1. From the Main menu, touch the

transportation mode icon.

2. Select a mode.

3. Touch Save.

10 nüvi2200SeriesQuickStartManual

About Trafc

Notice

Garmin is not responsible for the

accuracy or timeliness of FM Trafc

information.

Some models can receive FM

Trafc Message Channel (TMC)

trafc content. The FM TMC trafc

receiver, which is integrated in the

vehicle power cable, is included in

some packages. The FM TMC trafc

subscription is automatically enabled.

For information about trafc receivers

and coverage areas, go to www

.garmin.com/trafc.

Receiving Trafc

Information

The vehicle power cable and the

device must be in data range of

an FM station transmitting trafc

information.

1. Connect the trafc receiver to an

external power source.

2. Connect the trafc receiver to the

device.

NOTE: Heated (metallized)

windshields could degrade the

performance of the trafc receiver.

Trafc on Your Route

When calculating your route, the

device examines the current trafc

and automatically optimizes the

route for the shortest time. If a severe

trafc delay occurs on your route

while you are navigating, the device

automatically recalculates the route.

You might still be routed through

trafc if no better alternative routes

exist.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Garmin GPS

Garmin

Garmin GPSMAP 64SX Manuale utente

Garmin

Garmin nuvi 3790V Manuale di istruzioni

Garmin

Garmin GPSMAP 60Cx Guida rapida

Garmin

Garmin EDGE 1030 Manuale utente

Garmin

Garmin GVN 52 - Antenna For Navigation System Manuale utente

Garmin

Garmin GPS 35 USB Manuale utente

Garmin

Garmin G3X Touch Specifiche tecniche

Garmin

Garmin GPSMAP 441 Manuale utente

Garmin

Garmin APPROACH G30 Manuale utente

Garmin

Garmin V Deluxe Manuale utente

Garmin

Garmin GPSMAP 64 Manuale utente

Garmin

Garmin 010-00625-00 - Mobile - For BlackBerry Guida di riferimento

Garmin

Garmin nuvi 205W Series Manuale di istruzioni

Garmin

Garmin Edge 810 Manuale di istruzioni

Garmin

Garmin GPS 12XL - Hiking Receiver Manuale utente

Garmin

Garmin nuvi 2405 series Manuale utente

Garmin

Garmin StreetPilot c510 Manuale del proprietario

Garmin

Garmin GPS 95 STD Personal Navigator Manuale utente

Garmin

Garmin Oregon 600t Manuale utente

Garmin

Garmin Approach S6 Manuale utente

Garmin

Garmin nuvi 5000 Manuale di istruzioni

Garmin

Garmin eTrex Legend Cx Guida di riferimento

Garmin

Garmin Oregon 600 Manuale utente

Garmin

Garmin GTM 10 Manuale utente

Manuali GPS popolari di altre marche

Raven

Raven Cruizer II Manuale

Hama

Hama 53118 Manuale utente

Jigabot

Jigabot EX Manuale utente

Pointer

Pointer Cellocator CelloTrack XT LTE Guida all'installazione

Queclink

Queclink GV55LITE Manuale utente

Voxson

Voxson Voxtrack GPS500 Manuale di istruzioni

Starcom Systems

Starcom Systems Kylos Compact Manuale utente

Cobra

Cobra Marine MC 600Ci Manuale utente

Cellocator

Cellocator CelloTrack T Manuale utente

Enfora

Enfora Mini-MT GSM2228UG001 Manuale utente

Magellan

Magellan eXplorist 100 Manuale utente

LTE

LTE G50B Manuale utente

SkyGolf

SkyGolf SkyCaddie SG1 Manuale utente

Kenwood

Kenwood DNN9330BT Manuale utente

Safelet

Safelet Indra Manuale utente

Bushnell

Bushnell 360100 Manuale utente

Geneq

Geneq SXBlue Manuale utente

ORIGO

ORIGO ED308 Manuale utente

Garmin nuvi 2250LT Manuale di istruzioni

Manuali GPS popolari di altre marche
